  • Page 1 USER MANUAL SAILOR 6222 VHF DSC...
  • Page 3 SAILOR 6222 VHF DSC User manual Document number: 98-131184-C Release date: January 5, 2012...
  • Page 4 Disclaimer Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed by Thrane & Thrane. The information in this manual is provided for information purposes only, is subject to change without notice and may contain errors or inaccuracies.
  • Page 5 Please write "source for product SAILOR 6222 VHF DSC" in the memo line of your payment. You may also find a copy of the source at http://www.thrane.com/foss. This offer is valid to anyone in receipt of this information. Warranties Any attempt to install or execute software not supplied by Thrane & Thrane on this device will result in the warranty being void.

  • Page 6: Safety Warning

    Thrane & Thrane assumes no liability for the customer's failure to comply with these requirements. Ground the equipment To minimise shock hazard, the SAILOR 6222 VHF DSC unit must be connected to an electrical ground and the cable instructions must be followed. RF exposure hazards and instructions Your Thrane &...
  • Page 7 Alerte de sécurité Dangers liés à l'exposition aux fréquences radio et instructions Conformément à la réglementation d'Industrie Canada, le présent radio émetteur ne peut fonctionner qu'avec une antenne de type omnidirectionnelle, demi-onde ou d'un gain maximal de 4 dB, approuvée par Industrie Canada.

  • Page 8: Emergency Calls

    Emergency calls L L L L L if if if if ift C t C t C t Cov ov ov ov over er er er er P P P P P r r r r r e e e e e s s s s s s RED Button s RED Button s RED Button s RED Button...
  • Page 9 SAILOR 6222 VHF DSC is designed for occupational use only and must be operated by licensed personnel only. SAILOR 6222 VHF DSC is not intended for use in an uncontrolled environment by general public. SAILOR 6222 VHF DSC is designed for installation by a skilled...
  • Page 10 Training information The SAILOR 6222 VHF DSC is designed for occupational use only and is also classified as such. It must be operated by licensed personnel only. It must only be used in the course of employment by individuals aware of both the hazards as well as the way to...
  • Page 11 radio (25W selected) with an half wave omni-directional antenna having a maximum gain of 4 dB. This means all persons must be at least 200 cm away from the antenna when the radio is transmitting. Installation 1. An omni-directional antenna with a maximum power gain of 4 dB must be mounted at least 400 cm above the highest deck where people may be staying during radio transmissions.

  • Page 12: Manual Overview

    • Appendix with Technical specifications and Maritime channels. Important All installation information and instructions are not covered in this manual. Please download the SAILOR 6222 VHF DSC Installation manual at http://extranet.thrane.com/. In the installation manual you can read how to mount the VHF radio and how to connect accessories and external equipment, including detailed system configuration examples with cable specifications.

  • Page 13: Table Of Contents

    Setup ................38 Chapter 3 Service & maintenance Contact for support ............51 Maintenance ..............51 Troubleshooting guide .............53 Warranty and returning units for repair ......58 App. A Technical specifications Transceiver unit SAILOR 6222 VHF DSC ......61 General DSC specifications ..........63...
  • Page 14 Table of Contents NMEA data rates and formats .......... 64 SAILOR 6090 Power Converter 24—12 V ......64 App. B Maritime channels International channels (INT) ........65 US channels ..............66 CA channels ..............67 BI channels ..............68 Glossary ..................

