2008 Mountaineer (mnt)
Owners Guide (post-2002-fmt)
USA (fus)

Table of Contents

12
20
77
85
96
101
102
105
110
115
135
135
135
141
4
12
17
20
24
32
40
42
45
49
76
77
79
82
83
96
97
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mountaineer 2008 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford Mountaineer 2008

Summary of Contents for Ford Mountaineer 2008

  • Page 1: Table Of Contents

    Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems How to get going AM/FM stereo with CD AM/FM stereo with in-dash six CD Auxiliary input jack (Line in) USB port Satellite radio information Family entertainment system Navigation system Climate Controls Manual heating and air conditioning...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction Control™/AdvanceTrac Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2007 Ford Motor Company...

  • Page 4: Introduction

    For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
  • Page 5 Introduction Fuel pump shut-off switch: In the event of an accident the safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.
  • Page 6 Introduction BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.
  • Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
  • Page 8 Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs.
  • Page 9 Introduction Export unique (Non–United States/Canada) vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide. A market unique supplement may be supplied that complements this book.
  • Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
  • Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 12: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 13 Instrument Cluster Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter.
  • Page 14 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when the ignition is turned to ON, continues to flash or...
  • Page 15 Instrument Cluster Engine coolant temperature: Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Refer to Engine coolant in the Maintenance and Specifications chapter. Never remove the coolant reservoir cap while the engine is running or hot.
  • Page 16 Instrument Cluster AdvanceTrac : Flashes when the AdvanceTrac with RSC system is active. Illuminates solid when the system has been disabled (by the driver or as a result of a system failure), refer to the Driving chapter for more information. If “SERVICE RSC NOW”...

  • Page 17: Gauges

    Instrument Cluster Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
  • Page 18 Instrument Cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating, refer to Engine coolant in the Maintenance and Specifications chapter.
  • Page 19 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

  • Page 20: Entertainment Systems

    Quick start — How to get going Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 21 Entertainment Systems Listening to satellite radio (if equipped) 1. If the audio system is turned off, press VOL-PUSH to turn the radio on. Turn VOL-PUSH to adjust the volume. Note: The system may take a few moments to turn on. 2.
  • Page 22 Entertainment Systems For a single CD system, if a disc is not already loaded, insert only one, label side up into the CD slot. LOADING CD and READING DISC will appear in the display. The first track on the disc will begin playing. For an in-dash six CD system, if a disc is not already loaded, press LOAD.
  • Page 23 Entertainment Systems Press SHUFFLE to engage shuffle mode. SHUFFLE ON will appear in the display. If you wish to engage shuffle mode right away, press SEEK to begin random play. Otherwise, random play will begin when the current track is finished playing. CD SHUF will appear in the display.

  • Page 24: Am/Fm Stereo With Cd

    (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 25 Entertainment Systems In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to Category Mode under Menu for further information. Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. (Phone): If your vehicle is equipped with SYNC (late availability), press to access SYNC...
  • Page 26 Entertainment Systems • DELETE SONG: Press OK to delete a song from the system’s memory. Press to cycle through the saved songs. When the song appears in the display that you would like to delete, press OK. The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED.
  • Page 27 Entertainment Systems To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use SEEK to toggle RBDS ON/OFF. When RBDS is OFF, you will not be able to search for RBDS equipped stations or view the station name or type. Press OK to close and return to the main menu.
  • Page 28 Entertainment Systems TRACK/FOLDER MODE: Available only on MP3 discs in CD mode. In track mode, press SEEK, SEEK to scroll through all tracks on the disc In folder mode, press SEEK, SEEK to scroll through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
  • Page 29 Entertainment Systems (Jazz, Rock, News, etc.), press SEEK, SEEK to seek to the previous/next channel in the selected category. Press and hold SEEK, SEEK to fast seek through the previous /next channels. In TEXT MODE, press SEEK, SEEK to view the previous/additional display text.
  • Page 30 Entertainment Systems 10. FF (Fast forward): Press FF to manually advance in a CD/MP3 track. 11. REW (Rewind): Press REW to manually reverse in a CD/MP3 track. 12. Memory presets: To set a station, select the desired frequency band, AM, FM1 or FM2. Tune to the desired station.
  • Page 31 Entertainment Systems 14. AM/FM: Press to select AM/FM1/FM2 frequency band. 15. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. Note:If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.

  • Page 32: Am/Fm Stereo With In-Dash Six Cd

    (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 33 Entertainment Systems In satellite radio mode (if equipped), press to tune to the next/previous channel. In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to Category Mode under Menu for further information. Satellite radio is available only with a valid SIRIUS radio subscription.
  • Page 34 Entertainment Systems • DELETE SONG: Press OK to delete a song from the system’s memory. Press to cycle through the saved songs. When the song appears in the display that you would like to delete, press OK. The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED.
  • Page 35 Entertainment Systems RBDS: Available only in FM mode. This feature allows you to search RBDS-equipped stations for a certain category of music format: CLASSIC, COUNTRY, INFORM, JAZZ/RB, ROCK, etc. To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use SEEK to toggle RBDS ON/OFF.
  • Page 36 Entertainment Systems TRACK/FOLDER MODE: Available only on MP3 discs in CD mode. In track mode, press SEEK, SEEK to scroll through all tracks on the disc In folder mode, press SEEK, SEEK to scroll through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
  • Page 37 Entertainment Systems 5. SEEK: In radio and CD/MP3 mode, press to access the previous ) or next ( ) strong station or track. In satellite radio mode (if equipped), press SEEK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK, SEEK to seek to the previous/next...
  • Page 38 Entertainment Systems 8. FOLDER : In folder mode, press FOLDER to access next folder on MP3 discs, if available. FOLDER: In folder mode, press FOLDER to access the previous folder on MP3 discs, if available. 10. FF (Fast forward): Press FF to manually advance in a CD/MP3 11.
  • Page 39 Entertainment Systems In CATEGORY MODE, press SCAN to hear a brief sampling of the channels in the selected category. Press again to stop. Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. In TEXT MODE sometimes the display requires additional text to be displayed.

  • Page 40: Auxiliary Input Jack (Line In)

    Entertainment Systems (CD eject): To eject a disc from the system, press . Select the correct slot number using memory presets 1–6. When ready, the system will eject the disc and the display will read REMOVE CD. If the disc is not removed in 15 seconds, the system will reload the disc.
  • Page 41 Entertainment Systems 4. Turn the radio on, using either a tuned FM station or a CD loaded into the system. Adjust the volume to a comfortable listening level. 5. Turn the portable music player on and adjust the volume to 1/2 the volume.

  • Page 42: Usb Port

    USB port (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 43 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
  • Page 44 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.

