- Page 1 Multi Function Recorder An Integration of Backup System, DVD Player, Storage Card Media Player, Hi-Speed USB Card Reader, and More... User’s Guide ENGLISH...
- Page 2 INTRODUCTION Features Allows directly copying data from storage card to CD-R/CD-RW via a very simple operation without connecting to computer. Allows playing movie DVD(DVD-Video), VCD(VideoCD 1.1, 2.0, & 3.0), SVCD(Super VideoCD), Audio CD(CD-DA), and Kodak Picture-CD on TV/projector via RCA/S-Video. Allows playing JPEG/MPEG1/MPEG2/MP3 files in the disc or in the storage card on TV/projector via RCA/S-Video.
-
Page 3: Package Contents
INTRODUCTION Package Contents Carrying Bag Li Rechargeable Battery DC Power Adapter Remote Controller AAA Battery AV Cable(RCA) S-Video Cable USB Cable Quick Start Guide Driver CD Burning Software CD CD-R Scart (Optional) User’s Guide (Optional) Overview of Panels Battery Indicator Play/Pause/Enter Backup Stop/Cancel... - Page 4 INTRODUCTION Overview of Panels Slim Combo Device Locker Slim Combo Device Battery Locker Ejector 4-in-1 Socket CF Socket CF Socket 4-in-1 Socket Indicator Indicator CD Tray CD Tray Ejector Manual Ejector Disc Indicator...
-
Page 5: Remote Controller
INTRODUCTION Overview of Panels System Switch DC Power Connector USB Connector RCA Audio Connector RCA Video Connector S-Video Connector Power Switch Remote Controller 1: Power ON/OFF 2: Switch to DVD mode 3: Setup menu 4: Backup 5: Mute 6: Repeat 7: Transition mode of slide show 8: Thumbnail Mode/Root Menu 9: Volume up 10: Zoom in... - Page 6 Recover the battery cap, and the remote controller can work now. Charging Li Battery Set The MFR can use the Li battery set for independent power supply. The Li battery set must be charged before using it for power supply.
- Page 7 INFO:BEFORE USING Removing Li Battery Set The MFR also can work only with connected DC power adapter instead of the battery set. To remove the Li battery set, please refer to following instructions. Turn the MFR over. Push the locker of the Li battery set to BATTERY UNLOCK and pull the Li battery set to take it off.
- Page 8 Push the power switch to ON. When the power switch is on, you can use the remote controller to turn MFR off and on again. With only Li Battery set connected, using the power switch is recommended to save more power.
- Page 9 The MFR will load the disc automatically. After the disc loading process(for about 10 seconds), insert the storage card that is going to be backup. The MFR allows backing up one card at one time, so please do not insert two cards simultaneously. Press the Key once to get ready to backup, and the LCM will show “BACKUP?”...
- Page 10 After the backup begins, you can read the information of burning process from the LCM. The burning process is done, and the CD tray will extract the CD-R/CD-RW automatically. The MFR supports multi-session burning. If there is still free space in the burned CD-R/CD-RW, you can use it for backup again.
-
Page 11: Mp3 Player
USAGE: STAND-ALONE MP3 Player The MFR can play MP3 file in the card or in the disc just like a MP3 player. Refer to following instructions to learn how to use this function. Connect the headphone or speaker to the audio output of the MFR. -
Page 12: Using Setup Menu
The MFR can play movie DVD, movie VCD, audio CD, Kodak Picture-CD, and JPEG/MPEG1/MPEG2/ MP3 files in the disc or in the storage card on TV or projector via AV connection. To connect the MFR to the TV/projector, please refer to following instructions. - Page 13 USAGE: ON TV/PROJECTOR Using Setup Menu To quit the setup menu, move the light bar to EXIT SETUP and press the key; or press the Menu key again in any page. Setting TV Display Mode Enter the setup menu and get into the general setup page. Use the key to move the light bar to TV DISPLAY, and then press the key to move...
-
Page 14: Dvd Player
TV DISPLAY; to quit to the main page, move the light bar to MAIN PAGE and press DVD Player The same with a DVD player, the MFR can play movie DVD(DVD-Video), VCD(VideoCD 1.1, 2.0, & 3. 0), SVCD(Super VideoCD), Audio CD(CD-DA), and Kodak Picture-CD on TV/projector. To use this function, please refer to following instructions. - Page 15 USAGE: ON TV/PROJECTOR Volume Control While playing, the volume can be set by the remote controller. Press the VOL+ key to turn the volume up, and press the VOL- key to turn the volume down. If you want to turn the volume off, press the MUTE key on the remote controller.
- Page 16 Attention! While using the DVD player function, insertion of storage card will make the MFR switch to media player mode automatically. To return to DVD player mode, press the DVD MODE key on the remote controller.
-
Page 17: Media Player
The two card sockets cannot be used simultaneously, so please insert only one card at one time. Otherwise, using the disc and the card simultaneously is not recommended. After the insertion of the disc or the storage card, the MFR will show the contents in the disc or the card automatically. - Page 18 USAGE: ON TV/PROJECTOR Play JPEG File: Rotating In the viewing frame of the file, press the or the key to rotate the picture clockwise or counterclockwise in 90 degrees. Play JPEG File: Zooming In the viewing frame of the file, press the ZOOM ON/OFF key to activate the zoom function. After the zoom function is activated, press the ZOOM OUT or the ZOOM IN key to zoom the picture out/in from 25% to 200%.
- Page 19 USAGE: ON TV/PROJECTOR Play JPEG File: Slide Show Once entering a viewing frame, a slide show of all the pictures in the folder will be automatically performed. You can pause the slide show by pressing key on the remote controller or the control panel.
- Page 20 The two card sockets cannot be used simultaneously, so please insert only one card at one time. Otherwise, using the disc and the card simultaneously is not recommended. After the insertion of the disc or the storage card, the MFR will show the contents in the disc or the card automatically.
- Page 21 Power on the computer and enter the OS. Power the MFR on. Connect the USB cable from the USB connector of the MFR to the USB/Hi-Speed USB port of the computer. After the connection, the system will automatically detect and register new devices.
- Page 22 Read DVD/CD Connect the MFR to the computer and power them on. Eject the CD tray of the MFR and Insert the DVD/CD you want to read. Then you can read the disc as the way you use any other DVD-ROM.
- Page 23 To write a CD-RW/CD-R, you must have a pre-installed burning software on your system. Connect the MFR to the computer and power them on. Eject the CD tray of the MFR and Insert a CD-RW/CD-R. Then you can burn the disc as the way you use any other CD-RW/CD-R drives.