  • Page 15: Chapter 1 Introduction

    Chapter 1 Introduction VHF radio with DSC Class A SAILOR 6222 VHF DSC your new VHF radio with full DSC functionality, is approved to MED, FCC and Industry Canada and is waterproof to the IPx8 and IPx6 standard. As part of the required safety...
  • Page 16 Chapter 1: Introduction Controls on the front plate Figure 1-1: Controls on the front plate 1. Loudspeaker. 2. Four soft keys with function title in the display. 3. Large display. 4. Keys 0 to 9 to enter numbers or text. 5.
  • Page 17 Chapter 1: Introduction SAILOR 6222 VHF DSC display The picture shows the display after start-up. The display holds various fields of information, LOC LO CALL depending on the currently selected function. ALERT 1. Functions you can select with DISTRESS/CALL DROBOS the soft keys.
  • Page 18 SAILOR 6201 Handset One SAILOR 6201 Handset with with cradle cradle is included in the delivery (additional) of the SAILOR 6222 VHF DSC. You can connect another SAILOR 6201 Handset with cradle. SAILOR 6203 Handset SAILOR 6203 Handset with cradle, with cradle waterproof to IPx6.

  • Page 19: Accessories Available

    (part number: 406204-940). 5m Connection cable, 1x10 pole: Use this cable in installations when connecting external equipment to the SAILOR 6222 VHF DSC. This cable is included in the SAILOR 6207 Connection Box for parallel Handsets (part number: 406207-941).
  • Page 20 Chapter 1: Introduction Accessory Description SAILOR 6197 Ethernet The SAILOR 6197 Ethernet Switch is Switch used in installations with SAILOR 6103 Multi Alarm Panels and in installations with ThraneLINK. The Ethernet switch has 5 ports. SAILOR 6090 Power The SAILOR 6090 Power Converter is Converter 24 V to used to provide 12 V DC for the SAILOR 12 V DC...
  • Page 21 Chapter 1: Introduction System configuration — example The SAILOR 6222 VHF DSC can be customized to suit your installation. The following illustration is one example of a system. For further configuration examples see the installation manual, Appendix B, System configurations.
  • Page 22 Chapter 1: Introduction Accessories available...

  • Page 23: Chapter 2 Operation

    Note Before using the VHF radio make sure that the VHF and DSC antennas, power cable and other external equipment are connected properly. For installation instructions see the SAILOR 6222 VHF DSC, Installation manual (download only). Overview In this chapter you find detailed instructions and guidelines for: •...

  • Page 24: General Use And Navigation

    Chapter 2: Operation General use and navigation Power on and volume in handset and speaker The VHF radio has a dual-function on/off knob for power on/off and volume control. To power on the VHF radio press the on/off knob. To power off the VHF radio, press and hold the on/off knob and follow the instructions in the display.
  • Page 25 Chapter 2: Operation Speaker devices The VHF radio can be equipped with the following speaker devices: • SAILOR 6201/SAILOR 6203 Handset with cradle and PTT (Push To Talk) button. • SAILOR 6202 Hand Microphone with PTT button. • SAILOR 6204 Control Speaker Microphone with PTT button. See Controller setup on page 45 for controlling the connected speaker devices.
  • Page 26 Chapter 2: Operation Position and MMSI number The position and MMSI number for the SAILOR SCAN 6222 VHF DSC radio is always shown in the DSC window (the lower half of the radio’s LOCAL display) in stand-by mode. The display shows DISTRESS/CALL also the current (latest) position (if a GPS is PHBOOK...
  • Page 27 Chapter 2: Operation If the GPS was present and then disappears a warning appears in the display after 10 minutes, then you can enter the position and UTC time manually as described above. Soft-key functions A number of functions of the SAILOR CALL 6222 VHF DSC are accessed and set using the four soft keys to the left of the...

  • Page 28: Adjusting The Squelch Level

    Chapter 2: Operation Changing the display light, night view Red text on black background is available for optimal night vision. To dim the display backlight, e.g. to give comfortable night vision, press, hold and turn the selector knob anti-clockwise. The display shows a brightness bar. At the brightness value 45 the display changes to night view with red text on black background.

