Panasonic PT-DZ110XE Spec File

Panasonic PT-DZ110XE Spec File

3-chip dlp projector
Hide thumbs Also See for PT-DZ110XE:

Advertisement

Quick Links

Download this manual
P ro d u c t N u m b e r :
P ro d u c t N a m e :
As of May 2011. Specifications and appearance are subject to change without notice.
SFD10M004-2
S
P
E
C
PT DZ110XE
3-Chip DLP
™
Projector
F
I
L
E
The PT-DZ110XE is not equipped with a lens.
The PT-DZ110XE is not equipped with a lens.
1 / 1 9

Advertisement

loading

Related Manuals for Panasonic PT-DZ110XE

Summary of Contents for Panasonic PT-DZ110XE

  • Page 1 The PT-DZ110XE is not equipped with a lens. The PT-DZ110XE is not equipped with a lens. PT DZ110XE P ro d u c t N u m b e r : 3-Chip DLP ™ Projector P ro d u c t N a m e : As of May 2011.
  • Page 5 462 (18-3/16 ) 26 (1-1/32) 468 (18-7/16 ) 530 (20-7/8 ) 11 12 13...
  • Page 6 3-Chip DLP ™ Projector ∅60.5 (2-3/8) Upper edge of projected image Projected image (7-25/32) (13-15/32) Lower edge of projected image Projected image (3-15/16) (3-15/16) • All construction work should be done by a qualified technician. • When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop- ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.
  • Page 7 Screen size Distance to screen (L) Height from the edge of screen to centre of lens (H) (diagonal) Zoom Fixed-focus Zoom lenses Fixed- ET-D75LE6 ET-D75LE10 ET-D75LE20 ET-D75LE30 ET-D75LE4 ET-D75LE8 ET-D75LE5 focus Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Fixed-focus Except...
  • Page 8 Screen size Distance to screen (L) Height from the edge of screen (diagonal) to centre of lens ET-D75LE1 ET-D75LE2 ET-D75LE3 Zoom lens Zoom lens Zoom lens [m] / [in] min. max. min. max. min. max. 1.78 2.01 2.69 2.72 4.10 4.11 6.90 -0.05...
  • Page 9 Screen size Distance to screen (L) Height from the edge of screen to centre of lens (H) (diagonal) Zoom Fixed-focus Zoom lenses Fixed- ET-D75LE6 ET-D75LE10 ET-D75LE20 ET-D75LE30 ET-D75LE4 ET-D75LE8 ET-D75LE5 focus Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Fixed-focus Except...
  • Page 10 Screen size Distance to screen (L) Height from the edge of screen (diagonal) to centre of lens ET-D75LE1 ET-D75LE2 ET-D75LE3 Zoom lens Zoom lens Zoom lens [m] / [in] min. max. min. max. min. max. 1.78 2.07 2.77 2.80 4.22 4.23 7.10 -0.09...
  • Page 12 (Width of 0.2H projected image) 0.2H Standard postition of projected image (Width of 0.15H projected image) 0.15H Standard postition of projected image...
  • Page 13 Display mode Display Scanning frequency Dot clock Format resolution frequency (dots) (kHz) (kHz) (MHz) NTSC/NTSC4.43/PAL-M/PAL60 720 × 480i 15.7 59.9 − VIDEO/S-VIDEO PAL/PAL-N/SECAM 50.0 − 720 × 576i 15.6 480i (525i) 13.5 SDI/RGB/YP 720 × 480i 15.7 59.9 576i (625i) 720 ×...
  • Page 14 Display mode Display Scanning frequency Dot clock Format resolution frequency (dots) (kHz) (kHz) (MHz) 1280 × 800 1280 x 800 41.3 50.0 68.0 HDMI/DVI-D/RGB 83.5 49.7 59.8 1280 x 800 49.3 59.9 71.0 1280 x 800 62.8 74.9 106.5 71.6 84.9 122.5 MSXGA...
  • Page 15 I1 I2 P1 P2 ... Pn Start (2 byte) Semicolon Colon (1 byte) (1 byte) (1 byte) (1 byte) ID: 2 characters Parameters (2 bytes) (undefined length) Command 01 to 64: Address number (3 bytes) 0A to 0Z: Group ID (Control and/or query commands) ZZ: All units (ID ALL) ID designator...
  • Page 16 Projector PC (DTE) Command : Parameter Function Callback Standby power on POWER (STANDBY) Standby power off IIS:SDI INPUT SELECT IIS:SDI IIS:HD1 HDMI IIS:HD1 IIS:DVI IIS:DVI RGB 1 IIS:RG1 IIS:RG1 IIS:RG2 RGB 2 IIS:RG2 IIS:VID Video IIS:VID S-Video IIS:SVD IIS:SVD LPM:0 Dual (two lamps) LPM:0 LAMP SELECT...
  • Page 17 Command : Parameter Function Callback Description Q PW Main power status Standby (Off) Shutter function status Q FZ Freeze function status Input signal status HDMI RGB 1 RGB 2 Video S-Video On-screen display status Projector run time p1p2p3p4p5 00000h –99999h Q$L:1 Lamp 1 run time p1p2p3p4...
  • Page 18 500 mm (19-11/16 ˝ ) 500 mm (19-11/16 ˝ ) 500 mm (19-11/16 ˝ ) or more or more or more Do not stack projector 100 mm units directly on top of ( 3-15/16 ˝ ) one another. or more...