  • Page 45: Satellite Radio Information

    Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
  • Page 46 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
  • Page 47 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. than two seconds to This message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does system failure not clear within a short present.
  • Page 48 Entertainment Systems Radio Display Condition Action Required NO TEXT Song title information Song title information not available. not available at this time on this channel. The system is working properly. NO TEXT Category information Category information not available. not available at this time on this channel.

  • Page 49: Family Entertainment System

    FAMILY ENTERTAINMENT DVD SYSTEM (IF EQUIPPED) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 50 Entertainment Systems 3. Press the power button on the DVD player, then press Play ( to begin to play the disc. If a DVD is already loaded into the system, press PLAY on the DVD player. Note: If sound can be heard, but no video is present, press VIDEO to select the video source (DVD or aux-inputs).
  • Page 51 Entertainment Systems 3. The disc will begin to play and the ’CD Audio Disc’ screen will display. From this screen, you can also select from COMPRESSION, SHUFFLE and SCAN features. To play an MP3 disc in the DVD system: 1. Ensure that the vehicle ignition is in the RUN or ACCESSORY position.
  • Page 52 Entertainment Systems 3. Connect an auxiliary audio/video source by connecting RCA cords (not included) to the RCA jacks on the left hand side of the system. • Yellow (1) — video input • White (2) — left channel audio input •...
  • Page 53 Entertainment Systems Using the infrared (IR) wireless headphones: 1. Press the power control on the earpiece to turn the headphones ON. 2. Select Channel A or B for each set of wireless headphones by using the A/B control on the ear piece. 3.
  • Page 54 Entertainment Systems DVD player controls ENTER MENU RETURN MEDIA VIDEO VOLUME 1. Headphone control A/B: Press to select either the A or B headphone source. Then press MEDIA to select the desired playing media for that headset. When a headphone channel has been selected (A or B), selections will affect the source on that channel only.
  • Page 55 Entertainment Systems (Fast forward): Press and release for the next chapter or track. Press and hold to forward search a DVD, Video CD, or FES CD in DVD/CD mode. (Play/Pause): Press (Play) to select DVD mode (and to turn the DVD system on if it is off). If a disc is present, it will resume or begin to play.
  • Page 56 Entertainment Systems (Headphones/Speakers): Press once for Dual Play (Headphone mode- the rear speakers are muted) and press again for Single Play (same media playing through all speakers). You can also press the 2 and 4 memory preset buttons on the audio system at the same time to perform the same function.
  • Page 57 Entertainment Systems Remote control Unless otherwise stated, all operations can be carried out with the remote control. Always point the remote control directly at the player. Ensure that there are no obstructions between the remote and player. 1. Power control: Press to turn the FES (Family Entertainment System) ON/OFF.
  • Page 58 Entertainment Systems 7. VOL (Volume): When in Single Play, press to increase ( ) or decrease ( ) the volume over all speakers. When in Dual Play, press to increase ( ) or decrease ( ) the volume for the wired headphones. (Wireless headphone volume is controlled with the rotary dial on the right ear piece.) 8.
  • Page 59 Entertainment Systems 21. LANGUAGE (DVD dependent): Press to select the desired language. 22. ENTER: Press to select the highlighted menu option. 23. ILLUMINATION: Press to illuminate the remote control and backlight all of the buttons. Battery replacement Batteries are supplied with the remote control unit. Since all batteries have a limited shelf life, replace them when the unit fails to control the DVD player.
  • Page 60 Entertainment Systems Headphones Wireless headphones Your FES system is equipped with two sets of battery powered, infrared wireless headphones. Two AAA batteries are needed to operate the headphones. (Batteries are included.) Additional infrared wireless headphones may be purchased for use with the system. Also, wired headphones may be purchased and plugged in where indicated on the left and right hand sides of the...
  • Page 61 Entertainment Systems To install the batteries, remove the screw at the bottom of the cover. Then, lightly press down on top and slide the cover off. When replacing the batteries, use two new batteries (alkaline recommended) and install them with the correct orientation as indicated in the battery housing.
  • Page 62 Entertainment Systems Wired headphones Do not leave children unattended in the vehicle and do not let children operate the system while unsupervised. If wired headphones or auxiliary systems are used, children may become entangled in the cords and seriously injure themselves. You may purchase wired headphones for your FES (Family Entertainment System).
  • Page 63 Operation with an aftermarket audio system (Headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the Family Entertainment System will work in a state referred to as “Headphone Only Mode”.
  • Page 64 Entertainment Systems While operating in Headphone Only Mode, the system will have limited functionality. • The system will only output audio to the headphones. It will not be capable of providing audio to the speakers. • The available sources in FES Headphone Only Mode are DVD-DISC and DVD-AUX, regardless of headphone channel (A or B).
  • Page 65 Entertainment Systems Aspect ratio Select ASPECT RATIO to select the viewing size and shape of the video displayed on the LCD screen. This is disc dependent. You can select from: WIDE, LETTER BOX or PAN SCAN. Once you have made your selection, press ENTER to confirm.
  • Page 66 Entertainment Systems Subtitles Select SUBTITLES to turn the subtitle option on or off. The system default is OFF. Once you have made your selection, press ENTER to confirm. This is disc dependent. Audio CDs To play audio CDs on your DVD system: 1.
  • Page 67 Entertainment Systems Playing MP3 discs To play an MP3 disc on your DVD system: 1. Ensure that the vehicle ignition is in the RUN or ACCESSORY position. 2. Ensure that the DVD system is ON. 3. Insert the MP3 disc into the DVD system, label side up. 4.
  • Page 68 (DVD) only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD and DVD players. Irregular shaped CDs or DVDs, CDs or DVDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the FES DVD system.
  • Page 69 Entertainment Systems Playing a DVD 1. Ensure that the vehicle ignition is in the RUN or ACCESSORY position. 2. Ensure that the navigation system is on. 3. Insert a DVD label-side up into the system. 4. Use the DVD bezel controls to: Press to play or pause a DVD.
  • Page 70 Entertainment Systems Frame by frame 1. With a DVD playing, press pause. 2. Press the right cursor button. The DVD will advance one frame. Each press of the right cursor button will advance the DVD video by one frame. Headphone/auxiliary jacks There are wired headphones (not included) and auxiliary jacks on the left and right side of your DVD system.
  • Page 71 Entertainment Systems Audio displays Your DVD system interacts closely with the front audio system. Status messages will appear in the radio display showing the DVD status. Some possible radio display messages: • SINGLE PLAY or DUAL PLAY • DVD LOAD •...
  • Page 72 Entertainment Systems When the DVD system is ON, you can then press the memory preset controls 2 and 4 simultaneously to toggle between Single Play and Dual Play. In Single Play mode, all speakers listen to the same media. In Dual Play mode, rear seat passengers can use the infrared wireless, or wired (not included) headphones to listen to a different playing media than the front seat passengers.
  • Page 73 Safety information Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 74 Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln-Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 75 Compatibility with aftermarket audio systems (headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the FES will work in a state referred to as “Headphone Only Mode.”...