  • Page 29: Vhf Radio Communication

    Chapter 2: Operation VHF radio communication Basic VHF operation You can make VHF calls using the Handset or another speaker device. Note A single, short press on the 16/C key always brings you to channel 16, the international calling and distress channel, no matter what state the radio is in.
  • Page 30 Chapter 2: Operation 5. Suggest a working channel other than 16 by saying: “Channel [suggested channel number]”. 6. Say: “Over.” and release the PTT button to allow the caller to confirm the suggested new channel. 7. Switch to the new channel using the keypad or by turning the selector knob to the agreed channel and begin your conversation.
  • Page 31 Chapter 2: Operation • Primary channels • Weather channels (if any) • Private channels (if any) With a long press on the 16/C key the radio changes to the call channel (channel 16 for the channel tables INT and BI, and channel 9 for the channel tables US and CA, if no other channel is programmed in Channel setup on page 41).
  • Page 32 Chapter 2: Operation communication. If PTT is pressed the radio transmits on the displayed channel. If a signal is received, it is received on the displayed channel. Engagement status The radio is engaged when you press PTT. This is indicated with the tab in the display.

  • Page 33: Watch

    Chapter 2: Operation Watch The SAILOR 6222 VHF DSC radio has a watch function with dual or triple watch. In dual watch, the working channel and channel 16 are watched. In triple watch the working channel, channel 16 and the programmed call channel are watched.

  • Page 34: Dsc Calls

    Chapter 2: Operation If there is a signal in one of the scanned channels, the display shows the channel in which the signal is received. If PTT is pressed while scanning, the scanning stops, the radio is tuned into the displayed channel and transmission starts immediately on the displayed working channel.
  • Page 35 Chapter 2: Operation Sending, acknowledging and cancelling own distress To send a distress message 1. Lift the cover of the red distress button and press and hold the distress button for longer than 3 seconds. For short step-by- step instructions how to proceed when sending a distress message see Emergency calls on page vi.
  • Page 36 Chapter 2: Operation • Time to next repeat of sending own distress. If you sent a distress message, the VHF radio is automatically set to channel 16, the channel reserved for international distress, safety and calling. ALERT: To send a distress message with specified nature When sending distress messages you can include the distress nature in the message.
  • Page 37 NO to return to distress sending procedure. 3. The SAILOR 6222 VHF DSC will send the self-cancellation call on channel 70 and the display automatically shows the message that you should say when cancelling the distress with a radio message.
  • Page 38 Power failure while in distress In case of a power failure or switch-off during the transmission of a Distress the SAILOR 6222 VHF DSC gives an audible warning after power-up and automatically resumes sending Distress 10 seconds after power up.
  • Page 39 Chapter 2: Operation DROBOSE — Distress Relay on behalf of someone else To send a distress message on behalf of someone else, do as follows: 1. From top-level standby press the soft key EXIT DISTRESS RELAY Type: RELAY INDIV: DROBOS. If it is not in the display, press the DISTRESS MMSI: soft key MORE until DROBOS appears.

