Specifications - DigiTech HARDWIRE HT-6 Owner's Manual

Specifications

Controls:
Jacks:
Tuning Range:
Tuning Accuracy:
Input Impedance:
Power Supply:
Current Draw:
Power Consumption:
Battery Life Expectancy:
DC Power Output Current:
Dimensions:
Weight:
Optional Power Supply:
Power Supply Polarity:
Power Supply Output:
*Recommended power saving GreenEdge power supply models.
On/Off Foot Switch, Mode Button, and Tuning Button
Input, Output
27.5 Hz - 1320 Hz
+/- 1 cent
Tuner On: >1 MΩ
Tuner Off (Bypass): True hardwire bypass
9 V Alkaline dry battery or Harman power supply
Tuner On: 45 mA (typical at 9 VDC)
Tuner Off (Bypass): 15 mA (typical at 9 VDC)
Tuner On: 400 mW (typical w/optional power supply)
Tuner Off (Bypass): 135 mW (typical w/optional power supply)
8 hrs (continuous use)/Prolonged battery life when in bypass mode
1 A max w/PS0913DC Power Supply
5.25"(L) x 3.5"(W) x 2.15"(H)
1.3 lbs.
Country (Voltage)
Japan (100 VAC, 50/60 Hz):
US and Canada (120 VAC, 60 Hz):
Europe (230 VAC, 50 Hz):
UK (240 VAC, 50 Hz):
Australia (240 VAC, 50 Hz):
PS200R (9.6 VDC 300 mA), PS0913DC* (9 VDC 1.3 A)
Compatible PSU Models
PS200R-100 or PS0913DC-01*
PS200R-120 or PS0913DC-01*
PS200R-230 or PS0913DC-01*
PS200R-240 or PS0913DC-02*
PS200R-240-AU or PS0913DC-02*
31
