Lab.gruppen FP 13000 Technical Data page 2

Specifications FP 13000
General
Number of channels
Peak total output both channels driven
Peak output voltage per channel
Max. output current per channel
Max. Output Power
Per ch. (both ch.'s driven)
Bridged per ch.
Performance with Gain: 35 dB and VPL: 195 V
THD 20 Hz - 20 kHz for 1 W
THD at 1 kHz and 1 dB below clipping
Signal To Noise Ratio
Channel separation (Crosstalk) at 1 kHz
Frequency response (1 W into 8 ohms) +0/-3 dB
Input impedance
Input Common Mode Rejection, CMR
Output impedance @ 100 Hz
Voltage Peak Limiter (VPL), max. peak output
VPL, selectable per ch.
VPL, selectable when bridged
1)
Voltage Peak Limiter mode (per ch.)
Gain and Level
Amplifier gain selectable (all channels)
– rear-panel switches
Default gain
Level adjustment (per ch.)
Connectors and Switches
Input connectors (per ch.)
Output connectors (per ch.)
Output bridge mode
NomadLink network
Intelligent fans (on/off)
Power on/off and Remote enable on/off
Cooling
Front-panel indicators:
Common
Per channel
Power
Operating voltage, 230 V / 115 V nominal
Minimum power-up voltage, 230 V / 115 V
Power Average Limiter (PAL)
2)
Soft start / Inrush Current Draw
Mains connector
Dimensions (W/H/D)
Weight
Finish
Approvals
Note 1): Automatic -6 dB gain compensation when bridging channels.
Note 2): PAL can reduce the maximum output power to keep the power supply operating safely, and/or to prevent excessive current draw tripping the mains breaker.
Refer to the FP+ Operation Manual section 7.5.8 Power Average Limiter (PAL) for more information.
Note 3): Regarding n.r. (not recommended) notes: The amplifier will be fully operational in bridge-mode into 2 ohm and high impedance (Hi-Z) loads, but due to physical
constraints in the construction, the max. output power will not be significanty higher than running individual channels and therefore this mode of operation is not
recommended.
Note 4): Separate 230 V or 115 V versions available. Not selectable on the amplifier.
All specifications are subject to change without notice.
Intercooler, NomadLink and Class TD are national and/or international registered trademarks of Lab.gruppen AB. R.SMPS and VPL are trademarks of Lab.gruppen AB. All other trade-
marks remain the property of their respective owners. Copyright © 2009 Lab.gruppen AB. All rights reserved.
i n t e r n a t i o n a L c o n t a c t ▸ i n f o @ L a b g r u p p e n . c o m
2
13000 W
195 V
82 A peak
2 ohms
6500 W
n.r. 3)
<0.1%
<0.05%
>112 dBA
>70 dB
6.8 Hz - 34 kHz
20 kOhm
54 dB
19 mOhm
195, 170, 140, 116, 100, 80, 66, 54 V
390, 340, 280, 232, 200, 160, 132, 108 V
Hard / Soft
23, 26, 29, 32, 35, 38, 41, 44 dB
1)
35 dB
Front-panel potentiometer, 31 position detented from -inf to 0 dB
3-pin XLR, electronically balanced
Binding Posts 2-pole
A+B - Ch. A is signal input source
On board, 2 x RJ45 EtherCon
Yes, depending on presence of output signal
Individual switches on front-panel
Two fans, front-to-rear airflow, temperature controlled speed
NomadLink network; Power Average Limiter (PAL)
Signal present / High-impedance; -20 dB, -15 dB, -10 dB and -4 dB output signal;
Voltage Peak Limiter (VPL); Current Peak Limiter (CPL); Very High Frequency (VHF); High temperature; Fault; Mute
130-265 V / 65-135 V
4)
171 V / 85 V
Yes
Yes / max. 5 A
230 V CE: 16 A, CEE7; 115 V ETL: 30 A Twist lock
W: 483 mm (19"), H: 88 mm (2 U), Overall D: 396 mm (15.6"), Mounting D: 358 mm (14.1")
12 kg (26.4 lbs.)
Black painted steel chassis with black painted steel / aluminum front
CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
L a b . g r u p p e n a b ▸ S w e d e n
w w w . l a b g r u p p e n . c o m
4 ohms 8 ohms
4400 W 2350 W
13000 W 8800 W
connectors, IN and OUT
®
; Power on
2)
u S & c a n a d a c o n t a c t ▸ i n f o @ t c g - a m e r i c a S . c o m
|
16 ohms
1200 W
4700 W
Item no. TDS-FP13000_V7