  • Page 40: Receiving Distress Calls

    Chapter 2: Operation Relay items Description LAT: Enter the position and UTC information or unknown of LON: the vessel in distress. POS UTC: 4. Lift the cover of the red distress button and push the Distress button for 3 seconds. Receiving distress calls When the radio receives a distress call, the 2- SILENT...
  • Page 41 Chapter 2: Operation Distress call with errors If a distress call contains errors, it is still 4360.0 received. CALL RECEIVED (ERR) 4068.0 DISTRESS ALERT Press soft key OK and press VIEW for more FROM: 123456789 information. Errors are marked with CAT DISTRESS RECEIVED: 0:00:05 underscores (_).
  • Page 42 Chapter 2: Operation To make a DSC call, do as follows: EXIT DSC CALL Type: INDIVIDUAL Cat: ROUTINE 1. Press the soft key CALL. PHBOOK Ch: 9 2. Turn and press the selector knob to select the call type: Depending on the DSC call type you can enter category, MMSI number and channel for the following communication.
  • Page 43 Chapter 2: Operation established call (e.g. an individual call request followed by an acknowledgement). A session can be either active or on hold. The active session has control over the radio transmitter. A session can have a purpose. For example if the purpose is to establish a communication on a working channel.
  • Page 44 Chapter 2: Operation Session line Explanation RELAY calls You watch or participate in a distress (numerous) communication for another station in distress ALL SHIPS TX/RX You have sent / received an all ships call GROUP TX/RX You have sent / received a group call INDIVIDUAL TX/RX You have either sent a call request to a station to establish contact, or another station has made a...
  • Page 45 Chapter 2: Operation Soft keys to control DSC sessions Call or session types vary in control options, and options may also change if a session changes its state. The following table gives an overview of the DSC soft key commands available: Soft key —...
  • Page 46 Chapter 2: Operation Soft key — DSC Radio function session DROBOS Distress Relay on behalf of someone else. ANNUL (Cancel Own Cancels an inadvertently transmitted distress Distress) CONFIRM (Cancel Confirms action and proceed sequence, used in Own Distress) cancel distress procedure VIEW (in Cancel Own Turns page of text message.
  • Page 47 Chapter 2: Operation For other session types the soft key function VIEW typically shows the details from a single call. Detail fields for other calls than distress are: INFO —other Explanation calls CALL Type (on received call) – This may be shown on call reception Category of the call: Urgency, Safety or Routine FROM The initiator of the call...

  • Page 48: Handling Multiple Calls - Dsc And Voice

    Chapter 2: Operation Handling multiple calls — DSC and voice The SAILOR 6222 VHF DSC can control multiple DSC sessions simultaneously with a VHF communication session. All sessions can keep track of their session state and the communication channel used. They are handled in their respective sessions, in the order as they are started up.

  • Page 49: Phone Book

    Chapter 2: Operation State of session icon Meaning for the current call (DSC or voice) (inverted) Active call/session Call on hold Phone book Use the phone book when making a DSC call. You can enter up to 200 contacts. A contact has the following details: •...
  • Page 50 Chapter 2: Operation Adding a contact to the phone book To add a contact to the phone book do as follows: 1. Press the soft key PHBOOK. If it is not in the display, press the soft key MORE until PHBOOK appears in the display. 2.

  • Page 51: Replay Function

    Chapter 2: Operation Contact Description Listen to Group For GROUP: Press and turn the selector knob to select YES or NO for this contact, press the soft key OK. The radio will respond to calls to the specified group. 3. Press the soft key SAVE to save the contact information. 4.

  • Page 52: Setup

    Chapter 2: Operation Recording is not possible during playback. Up to 60 tracks or 240 seconds can be handled. During a power cycle the recorded tracks are deleted. The recorded channel is displayed. The message length is shown in seconds. The display shows how old the message is.

  • Page 53: Radio Setup

    Chapter 2: Operation • DSC call logs • System setup • Controller setup Accessing a setup page To change a setting in one of the SETUP pages, do as follows 1. Press the soft key SETUP. If it is not in the display, press the soft key MORE until SETUP appears.
  • Page 54 Chapter 2: Operation Parameter Description Watch DUAL: Dual watch monitoring the working channel and the priority Mode channel (channel 16, default for international channels). TRIPLE: Triple watch. The working channel is watched with the priority channel (channel 16) and the programmed call channel (if any, otherwise dual watch).
  • Page 55 Chapter 2: Operation Channel setup Parameter Description Channel Mode To select the channel table for the primary channel. Channel tables available: INT, BI, US, CA, ALT. See also VHF channel table on page 17. Bandwidth Selection of the bandwidth for the fixed pre-programmed channels.