  • Page 76: Navigation System

    Entertainment Systems • When a disc is inserted into the FES while in Headphone Only Mode, both headphone channels (A and B) will be connected to FES-DISC. NAVIGATION SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Navigation System. Refer to the Navigation supplement for further information.

  • Page 77: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.
  • Page 78 Climate Controls • Remove any snow, ice or leaves from the air intake area at the base of the windshield. • To improve the A/C cool down when the vehicle interior is significantly warmer than the outside temperature, drive with the windows slightly open for 2–3 minutes after start up or until the vehicle has been “aired out.”...

  • Page 79: Automatic Temperature Control

    Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) SYSTEM (IF EQUIPPED) 16 17 DUAL AUTO 1. A/C control: Manually turns A/C on or off. 2. Recirculation control: Cools the vehicle more quickly by recirculating the cabin air instead of using outside air and helps prevent unpleasant outside odors or fumes from entering the vehicle.
  • Page 80 Climate Controls : Distributes outside air through the windshield defroster vents. : Distributes outside air through the windshield defroster vents and floor vents. Note: Some airflow will come out of the small vents near the side windows. : Distributes air through the floor vents. Note: Some airflow will come out of the small vents near the side windows.
  • Page 81 Climate Controls 17. Temperature conversion: Press to toggle between Fahrenheit and Celsius temperature on the DATC display only. The set point temperatures in Celsius will be displayed in half-degree increments. Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position.

  • Page 82: Auxiliary Passenger Climate Control

    Climate Controls Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. AUXILIARY SYSTEM (IF EQUIPPED) Your vehicle may be equipped with an auxiliary climate system. These auxiliary controls, located in the overhead console, allow the front passengers to control airflow direction, temperature and fan level of the rear compartment to quickly heat or cool the entire vehicle.

  • Page 83: Rear Window Defroster

    Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the 3 (ON) position to operate the rear window defroster.
  • Page 84 Climate Controls Note: Pushing the heated windshield button to activate the system will increase engine idle speed when the engine is warm and is already at or near its warmed up idle rpm. No increase in engine rpm will be noticed if the engine is cold and running at higher rpms associated with cold starts.

  • Page 85: Lights

    Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp Control The autolamp Control sets the headlamps to turn on and off automatically. The autolamp control, located on the headlamp control, may be set to: •...
  • Page 86 Lights Daytime running lamps (DRL) (if equipped) To activate DRL: • the ignition must be in the ON position and • the headlamp control is in the position • the transmission is not in park. Always remember to turn on your headlamps at dusk or during inclement weather.
  • Page 87 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel when exterior lights are on. • Rotate the thumbwheel from left to right to brighten the instrument panel. • Rotate the thumbwheel from right to left to dim the instrument panel.
  • Page 88 Lights • (1) Eight feet • (2) Center height of lamp to ground • (3) Twenty-five feet • (4) Horizontal reference line 2. The center of the headlamp has a 3.0 mm circle on the lens. Measure the height from the center of your headlamp to the ground (2) and mark an 8 foot (2.4 meter) long horizontal line on the plain surface (1) at this height (masking tape...
  • Page 89 Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Dome/reading lamps The dome lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated up until the courtesy lamps come on.
  • Page 90 Lights Cargo/reading lamps The dome portion of the lamp or the center light can be turned on when the panel dimmer control is rotated fully up or when a door is opened. The rear dome lamp can be turned ON or OFF by sliding the control. BULB REPLACEMENT Headlamp Condensation The headlamps are vented to equalize pressure.
  • Page 91 Lights Function Number of bulbs Trade number Side mounted turn WY5W (amber) signal Front sidemarker Rear sidemarker Fog lamp 9145 Cargo lamp 211-2 Interior overhead lamp 912 (906) Front door courtesy lamp Map lamps 168 (T10) Ashtray lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your authorized dealer.
  • Page 92 Lights 3. Disconnect the electrical connector. 4. Remove the old bulb by turning counterclockwise and pull it out. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass.
  • Page 93 Lights 4. Carefully pull the old bulb out of the lamp assembly. Reverse steps to reinstall bulb(s). Replacing side-mounted turn signal bulbs 1. Turn the headlamp switch to off. 2. Carefully pry the lamp assembly away from the fender. 3. Rotate the bulb socket counterclockwise to remove it from the lamp assembly.
  • Page 94 Lights Replacing tail/brake/turn/backup lamp bulbs 1. Turn the headlamp switch to OFF and open the liftgate. 2. Remove the two bolts from the lamp assembly. 3. Remove the lamp assembly. 4. Rotate the bulb socket counterclockwise and remove it from the lamp assembly. 5.
  • Page 95 Lights Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the OFF position. 2. Remove the lamp assembly by depressing the small tab and rocking the lamp assembly out. 3. Remove the bulb socket from the lamp assembly by turning counterclockwise and pull the bulb straight out.

  • Page 96: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...

  • Page 97: Steering Wheel Adjustment

    Driver Controls OFF — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position. From either position, the control will automatically return to the INT 2 or OFF position. TILT STEERING COLUMN Pull the lever down and release, to unlock the steering column tilt lock.
  • Page 98 Driver Controls Slide on rod feature Rotate the visor towards the side window and extend it rearward for additional sunlight coverage. Note: To stow the visor back into the headliner, visor must be retracted before moving it back towards the windshield. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package.
  • Page 99 Driver Controls Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: • Place the VELCRO hook onto the side of the aftermarket transmitter opposite of the button. •...
  • Page 100 Driver Controls Use only soft cups in the cupholder. Hard objects can injure you in a collision. Rear center console features (if equipped) The rear center console incorporates the following features: • Utility compartment • Cupholders • Flip forward armrest to provide a flat load floor AUXILIARY POWER POINTS (12VDC) Power outlets are designed for accessory plugs only.

  • Page 101: Power Windows

    Driver Controls fuse may have blown. Refer to Fuses and relays in the Roadside Emergencies chapter for information on checking and replacing fuses. To have full capacity usage of your power point, the engine is required to be running (in a safe manner) to avoid unintentional discharge of the battery.
  • Page 102 Driver Controls One touch down (AUTO) Allows the driver’s window to open fully without holding the control down. Push the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation.

  • Page 103: Mirrors

    Driver Controls Without voice activated Navigation System or SYNC With voice activated Navigation System or SYNC The mirror will automatically return to the normal state whenever the vehicle is placed in R (Reverse) to ensure a bright clear view when backing up.
  • Page 104 Driver Controls Fold-away mirrors Fold the side mirrors in carefully when driving through a narrow space, like an automatic car wash. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.

