Maximum Tilt - Hasselblad CFII Specifications

MOVeMenTs
The lens can be shifted 18 mm, either upwards or down-
wards, and it can be tilted 10 degrees up or down. Tilt and
shift can be combined according to the diagram.
hTs settings are presented on camera grip LCd and are
also embedded in the image file.

MaXIMUM TILT

The graph shows the maxi-
mum amount of tilt that can
be used without vignetting as
a function of the amount of
shift used.
format 36×48mm.
TILT and shIfT adapTer
10
8
6
4
2
0
0 5
Shift (mm)
Landscape mode
Portrait mode
10 15
www.hasselblad.com