  • Page 56: Power Supply

    Chapter 2: Operation Parameter Description ALT. Channels As described above. Private Channels As described above. Power Supply Parameter Description Monitor Set this to ENABLED if the radio is connected to a TT-6081A Power Supply and Charger. Set this to DISABLED for any other power supply. Status Visible if ENABLED.
  • Page 57 Chapter 2: Operation DSC setting Description Auto-Ack Position Auto-acknowledgement of position DSC messages. OFF (default) or ON Auto-Ack Auto acknowledgement of individually addressed, non Individual distress DSC messages OFF or ON (default) Non-Distr. Inactivity time-out to exit non-distress functions (e.g. in Inactivity setup) without automatic time-out (OFF): Range: OFF, 1 to 30 minutes, in 1 min.

  • Page 58: System Setup

    Chapter 2: Operation DSC setting Description DSC Self Test You can set the radio to run a DSC self test. OFF: Disabled (default) RUN: Run test. For further details about this test see DSC routine testing on page 54. DSC call logs Use the soft keys to leaf through all logs.

  • Page 59: Controller Setup

    Chapter 2: Operation SYSTEM SETUP Description Theme Changes the display colour. BlackOnWhite (default) WhiteOnBlack NMEA input (baud rate) 4800 (cannot be edited) GPS input Changes the GPS input. NMEA use if the GPS input is from the ACC connector. LAN use if the GPS input is from the LAN connector. Factory Defaults Resets the radio to factory defaults.
  • Page 60 Chapter 2: Operation Controlling device Description Ext. speaker FIX: Fixed level is set for external speaker REL: Relative level following volume adjustment of the internal speaker Ext. fixed vol: External speaker fixed volume: OFF, 5 to 100 in steps of 5 Wheel lock: You can set a time interval after which the SQ, volume and selector knobs are locked and protected against...
  • Page 61 Chapter 2: Operation Top-level standby SETUP EXIT Setup...
  • Page 62 Chapter 2: Operation Setup pages RADIO SETUP Scan Hang Time Scan Resume Watch mode Priority Scan ATIS code CHANNEL SETUP Channel Mode Bandwidth Call Channel Int. Channels BI. Channels US. Channels CA. Channels ALT. Channels Private Channels POWER SUPPLY Monitor DSC SETUP Positon &...
  • Page 63 Chapter 2: Operation Setup pages SYSTEM SETUP Printer Config System time & date Inactivity timeout Language Theme NMEA in (baud) GPS Input Factory Defaults Password Radio Info CONTROLLER SETUP Handset 1 vol: Handset 2 vol: Ext. Speaker Ext. fixed vol: Wheel lock Setup...
  • Page 64 Chapter 2: Operation Setup...

  • Page 65: Chapter 3 Service & Maintenance

    Maintenance Preventive maintenance Maintenance of the SAILOR 6222 VHF DSC can be reduced to a maintenance check at each visit of the service staff. Inspect the radio for mechanical damages, salt deposits, corrosion and any foreign material. Due to its robust construction and ruggedness the radio has a long lifetime.
  • Page 66 Chapter 3: Service & maintenance DSC self test To run a control routine DSC self test, do as follows: 1. Press the soft key SETUP. If it is not in the display, press the soft key MORE until SETUP appears. 2.

  • Page 67: Troubleshooting Guide

    Chapter 3: Service & maintenance Troubleshooting guide Action Symptom Remedy The radio The display is Check if power is present. will not turn empty. Check fuse which is placed in the power connector. Check performance of power supply if connected to one.
  • Page 68 Chapter 3: Service & maintenance Action Symptom Remedy DSC routine Check the DSC function regularly. Verify the testing complete DSC installation, with antennas, by transmitting a Safety Test call to another station (coast or ship). The test call is generated using the DSC call flow via menu CALL.
  • Page 69 Chapter 3: Service & maintenance Action Symptom Remedy System time DSC logs are A wrong radio time indication should occur only if sorted with GPS position source is not connected or providing wrong time correct time data. A valid GPS time signal will stamp or update the UTC time used for time stamping the radio time is...
  • Page 70 Chapter 3: Service & maintenance Action Symptom Remedy WARNING: Power supply In Setup, Power Supply, set Monitor to disabled. POWER status cannot You can only monitor the power supply if the radio SUPPLY is powered by a SAILOR 6081 Power Supply Unit LOST monitored.
  • Page 71 Chapter 3: Service & maintenance Replacing the fuse in the SAILOR 6090 Power Converter One fuse is installed in the SAILOR 6090 Power Converter. If the fuse is blown, do as follows: 1. Track down why the fuse was blown and solve the problem. 2.