  • Page 105: Speed Control

    Driver Controls SPEED CONTROL With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved. Setting speed control The controls for using your speed control are located on the steering...
  • Page 106 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are two ways to set a higher speed: •...
  • Page 107 STEERING WHEEL CONTROLS Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 108 Driver Controls In AM, FM1, or FM2 mode: • Press SEEK select preset stations within the selected radio band or press and hold to select the next/previous radio frequency. In Satellite radio mode (if equipped): • Press SEEK advance through preset channels. In CD or SYNC USB mode (if equipped): •...
  • Page 109 Driver Controls Navigation system hands free control features (if equipped) Press and hold VOICE briefly until the voice icon appears on the Navigation display to use the voice command feature. Press VOICE to complete a voice command. For further information on the Navigation system, refer to the Navigation supplement.

  • Page 110: Moon Roof

    Driver Controls MOON ROOF (IF EQUIPPED) You can move the glass panel of the moon roof back to open or tilt up (from the closed position) to ventilate the vehicle. Do not let children play with the moon roof or leave children unattended in the vehicle.
  • Page 111 Driver Controls To vent: • To tilt the moon roof into the vent position (when the glass panel is closed), press and hold the front portion of the control. • To close the moon roof from the vent position, press and hold the rear portion of the control until the glass panel stops moving.
  • Page 112 Driver Controls Programming Do not program HomeLink with the vehicle parked in the garage. Note: Some vehicles may require the ignition switch to be turned to the second (or “ACC”) position for programming and/or operation of the HomeLink . It is also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal.
  • Page 113 Driver Controls 5. Firmly press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate Step 6. 6. Return to the vehicle and firmly press, hold for two seconds and release the HomeLink button.
  • Page 114 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).

  • Page 115: Message Center

    Driver Controls MESSAGE CENTER With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status. The system will also notify you of potential vehicle problems with a display of system warnings followed by an indicator chime.
  • Page 116 Driver Controls Info menu The Info menu items are shown on the top two lines of the message center. Press the INFO control to display the following: • Trip odometer (Trip A and Trip • Distance to Empty • Average Fuel Economy •...
  • Page 117 Driver Controls Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel economy in miles/gallon or liters/km. If you calculate your average fuel economy by dividing miles traveled by gallons of fuel used (liters of fuel used by 100 kilometers traveled), your figure may be different than displayed for the following reasons:...
  • Page 118 Driver Controls Fuel Used Selecting this function from the INFO menu. “FUEL USED XXX.X GAL” will display the fuel used since last reset. The information displayed will be in gallons or liters, depending on English/Metric mode state. Trip elapsed drive time Select this function from the INFO menu to display a timer.
  • Page 119 Driver Controls • Easy Entry/Exit Seat (if equipped) • Park Aid (if equipped) • Compass Zone (if equipped) • Compass Calibration (if equipped) • Oil Life Reset and Start Value AWD lock (4.6 L engine vehicles only) Select this function from the SETUP MENU to display the AWD locked function.
  • Page 120 Driver Controls 5. EXTERIOR LAMP 6. BRAKE FLUID LEVEL 7. PARK BRAKE 8. FUEL LEVEL AND DISTANCE TO EMPTY Units (English/Metric) 1. Select this function from the SETUP MENU for the current units to be displayed. 2. Press the RESET control to change from English to Metric.
  • Page 121 Driver Controls 1. To change the delay time of the autolamp feature, select this function from the SETUP MENU. 2. Press the RESET control to select the new Autolamp delay time (in seconds) value of 0, 10, 20, 30, 60, 90, 120 or 180 and wraps back to 0.
  • Page 122 Driver Controls Running Boards (if equipped) This feature automatically deploys the side running boards for easy entry/exit from the vehicle or for cleaning. Refer to Running boards in this chapter for more information. 1. To change operation of the power running board feature, select this function from the SETUP MENU.
  • Page 123 Driver Controls Reverse Sensing System (Park Aid) (if equipped) This feature sounds a warning tone to warn the driver of obstacles near the rear bumper, and functions only when R (Reverse) gear is selected. 1. To disable/enable the reverse sensing system feature with the vehicle in P (Park), select this function from the SETUP MENU or put the vehicle in R (Reverse).
  • Page 124 Driver Controls Compass zone adjustment (if equipped) 1. Determine your magnetic zone by referring to the zone map. 2. Turn ignition to the ON position. 3. Start the engine. 7 8 9 1011 4. From SETUP MENU, select compass zone. 5.
  • Page 125 Driver Controls Compass calibration adjustment Perform compass calibration in an open area free from steel structures and high voltage lines. For optimum calibration, turn off all electrical accessories (heater/air conditioning, wipers, etc.) and make sure all vehicle doors are shut. 1.
  • Page 126 Driver Controls 2. Press and hold the RESET control for more than 2 seconds. Oil life is set to 100% and “OIL CHANGE SET TO 100%” is displayed. Note: To change oil life 100% miles value from 7,500 miles (12,070 km) or 6 months to another value, proceed to step 3.
  • Page 127 Driver Controls Warning display Status Door ajar Warning cannot be reset Fuel level low Warning returns after 10 minutes Park brake engaged Check brake system Check park aid (if equipped) Warning returns only after the ignition key is turned from OFF to ON. Brake fluid level low Check headlamp Check highbeam lamp...
  • Page 128 Driver Controls electrical loads as soon as possible. If the warning stays on or comes on when the engine is operating at normal speeds, have the electrical system checked as soon as possible. FUEL LEVEL LOW. Displayed as an early reminder of a low fuel condition.
  • Page 129 Driver Controls CHECK TURN LAMP. Displayed when the turn lamps are activated and at least one bulb is burned out. Check the lamps as soon as possible and have the burned out lamp replaced. Refer to Replacing headlamp bulbs in the Lights chapter. WASHER FLUID LEVEL LOW.
  • Page 130 Driver Controls RUNNING BOARDS (IF EQUIPPED) Deployable running boards (DRB) automatically move when the doors are opened to assist entering and exiting the vehicle. Automatic power deploy: • The running boards will extend down when the doors are opened. Automatic power stow: •...
  • Page 131 Driver Controls Note: Do not use the running boards, front and rear hinge assemblies, running board motors, or the running board under body mounts to lift the vehicle with the jack, refer to Changing tires in the Roadside Emergencies chapter. In extreme climates, excessive ice buildup may occur, causing the running boards not to deploy.
  • Page 132 Driver Controls CARGO COVER (IF EQUIPPED) Your vehicle may be equipped with a cargo area cover that covers the luggage compartment of your vehicle. To install the cover: Push both ends of the cover into the depressions (right side first) in the trim panels behind the second row seat.
  • Page 133 Driver Controls 5 passenger stowage: When the lid is open, it will stand up on its own. 1. To open, lift the release handle and the lid. 2. To close, lower the lid, lift the release handle and press down on the lid.
  • Page 134 Driver Controls LUGGAGE RACK Your vehicle is equipped with a roof rack. The maximum recommended load is 100 lb. (45 kg), evenly distributed. Use the tie down loops on the thumbwheels (if equipped) to secure the load. To adjust cross-bar position (if equipped): 1.

