Notes
- 14 -
3. Place the whole unit either vertically or horizontally on a stable surface to avoid
possible movement.
4. Use the reverse procedure to remove the stand
Operating the Elite
1. Plug one end of the AC Adapter
other end into a standard AC electrical outlet.
2. Insert a memory card into the appropriate slot
3. Slide the Power Switch to the ON position
4. The power On sequence includes display information on the screen and
illumination of the touch sensor array. When complete the frame will display the
first image. Use the Touch Sensor Array to play individual images, or slideshow
for continuous presentation of all images.
5. Keep the power connected for at least 4 hours to fully charge the battery.

Using the Built-in Internal Battery

The built-in internal Li-Polymer battery is mainly designed for short-term use (for
•
example, during a short demo or power outage).
• Battery operating time is approximately 30 minutes (for photo display only).
When the AC power is connected, the battery is always automatically charging. The
•
charging automatically stops when the battery is fully charged.
• When the internal battery is nearly drained, it is recommended to have it replaced at
your nearest service center to avoid possible data loss when AC power is temporarily
not available (for example, during a power outage).
Using USB to Computer
A USB Port is included so that content can be transferred to Elite internal memory
directly from the computer. When USB is connected, the frame will halt the slideshow
in progress with the display indicating it is connected to the computer. On your
computer, the unit will appear as a drive letter representing the internal memory. Use
standard drag-n-drop techniques to copy content from the computer to the frame.
into the Digital Photo Frame and plug the
.
.
- 3 -
