Baby Lock Crescendo Quilting & Sewing Machine Quick Manual

Optional Accessories
Gold Standard Comprehensive Care Program
Sew with complete peace of mind with the Baby Lock Gold Standard
Comprehensive Care Program. With the Gold Standard, you'll receive
up to three years of unparalleled service and support for your machine.
All parts and labor are covered.
Plus, you will receive an instruction course on the Crescendo from
your retailer as well as exclusive savings on software, accessories
and other products.
Multi-Function Foot
Control
Give your hands more free
time with the Multi-Function
Foot Control. Start and stop
your sewing with the main
foot control and perform two
convenient functions with the
heel tap feature and side ped-
al. Choose two of these four
control options: thread cutting,
needle up/down, single stitch
and reverse stitch.
Circular Sewing
Attachment
This creative machine
accessory allows sewers to
stitch in a circular pattern
using any forward-feeding
utility or decorative stitch.
Technology Features • Ergonomic hands-free presser foot lift
with extra high setting 10mm automatic
• LCD Color Touch Screen with
and 13mm manual
touch pen
• 11.25" Workspace to the right
o Shows 260,000 colors
of the needle
o Measures 7" diagonally
• Sewing speed up to 1,050 spm
o Clock and Date
• Automatic drop feed
• Guide Beam for precision alignment
of stitches
Convenient Machine Features
o
Class 1 Laser Product
(IEC60825-1:2007) • Convenient one-touch buttons for
• Sensor Pen allows you to set preferences
o Start/Stop
on your fabric to:
o Reverse sewing
o Set a guideline for sewing
o Reinforcement stitch
o Select the needle position location
o Needle up/down
o Select custom zigzag widths
o Thread cutter
o Choose an ending point on the fabric
o Automatic presser foot lift
for stitches to stop sewing
o Auto threading
• Enhanced Stadium Lighting™ for
• Quick-Set bobbin winder
brighter true color LED lighting of 10"
• Needle plate with scale in inches and
around the needle
centimeters
• Digital Dual-Feed System ensures utmost
• Additional seam markings on bobbin
fabric control when feeding layers or
cover for needle position preference
difficult fabric types
• Quilting extension table for larger
work area
Key Quilting and Sewing
• Free arm
Features
• Two accessory storage compartments
• 573 Built-in stitches including
o 137 Utility with 14 one-step
Advanced Machine Features
buttonhole styles
• 2 USB drives: 1 (Type A) drive, connects
o 283 Decorative
with a mouse and flash drives and 1
o 20 Satin
(Type B) USB direct connect to a PC
o 61 Decorative satin
• Utility stitch editing capabilities
o 14 Cross
• Store personal stitch settings for each
o 58 Combinable Utility stitches
Utility stitch on machine
• 5 Built-in alphabets
• Decorative stitch editing capabilities
• Maximum utility stitch width: 7mm
• Back to the Beginning key, returns to the
• Stitch length 0.0mm - 5.0mm beginning of a decorative stitch pattern
• Digital Dual-Feed System ensures all
• Edit and combine Character/
layers feed evenly
Decorative stitches
• NeverMiss™ needle threader
• 24 Memory Pockets for Character/
• Automatic thread cutter Decorative stitches equaling 1 MG
• Independent bobbin winder motor and • Store additional stitch combinations
Quick-Set, top-loading bobbin on your PC using the 2 USB ports
• Advanced Pivoting Feature • Mirror-image capability for stitches
• Automatic Fabric Sensor System adjusts • Lock key for stitches keeps current
presser foot pressure and tension to settings
deliver perfect stitch
• Variable needle positions
• Programmable needle up/down
www.babylock.com
LBSP-BLCR 11/12
• Upper and lower thread sensors to
Crescendo
alert when threads are broken
• Lateral and diagonal feeding
• Fully automatic built-in darning
• Twin needle settings
Quilting & Sewing Machine
Additional Information
• Language conversion capabilities
(13 languages)
• Warranty (25-year limited, 10-year
parts, 5-year computer circuit, 5-year
electrical, 1-year labor)
• Optional Gold Standard
Comprehensive Care Program
Instructional and Help Resources
• Built-in Help Messages
• Built-in Operational Guide
• Built-in Sewing Application Guide
Included Accessories
• Sensor Pen and holder
• Touch pen (stylus)
• USB cable
• Knee lift
• 13 Feet
o Digital Dual-Feed System Foot
o 1/4" Quilting foot with a guide
o Buttonhole
o Overcasting
o Monogramming
o Zipper
o Zigzag
o Blind stitch
o Button fitting
o Free-motion quilting
o Free-motion open toe quilting
o Free-motion echo quilting
o Straight stitch foot
• Specialty bobbin case for bobbin work
• Cord guide bobbin cover
• Straight stitch needle plate
• Soft cover for machine
• Bobbins
• Seam ripper
• Twin needle
• Plus more