  • Page 135: Locks And Security

    Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your authorized dealer supplied keys, replacement keys are available through your authorized dealer.
  • Page 136 Locks and Security Deactivating/activating autolock Your vehicle comes with the autolock feature enabled. There are four methods to enable/disable this feature: • Through your authorized dealer, or • Performing the power door lock control procedure, or • Performing the keyless entry key pad (if equipped) procedure, or •...
  • Page 137 Locks and Security 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5. Release the 7 • 8. 6. Release the 3 • 4. The user should receive a horn chirp to indicate the system has been disabled or a chirp followed by a honk to indicate the system has been enabled.
  • Page 138 Locks and Security Power door unlock/lock procedure You must complete Steps 1-5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds. Note: All doors must be closed and remain closed throughout the configuration process.
  • Page 139 Locks and Security Power door lock/unlock inhibit feature (if equipped) If the key is not in the ignition, all doors are closed, and the vehicle has been locked using the remote entry transmitter, keypad (if equipped) or the power door unlock control on the door panel while a front door is open (then subsequently closed), the power door unlock control on the door panel will become disabled 20 seconds after the lock event occurred.
  • Page 140 Locks and Security CHILDPROOF DOOR LOCKS • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.

  • Page 141: Anti-Theft System

    Locks and Security The remote entry system allows you to lock or unlock all vehicle doors and liftgate, open the liftgate window without a key and activate the panic alarm. The remote entry lock/unlock feature operates in any ignition position. The liftgate glass feature operates as long as the vehicle’s speed is less than 3 mph (5 km/h).
  • Page 142 Locks and Security Switching from two step to one step door unlocking Your vehicle comes with two step unlocking enabled. Unlocking can be switched between two step and one step door unlocking by pressing and holding both the buttons simultaneously on the remote entry transmitter for approximately 4 seconds.
  • Page 143 Locks and Security Memory seats/adjustable pedals/easy entry-exit feature (if equipped) The remote entry system can also control the memory seat /adjustable pedals/easy entry-exit feature. Press to automatically move the seat and adjustable pedals to the desired memory position (the seat position corresponds to the transmitter being used).
  • Page 144 Locks and Security Replacing the battery The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE...
  • Page 145 Locks and Security transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for reprogramming. How to reprogram your remote entry transmitters You must have all remote entry transmitters (maximum of six) available before beginning this procedure. If all remote entry transmitters are not present during the programming procedure, the transmitters that are not present during programming will no longer operate the vehicle.
  • Page 146 Locks and Security Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The illuminated entry system will turn off the interior lights if: • the ignition is turned to the 2 (ACC) or 3 (ON) position, or •...
  • Page 147 Locks and Security Programming a personal entry code Up to three personal entry codes may be programmed to the vehicle. To create your own personal entry code: 1. Enter the factory set code. 2. Within five seconds press the 1 • 2 on the keypad. 3.

  • Page 148: Anti-Theft System

    Note: The SecuriLock™ passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
  • Page 149 Locks and Security • When the ignition is in the 3 (ON) position, the indicator will glow for 3 seconds to indicate normal system functionality. If a problem occurs with the SecuriLock™ system, the indicator will flash rapidly or glow steadily when the ignition is in the 3 (ON) position. If this occurs, the vehicle should be taken to an authorized dealer for service.
  • Page 150 Locks and Security Programming spare keys You can program your own coded keys to your vehicle. Tips: • A maximum of eight keys can be coded to your vehicle. • Only use SecuriLock™ keys. • You must have two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible.
  • Page 151 Locks and Security 8. Turn the ignition from the 1 (OFF/LOCK) position to the 3 (ON) position. Keep the ignition in the 3 (ON) position for at least three seconds, but not more than 10 seconds. 9. Remove the newly programmed coded key from the ignition. If the key has been successfully programmed it will start the vehicle’s engine and the theft indicator light will illuminate for three seconds and then go out.

  • Page 152: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 153 Seating and Safety Restraints Push control to lower head restraint. Adjusting the front manual seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 154 Seating and Safety Restraints Using the manual lumbar support (if equipped) For more lumbar support, turn the lumbar support control toward the front of vehicle. For less lumbar support, turn the lumbar support control toward the rear of vehicle. Adjusting the front power seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving.
  • Page 155 Seating and Safety Restraints To reduce the risk of possible serious injury: Do not hang objects off seat back or stow objects in the seatback map pocket (if equipped) when a child is in the front passenger seat. Do not place objects underneath the front passenger seat or between the seat and the center console (if equipped).
  • Page 156 Seating and Safety Restraints Press the control to recline the seatback forward or rearward. Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press one side of the control to adjust firmness.
  • Page 157 Seating and Safety Restraints A position can be recalled: • in any gearshift position if the ignition is not in the RUN position. • only in Park or Neutral if the ignition is in the RUN position. A memory seat position may be programmed at any time. The memory positions are also recalled when you press your remote entry transmitter UNLOCK control if the transmitter is programmed to a memory position or when you enter a valid personal entry code that is...
  • Page 158 Seating and Safety Restraints To operate the heated seats: • Push control to activate. • Push again to deactivate. REAR SEATS To have an unobstructed rear view, you can fold down the second and third row head restraints. Refer to the Folding down the 2nd row 60/40 seats and bucket seats and 3rd row folding seat (if equipped) sections later in this chapter.
  • Page 159 Seating and Safety Restraints 2. Locate the recline handle situated on the side of the seat cushion by the door. 3. Pull up on the handle and push the seatback forward toward the front of the vehicle. To return the seat to the upright position (seats not equipped with E-Z entry): 1.
  • Page 160 Seating and Safety Restraints To return the seat to the upright position (E-Z entry equipped seats): 1. Lift the seatback toward the rear of the vehicle. 2. Rotate the seatback until you hear a click, locking it in the upright position.
  • Page 161 Seating and Safety Restraints 2. Lift the cargo mode lever located on the back of the seatback to kneel the seat down and get a flat loading floor. Returning to the upright position from full lowered load floor position The seatback cannot be returned to the upright position until the seat is returned from the kneel down position.
  • Page 162 Seating and Safety Restraints 2. Pull the handle up again until the seat releases from the floor. 3. Push the seat upward and fold it away from the third row. Always return the seat to the fully latched position before operating the vehicle.
  • Page 163 Seating and Safety Restraints 4. Lift up on the head restraint until it locks into its original position. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
  • Page 164 Seating and Safety Restraints 3rd row folding seat (if equipped) Before folding the third row seats, fold the head restraints down by pulling on the strap located under the restraint. Pull up on the handle located behind the seatback while pushing the seatback forward and down into the seat cushion.
  • Page 165 Seating and Safety Restraints The control buttons are located on the driver-side rear quarter trim panel (accessible from the liftgate area). Push the bottom portion of the control button to lower the desired seatback. Push the top of the control button to return the seatback to its original position.