  • Page 72: Warranty And Returning Units For Repair

    Chapter 3: Service & maintenance Warranty and returning units for repair Should your Thrane & Thrane product fail, please contact your dealer or installer, or the nearest Thrane & Thrane partner. You will find the partner details on thrane.com where you also find the Thrane & Thrane Self Service Center web-portal, which may help you solving the problem.
  • Page 73 Chapter 3: Service & maintenance 4. Seal the shipping container securely. 5. Mark the shipping container FRAGILE to ensure careful handling. Failure to do so may invalidate the warranty. Warranty and returning units for repair...
  • Page 74 Chapter 3: Service & maintenance Warranty and returning units for repair...

  • Page 75: Transceiver Unit Sailor 6222 Vhf Dsc

    Appendix A Technical specifications Transceiver unit SAILOR 6222 VHF DSC Item Specification Weight SAILOR 6222 VHF DSC < 1.50 kg (3.3 lbs) approximately Box weight 3.8 kg (8.4 lbs) approximately, including SAILOR SAILOR 6222 VHF DSC 6201 Handset with cradle and wall mount cradle, SAILOR 6090 Power Converter and Installation and user manual in box.
  • Page 76 High: 21 W ±0.75 dB Low: 0.8 W ±0.75 dB Frequency error Below 500 Hz Adjacent channel power Below 75 dB Below 0.25 W Conducted spurious emission Distortion Below 3% S/N ratio Better than 46 dB Receiver Transceiver unit SAILOR 6222 VHF DSC...

  • Page 77: General Dsc Specifications

    Appendix A: Technical specifications Item Specification Sensitivity < -119 dBm typically @ 20 dB SINAD CCITT weighted LF power Built-in loudspeaker: 6 W (at 5 kHz dev./1 kHz tone). External loudspeaker: 6 W / 8 Ohm Distortion Below 5% S/N ratio Better than 43 dB Spurious emissions Below 2 nW...

  • Page 78: Nmea Data Rates And Formats

    Appendix A: Technical specifications Item Description Frequency error Below ± 1 Hz Residual modulation Below —26 dB NMEA data rates and formats Item Value 61162-1 4800,8,n,1 61162-2 38400,8,n,1 SAILOR 6090 Power Converter 24—12 V Item Description Weight 300 g Dimensions Height: 33 mm Width: 190 mm Depth: 85 mm...

  • Page 79: International Channels (Int)

    Appendix B Maritime channels International channels (INT) International Channels Channels SIMPLEX DUPLEX Channels SIMPLEX DUPLEX Intership Port Port Public Intership Port Port Public 156,050 160,650 156,025 160,625 156,100 160,700 156,075 160,675 156,150 160,750 156,125 160,725 156,200 160,800 156,175 160,775 156 250 160 850 156,250 160,850 156 225 160 825 156,225 160,825...

  • Page 80: Us Channels

    Appendix B: Maritime channels US channels Channels SIMPLEX DUPLEX Channels SIMPLEX DUPLEX Channels 156,050 156,050 162,550 162,400 162,475 156,175 156,175 162,425 156,250 156,250 162,450 156,300 156,300 156,275 156,275 162,500 156,350 156,350 156,325 156,325 162,525 156,400 156,400 156,375 156,375 156,450 156,450 156,425 156,425 156,500 156,500 156,475 156,475...

