Gigabyte AirCruiser Quick Setup Manual

Gigabyte aircruiser router with smartsetup3

Package Contents

GIGABYTE AirCruiser Router with SmartSetup3

Ethernet Network Cable

Power Adapter

User Guide on CD-ROM

AirCruiser Quick Start Guide & SmartSetup 3 Quick Guide

Make sure you have the ISP login information for your Internet connection handy. This information is

normally given to you when you registered for the Internet account. You can also call your ISP for these

settings.

Make sure all networking, DSL/Cable modems, and PC's are

turned OFF.

Connect one end of RJ-45 Ethernet network cable (included) from

your PC's Network Interface Card (NIC) to any one of the Router's

four (4) LAN ports.

Repeat above step to connect any other wired networking device.

Connect the terminal end of your DSL or cable modem network

line to the Router's WAN (Internet) Port.

Power on your DSL or cable modem.

Connect the AC power adapter to the Router's power port, and

then plug the adapter into the wall socket.

Make sure the power, LAN and WAN LEDs are illuminated green.

Unit will self test for approximately 5 seconds.

Power on the PC you connected to the router in Step C.

Note: Make sure your PC's TCP/IP Ethernet adapter is set to "Obtain an IP address automatically". For

more information see Windows Help.

Table of Contents

Do you have a question about the AirCruiser and is the answer not in the manual?

Page 1: Package Contents
Ethernet Network Cable Power Adapter User Guide on CD-ROM AirCruiser Quick Start Guide & SmartSetup 3 Quick Guide Connect the Broadband Router Make sure you have the ISP login information for your Internet connection handy. This information is normally given to you when you registered for the Internet account. You can also call your ISP for these settings.
Page 2: Internet Connection Type
Internet Connection Type There are three possible types of Internet connections. PPPoE: Most common for home DSL subscribers. You will need to provide the PPPoE User Name and Password. Dynamic IP (DHCP): No login information is needed. Static IP: You will need to complete the Internet IP Address, Subnet Mask, Gateway, and DNS fields. You will need to enter at least one DNS address.
Page 3 If you do make any router settings changes, you will need to click Submit button and please allow the Router to reboot itself for changes to apply. Test the setup by opening your web browser again and going to www.gigabyte.com.tw. Congratulations! You have completed the setup of the Gigabyte Wireless Router. Enjoy!