  • Page 166: Safety Restraints

    Seating and Safety Restraints Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
  • Page 167 Seating and Safety Restraints The fact that the pretensioners or airbags did not activate for both front seat occupants in a collision does not mean that something is wrong with the system. Rather, it means the Personal Safety System™ determined the accident conditions (crash severity, belt usage, etc.) were not appropriate to activate these safety devices.
  • Page 168 Seating and Safety Restraints Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
  • Page 169 Seating and Safety Restraints to the Warning lights and chimes section in the Instrument Cluster chapter. Routine maintenance of the Personal Safety System™ is not required. The Restraints Control Module (RCM) monitors its own internal circuits and the circuits for the airbag supplemental restraints, crash sensor(s), safety belt pretensioners, front safety belt buckle sensors, front passenger sensing system, and the driver seat position sensor.
  • Page 170 Seating and Safety Restraints It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
  • Page 171 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. •...
  • Page 172 Seating and Safety Restraints Automatic locking mode When to use the automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. This mode should be used any time a child safety seat, except a booster, is installed in passenger front or rear seating positions.
  • Page 173 Seating and Safety Restraints • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Unbuckle the combination lap and shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive mode.
  • Page 174 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments at the front outboard seating positions. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, squeeze and hold the buttons on the side and slide the height adjuster up or down.
  • Page 175 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. 2. Slide the guide up or down along the webbing so that the belt is centered on the occupant’s shoulder. Position the safety belt comfort guide so that the belt rests across the middle of your shoulder.
  • Page 176 Seating and Safety Restraints Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the...
  • Page 177 Seating and Safety Restraints When the Belt-Minder feature is activated, the safety belt warning light illuminates and the warning chime sounds for 6 seconds every 30 seconds, repeating for approximately 5 minutes or until the safety belts are buckled. The Belt-Minder feature uses two different warning chimes. During the first minute of activation, the warning chime will sound once every second.
  • Page 178 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare events” 36700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
  • Page 179 Seating and Safety Restraints Reasons given... Consider... “I have an airbag” Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE.
  • Page 180 Seating and Safety Restraints Before following the procedure, make sure that: • The parking brake is set • The gearshift is in P (Park) (automatic transmission) • The ignition switch is in the OFF position • The driver and front passenger safety belts are unbuckled While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident.

  • Page 181: Airbags

    (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
  • Page 182 Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
  • Page 183 Modifications to the front end of the vehicle, including frame, bumper, front end body structure and non-Ford tow hooks may effect the performance of the airbag sensors increasing the risk of injury. Do not modify the front end of the vehicle with anything other than authorized Ford accessories for your vehicle.
  • Page 184 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
  • Page 185 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 186 Seating and Safety Restraints The front passenger sensing system will disable (will not inflate) the front passenger’s frontal airbag if: • the front passenger seat is unoccupied, or has small/medium objects in the front seat. • the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer’s instructions.
  • Page 187 Seating and Safety Restraints • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator will be unlit and stay unlit. If a person of adult size is sitting in the front passenger’s seat, but the passenger airbag off or pass airbag off indicator lamp is lit, it is possible that the person isn’t sitting properly in the seat.
  • Page 188 Seating and Safety Restraints The front passenger sensing system may detect small or medium objects placed on the seat cushion. For most objects that are in the front passenger seat, the passenger airbag will be disabled. Even though the passenger airbag is disabled, the pass airbag off lamp may or may not be illuminated according to the table below.
  • Page 189 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance chapter of this Owner’s Guide.
  • Page 190 Seating and Safety Restraints Any alteration/modification to the front passenger seat may affect the performance of the front passenger sensing system. Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system.
  • Page 191 Seating and Safety Restraints Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. See your authorized dealer. All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
  • Page 192 Seating and Safety Restraints The airbag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
  • Page 193 Seating and Safety Restraints Do not attempt to service, repair, or modify the Safety Canopy™ system, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing a Safety Canopy™. See your authorized dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an airbag SRS and Safety Canopy™...
  • Page 194 Seating and Safety Restraints • Roll over sensor in the restraints control module (RCM). The Safety Canopy™ system, in combination with safety belts, can help reduce the risk of severe injuries in the event of a significant side impact collision or rollover event. Children 12 years old and under should always be properly restrained in the second or third row seats (if equipped).
  • Page 195 Seating and Safety Restraints If the Safety Canopy™ system has deployed, the Safety Canopy™ will not function again. The Safety Canopy™ system (including the A, B and C pillar trim) must be inspected and serviced by an authorized dealer. If the Safety Canopy™...

  • Page 196: Child Restraints

    Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Airbag supplemental restraint system (SRS) in this chapter for special instructions about using airbags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.
  • Page 197 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 198 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
  • Page 199 Seating and Safety Restraints If needed, when installing some high back child restraints, the head restraints of the second row seating positions can be removed. Insert a thin pointed object, such as a paper clip or pushpin, into the hole of each head restraint guide and while lifting up remove the head restraint.
  • Page 200 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 201 Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
  • Page 202 Seating and Safety Restraints Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps in this chapter.
  • Page 203 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
  • Page 204 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
  • Page 205 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
  • Page 206 Seating and Safety Restraints Do not tie down cargo with anchors if the anchors are in use as child tethers. 1. Position the child safety seat on the rear seat cushion. 2. Route the tether strap under the head restraint and between the head restraint posts.
  • Page 207 Seating and Safety Restraints 4. Clip the tether strap to the anchor. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Install the child safety seat tightly using the LATCH anchors or safety belts.
  • Page 208 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the following seating positions. In addition, six passenger and seven passenger LATCH anchor positions are marked with the child seat symbol. • 5 passenger vehicle • 6 passenger vehicle •...
  • Page 209 Seating and Safety Restraints The lower anchors for child seat installation are located at the rear section of the second row seat between the cushion and seat back. The LATCH anchors are below the locator symbols on the seat back on 6 and 7 passenger vehicles.
  • Page 210 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.

  • Page 211: Tires, Wheels And Loading

    Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
  • Page 212 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.

  • Page 213: Tire Information

    Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 214 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 215 Tires, Wheels and Loading TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them. Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry.