  • Page 81: Ca Channels

    Appendix B: Maritime channels CA channels Channels SIMPLEX DUPLEX Channels SIMPLEX DUPLEX Channels 156,050 160,650 156,025 160,625 162,550 156,100 160,700 156,075 156,075 162,400 156,150 160,750 156,125 156,125 162,475 156,200 156,200 156,175 156,175 162,425 156,250 156,250 156,225 160,825 162,450 156,300 156,300 156,225 156,225 162,500 156,350 156,350...

  • Page 82: Bi Channels

    Appendix B: Maritime channels BI channels Channels SIMPLEX DUPLEX Channels SIMPLEX DUPLEX Intership Port Port Public Intership Port Port Public 156,050 160,650 156,025 160,625 156,100 160,700 156,075 160,675 156,150 160,750 156,125 160,725 156,200 160,800 156,175 160,775 156,250 160,850 156,225 160,825 156,300 156,300 156,275 160,875 156,350 160,950...

  • Page 83: Glossary

    Glossary Glossary Automatic Identification System, a short range coastal tracking system used on ships and by Vessel Traffic Services for identifying and locating vessels by electronically exchanging data with other nearby ships. ATIS Automatic Transmission Identification System DROBOS Distress Relay On Behalf Of Someone else Digital Selective Calling EPIRB Emergency Position-Indicating Radio Beacon.
  • Page 84 Glossary MMSI Maritime Mobile Service Identity. A series of nine digits which are sent in digital form over a radio frequency channel in order to uniquely identify ship stations, ship earth stations, coast stations, coast earth stations, and group calls. These identities are formed in such a way that the identity or part thereof can be used by telephone and telex subscribers connected to the general telecommunications network to call ships automatically.

  • Page 85: Index

    Index Index Numerics backlight, 1 dim, 10 16/C, 10, 15 bandwidth, 41 Bi, 68 Bi channels, 68 browse channels, 10 acknowledgement, distress, 23 action line, display, 3 activate scan resume, 39 CA channel table, 41 scanning, 20 CA channels, 67 watch, 19 CALL, 35 ADD, 36...
  • Page 86 Index channels distress Bi, 68 acknowledgement, 23 CA, 67 cancelling, 23 international, 65 display, 21 primary, 17 message relay, 25 private, 17 nature, 21 US, 66 power failure, 24 weather, 17 received calls, 26 Colour theme, 45 send from alarm panel, 24 Comm Inactivity, 43 time since activation, 21 configuration...
  • Page 87 Index editing a contact, 37 icons Emergency call sheet, x session state, 29 emergency calls, vi input engagement status, 18 NMEA, 45 enter position manually, 12 installation EPIRB cradle for 6201, 5 nature in DROBOS, 25 handset cradle, 5 error messages, 51 installation guide, A3, x installation manual, x Alarm Panel, x...
  • Page 88 Index MAYDAY, vi phone book, 35 medical transport, 43 add contact, 36 menu, overview, 46 delete a contact, 37 message edit a contact, 37 replay, 37 position MMSI enter manually, 12 change, 45 position data wrong number in the radio, 54 enter manually, 42 monitor power supply, 42 position Info, 42...
  • Page 89 Index someone else, 25 setup remote control, 14 controller, 45 replay, 1, 37 DSC call logs, 44 button, 3 overview, 46 reset to default, 45 parameters, 46 resume time, 39 Radio, 39 RF exposure hazards, iv system, 44 watch, 39 DSC self test, 44 simplex, 1 soft key, 13...
  • Page 90 Index system configuration volume example, 8 louder, 10 system setup, 44 softer, 10 speaker, 10 Volume knob, 3 TAG, 20 remove, 20 tagged channels warnings, 51 view, 20 warranty, 58 technical data, 61 limitation, iv temperature WATCH, 19 operational, 61, 64 watch storage, 61, 64 dual and triple, 19...
  • Page 92 98-131184-C info@thrane.com thrane.com •...
