Page 1: Operation Manual
VIVID TV BOX VTB-101 Operation Manual Please browse our online catalogue to view our full product range. 44-48 Maitland Road, Mayfield East, NSW, 2304 Australia, sales@converters.tv Phone +61 249689313 Fax +61 249689314 www.converters.tv... - Page 2 Introduction The compact unit easily turns your LCD, CRT monitor, plasma display or projector into a multimedia center. With a built-in TV tuner and multiple video ports, you can connect DVD players, digital cameras, VCRs or even game consoles. It has a custom built-in V- chip so the content can be filtered.
- Page 3 Features Stand-alone, Plug-n-Play. No software drivers required and no messy PC installation routines. No PC compatibility problems & special firmware design for some famous PDPs (Plasma Displays). Built-in TV tuner, support up to 125 channels with Fine Tuning function. Provide user-friendly OSD (on screen display) to control functions. Automatic source standard detection (NTSC/PAL/SECAM for video or S-Video).
- Page 4 Front Panel POWER Pressing this button to switch the unit On or Off. VIDEO SOURCE SELECTION Select the video source between TV/Cable, S-Video, AV or PC 3. POWER LED / INFRARED RECEIVER Lights when the TV BOX is powered up and ready to operate. Receive the Infrared signal from the remote control.
- Page 5 5. Line In- Please connect the audio from the sound card to Line In port. Thus you should be able to have sound from PC/external speakers even when your unit is in sound by mode. 6. S-Video- Please connect it to the S-Video In port when the external Video device is S-Video.
- Page 6 Operation Instruction Initial Settings For all function settings of the unit, you can use the supplied remote control unit. Please refer to the following steps below: Install 2 AAA batteries into the Remote Control. Power on the unit or press the Power button on the Remote Control Press the “Source”...
- Page 7 PICTURE setting Picture Sub-Menu provides BRIGHTNESS, CONTRAST, COLOR, TINT, SHARPNESS adjustment modes AND RESET. 1. In the Picture Sub-MENU, PRESS button to choose the required item. 2. Press button to adjust the selected item. E.g. To adjust the level of brightness: 3.
- Page 8 3. To adjust the selected item by button. E.g. Adjusted Bass level: LOUDNESS function enhances the audio volume from the TV BOX. Press turn it on or off. SURROUND function activates the surround effects of the TV Box. Press the to turn it on or off.
- Page 9 3. To scan program channels automatically, press the AUTOSCAN button. After finishing the AUTOSCAN, the scanned program channel will be saved. Channel Swapping Press and “Enter” button to enter the CHANNEL SWAP function. The Original column remains the present channel number. Key in the channel number you like to swap at the TARGET column.
- Page 10 Channel Rename The CHANNEL RENAME function allows you to edit the channel’s name. After you edit the channel name, it will shows below the channel number. Press and “Enter” button to enter the CHANNEL RENAME function. After entered the CHANNEL RENAME function, the Channel List dialog will show up. Press the button to select the channel you want to rename then press “Enter”...
-
Page 11: Channel Editing
After you have entered the channel name, press “Enter” then the channel name will be saved. The channel list will depend on the channels you’ve scanned. The scanned channel will be marked with a check, which means this channel is available. All the channels will be listed on the channel list screen. - Page 12 The channels are not actually removed or added but skipped from or recovered to the channel table. You can still select the removed channel by pressing the channel number. Adding a channel. For example to add CH 60 use the Remote Control unit, to select CH 60, then enter the TV function sub-menu, press button to enter the CHANNEL EDIT.
-
Page 13: System Setting
6. Favorite Channel Setting The favorite channel setting function provides 5 channels for setting your own favorite channels. You can set your favorite channel from OSD or your remote control unit. Press and “Enter” button to select the CHANNEL MEMORY function. In the CHANNEL MEMORY sub menu, press buttons to move the square mark and press the “Enter”... -
Page 14: Resolution Setting
RESOLUTION Setting The RESOLUTION Sub-Menu provides 640 X 480@60Hz, 800 X 600@60Hz, 1024 X 768@60Hz, 640x480@75Hz, 800x600@75Hz, 1024x768@75Hz modes 1. To enter your demand resolutions, press button to select one of them, then press “Enter” to confirm the setting and Exit to main menu OSD FUNCTION Setting The OSD FUNCTION Sub-Menu provides OSD POSITION, OSD COLOR settings. - Page 15 SYSTEM INFO Press and the Enter button to entry the system info sub menu. You can see the details information of the TV box from the system info sub menu. Please browse our online catalogue to view our full product range. 44-48 Maitland Road, Mayfield East, NSW, 2304 Australia, sales@converters.tv Phone +61 249689313 Fax +61 249689314...
-
Page 16: Sleep Setting
SLEEP SETTING SLEEP SETTING function provides the functionality switches off the TV Box automatically as desired; 5, 10, 15, 30, 60, 90 minute options. Press to select the sleep time. SYSTEM RESET function Press to select the SYSTEM RESET function and the Enter button. You can see the LED at the front panel will blink. - Page 17 Press the DISPLAY button to display the information of your video source and volume. Press the MUTE button to turn off the sound. Switch the video resource to TV, AV, and S-video, press the SOURCE button on the remote control unit. If you want to change the PIP screen size, then press the PIP button. The PIP function provides 3 screen sizes (small, medium, and large) for PIP selection.
-
Page 18: Favorite Function
How to record you favorite radio channel… The FM function provides 8 radio stations for you to set your own favorite channels. Please follow the instructions to set your favorite channels. 1. Tune the radio frequency to the channel, e.g.89.50. Press the FAV.SET button on the remote control unit;... - Page 19 1. POWER Powers the unit on and off. 2. SOURCE Selects the video source between TV/cable, AV, S-video and YCbCr (Component). 3. PC/AV Switches the AV and PC modes. 4. MODE Adjusts the video resolution – 1024x768, 800x600, 640x480 5. DISPLAY Displays current setting information on your screen.
-
Page 20: Number Keys
Adds the current channel, which you lose from the TV cable. 10. CH ERASE Press the button to erase the current channel, which you don’t like to see. 11. FINE TUNE - Tunes the TV channel signal down by continuous clicking the button. 12. - Page 21 Sets the current channel to “Favorite Channel”. 27. SURROUND Activates the surround effect. 28. LOUDNESS Enhances the volume setting 29. STATIC Enables Interlace Mode 30. SPORTS Enables De-interlace Mode Favorite Channel Setting 1. Go to the channel you want, press “ FAVSET “ button on the remote control unit. The favorite channel setting OSD will pop up.
-
Page 22: Troubleshooting
Trouble Shooting Symptom Solution Make sure the power cord is connected to AC outlet, DC plug is connected to DC IN port and the power is on. No picture on monitor Check the connection of your source signal. The IR control can’t control product ...