  • Page 216: Tire Inflation

    (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
  • Page 217 Tires, Wheels and Loading on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label. When weather temperature changes occur, tire inflation pressures also change.
  • Page 218 Tires, Wheels and Loading TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check for holes or cuts that may permit air leakage from the tire and make necessary repairs.
  • Page 219 Tires, Wheels and Loading Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after six years regardless of tread wear.
  • Page 220 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
  • Page 221 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
  • Page 222 Tires, Wheels and Loading vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have an authorized dealer check the wheel alignment periodically. Wheel misalignment in the front or the rear can cause uneven and rapid treadwear of your tires and should be corrected by an authorized dealer.
  • Page 223 Tires, Wheels and Loading Note: Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels. If you have a dissimilar spare tire/wheel it is intended for temporary use only and should not be used in a tire rotation.
  • Page 224 Tires, Wheels and Loading 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6. 95: Indicates the tire’s load index. It is an index that relates to how much weight a tire can carry.
  • Page 225 Tires, Wheels and Loading numbers represent the week and year the tire was built. For example, the numbers 317 mean the 31st week of 1997. After 2000 the numbers go to four digits. For example, 2501 means the 25th week of 2001. The numbers in between are identification codes used for traceability.
  • Page 226 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
  • Page 227 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.

  • Page 228: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 229 Tires, Wheels and Loading The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 230 Tires, Wheels and Loading Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The Low Tire Pressure Warning Lamp will turn ON if the tire pressure is significantly low.
  • Page 231 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Solid Warning Light Tire(s) 1. Check your tire pressure to under-inflated ensure tires are properly inflated; refer to Inflating your tires in this chapter. 2. After inflating your tires to the manufacturer’s recommended inflation pressure as shown on the Tire...
  • Page 232 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Flashing Warning Spare tire in use Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.

  • Page 233: Vehicle Loading

    The tires on your vehicle have all-weather treads to provide traction in rain and snow. However, in some climates, using snow tires or traction devices may be necessary. Ford offers tire cables as a Ford approved accessory and recommends use of these or SAE class “S” tire cables. See your authorized dealer for more information on tire cables for your vehicle.
  • Page 234 Tires, Wheels and Loading Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. Payload – is the combined weight of cargo and passengers that the vehicle is carrying.
  • Page 235 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 236 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
  • Page 237 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 238 Tires, Wheels and Loading Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lb.” on your vehicle’s placard. 2.
  • Page 239 Tires, Wheels and Loading transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.

  • Page 240: Trailer Towing

    Tires, Wheels and Loading TRAILER TOWING Trailer towing with your vehicle may require the use of a trailer tow option package. Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing.
  • Page 241 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weight Engine Rear axle ratio Maximum Trailer weight GCWR-lb. (kg) range-lb. (kg) (0-Maximum) 4.0L SOHC Class 3.55 8500 (3856) 0–3500 (0–1588) II towing 4.6L* Class II 3.55 8500 (3856) 0–3500 (0–1588) towing 4.0L SOHC Class 3.73...
  • Page 242 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weight Engine Rear axle ratio Maximum Trailer weight GCWR-lb. (kg) range-lb. (kg) (0-Maximum) 4.0L SOHC Class 3.55 8500 (3856) 0–3500 (0–1588) II towing 4.6L* Class II 3.55 8500 (3856) 0–3500 (0–1588) towing 4.0L SOHC Class 3.73...
  • Page 243 Tires, Wheels and Loading Safety chains Always connect the trailer’s safety chains to the frame or hook retainers of the vehicle hitch. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. If you use a rental trailer, follow the instructions that the rental agency gives to you.
  • Page 244 Tires, Wheels and Loading Driving while you tow When towing a trailer: • To ensure proper “break-in” of powertrain components, do not trailer tow during the first 1,000 miles (1600 km) of a new vehicle. • To ensure proper “break-in” of powertrain components during the first 500 miles (800 km) of trailer towing, drive no faster than 70 mph (112 km/h) with no full throttle starts.

  • Page 245: Recreational Towing

    Tires, Wheels and Loading • If you will be towing a trailer frequently in hot weather, hilly conditions, at GCWR, or any combination of these factors, consider refilling your rear axle with synthetic gear lube if not already so equipped. Refer to the Maintenance and Specifications chapter for the lubricant specification.
  • Page 246 • Maximum distance is 50 miles (80 km). If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician at an authorized dealer.

  • Page 247: Driving

    Driving STARTING Positions of the ignition 1. OFF/LOCK, shuts off the engine and all accessories/locks the steering wheel, gearshift lever and allows key removal. 2. ACC, allows the electrical accessories such as the radio to operate while the engine is not running.
  • Page 248 Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked.
  • Page 249 Driving • Make sure the gearshift is in P (Park). • Turn the key to 3 (ON) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
  • Page 250 Driving Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. This condition may occur when: •...
  • Page 251 Driving ENGINE BLOCK HEATER (IF EQUIPPED) An engine block heater warms the engine coolant which aids in starting and allows the heater/defroster system to respond quickly. If your vehicle is equipped with this system, your equipment includes a heater element which is installed in your engine block and a wire harness which allows the user to connect the system to a grounded 120 volt a/c electrical source.

  • Page 252: Brakes

    Driving • Be sure that areas where the vehicle is parked are clean and clear of all combustibles such as petroleum products, dust, rags, paper and similar items. • Be sure that the engine block heater, heater cord and extension cord are solidly connected.
  • Page 253 Driving Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking. Noise from the ABS pump motor and brake pedal pulsation may be observed during ABS braking and the brake pedal may suddenly travel a little farther as soon as ABS braking is done and normal brake operation resumes.
  • Page 254 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released.

  • Page 255: Traction Control™/Advancetrac

    Driving ADVANCETRAC WITH ROLL STABILITY CONTROL™ (RSC) STABILITY ENHANCEMENT SYSTEM The AdvanceTrac with RSC system provides stability enhancement features such as Roll Stability Control™ (RSC), Electronic Stability Control (ESC) and Traction Control (TCS) for certain driving situations. The system includes an AdvanceTrac with RSC on/off button, and a “sliding car”...
  • Page 256 Driving If the vehicle is stuck in snow or mud or when driving in deep sand, switching off the AdvanceTrac with RSC system may be beneficial so the wheels are allowed to spin. If your vehicle seems to lose engine power while driving in deep sand or very deep snow, switching off the AdvanceTrac with RSC stability enhancement feature will restore full engine power and will enhance momentum through the obstacle.
  • Page 257 Driving Driving conditions that may activate AdvanceTrac with RSC include: • Emergency lane-change • Taking a turn too fast • Quick maneuvering to avoid an accident, pedestrian or obstacle AdvanceTrac with RSC button and functionality The AdvanceTrac with RSC system automatically turns on each time the engine is started, even if it was turned off when the engine was last shut down.
  • Page 258 Driving All these conditions are normal during AdvanceTrac with RSC operation. Refer to the following table. AdvanceTrac with RSC Features “Sliding Engine Brake Button car” Traction Traction functions Control Control icon Illuminated Default at during bulb Enabled Enabled Enabled Enabled start-up check Disabled...
  • Page 259 Driving STEERING To help prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than a few seconds when the engine is running • Do not operate the vehicle with a low power steering pump fluid level (below the MIN mark on the reservoir).

  • Page 260: Transmission Operation

    Driving Vehicles with a higher center of gravity such as utility vehicles and trucks handle differently than vehicles with a lower center of gravity. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
  • Page 261 Driving 5. Return the cover plug to the console access hole. Start the vehicle. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly.
  • Page 262 Driving Driving with a 5–speed automatic transmission (if equipped) This vehicle is equipped with an Adaptive Transmission Control Strategy. This Adaptive Transmission Control Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
  • Page 263 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Start the engine • Depress the brake pedal • Press the gearshift release button on the front of the lever and move the gearshift lever into the desired gear To put your vehicle in P (Park):...
  • Page 264 Driving D (Drive) without Overdrive Overdrive can be deactivated by pressing the transmission control switch on the side of the gearshift lever. • This position allows for all forward gears (1-4) except overdrive. • Provides engine braking. • Use when driving conditions cause excessive shifting from O/D to other gears.
  • Page 265 Driving Forced downshifts • Allowed in D (Overdrive) or Drive. • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. Driving with a 6–speed automatic transmission (if equipped) This vehicle is equipped with an Adaptive Transmission Control Strategy. This Adaptive Transmission Control Strategy offers the optimal transmission operation and shift quality.
  • Page 266 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Depress the brake pedal • Start the engine • Press the gearshift lever release button (on the front of the lever) and shift into the desired gear To put your vehicle in P (Park): •...
  • Page 267 Driving D (Drive) without Overdrive Overdrive can be deactivated by pressing the transmission control switch on the side of the shift lever. • This position allows for all forward gears (1-4) except overdrive. • Provides engine braking. • Use when driving conditions cause excessive shifting from O/D to other gears.
  • Page 268 Driving • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds. Forced downshifts • Allowed in D (Drive) only. • Depress the accelerator to the floor. •...
  • Page 269 Driving Certain add-on devices such as large trailer hitches, bike or surfboard racks and any device that may block the normal detection zone of the RSS system may create false beeps. The RSS detects obstacles up to six feet (two meters) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for...
  • Page 270 Driving ALL WHEEL DRIVE (AWD) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with an All Wheel Drive (AWD) transfer case. With the AWD option, there is no need to shift between two-wheel drive and four-wheel drive. For the lubricant specification and refill capacity of the AWD transfer case refer to Maintenance and Specifications chapter.
  • Page 271 Driving Autolock operation (4.6L engine vehicles only) If the AWD system begins to overheat, the system will place itself in the Autolock mode: • the 4X4 indicator light will illuminate in the instrument cluster and AWD DISABLED <LOCKED> will be displayed in the message center. •...
  • Page 272 Driving If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface.
  • Page 273 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander.
  • Page 274 Driving Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels.
  • Page 275 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
  • Page 276 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
  • Page 277 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).

  • Page 278: Roadside Emergencies

    Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
  • Page 279 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.

  • Page 280: Hazard Flasher Switch

    Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
  • Page 281 Roadside Emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.

  • Page 282: Fuses And Relays

    Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
  • Page 283 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below the instrument panel on the driver’s side. To remove a fuse use the fuse puller tool provided on the fuse panel box. The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse...
  • Page 284 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Moonroof, Door lock switch illumination, Rearview mirror with microphone Liftglass release motor, Door unlock/lock Trailer stop/turn Ignition switch power, PATS, Cluster 6R TCM/PCM (Ignition RUN/START), Fuel pump relay Front wiper RUN/ACC relay in Radio start Rear wiper motor RUN/ACC,...
  • Page 285 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Brake switch, Bi-color stop lamps, CHMSL, All turn lamps Interior lamps, Puddle lamps, Battery saver, Instrument illumination, Homelink Cluster, Theft LED Trailer tow park lamps License plate/rear park lamp, Front park lamps, Manual climate Tri-color stop lamps Manual/DEATC...
  • Page 286 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
  • Page 287 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 50A** BATT 2 (SJB) 50A** BATT 3 (SJB) 50A** BATT 1 (SJB) 30A** Fuel pump, Injectors 30A** Third row seat (left) 40A** ABS pump 40A** Powertrain Control Module...
  • Page 288 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 30A** Memory seats (DSM) 40A** Non-memory seats 40A** Rear defrost, Heated mirrors 40A** Front blower motor 30A** Trailer electronic brakes 30A** Auxiliary blower motor 30A** Running boards 30A** Front wiper motor 20A* Rear power point 20A*...
  • Page 289 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 15A* Fan clutch, PCV valve (4.0L engine only), AC clutch relay, GCC fan 15A* SDARS, DVD, SYNC 15A* Redundant brake switch, EVMV, MAFS, HEGO, EVR, VCT1 (4.6L engine only), VCT2 (4.6L engine only), CMCV (4.6L engine only), 15A* Coil on plug (4.6L engine only),...

  • Page 290: Changing Tires

    Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 291 Roadside Emergencies A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels and can be one of three types: 1. T-type mini-spare: This spare tire begins with the letter “T” for tire size and may have “Temporary Use Only”...
  • Page 292 Roadside Emergencies The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability •...
  • Page 293 Roadside Emergencies Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Tool Location Spare tire Under the vehicle, just in front of the rear bumper. The spare tire winch drive nut is located at the rear center of the cargo area under a lid.
  • Page 294 Roadside Emergencies Removing the spare tire Do not use an impact wrench on the winch drive nut. This will damage the spare tire winch. 1. Open the cover from the carpeting on cargo floor to expose the winch drive nut. 2.
  • Page 295 Roadside Emergencies 3. Turn the wrench counterclockwise until the tire is lowered to the ground and the cable has slack. When turning the wrench, make sure that it does not scuff the kick plate. 4. Slide the tire rearward, lift one side and remove the retainer from the spare tire.
  • Page 296 Roadside Emergencies 1. Block the wheel that is diagonally opposite of the flat tire using the wheel chock provided with your vehicle. 2. Use the tip of the lug wrench to remove the beauty cap by twisting the tip under the cap. On 5–passenger vehicles, the carpeted floor lid can be used as a kneeling pad.
  • Page 297 Roadside Emergencies 5. Position the jack according to the illustrated guides and turn the jack handle clockwise until the tire is a maximum of 1 inch (25 mm) off the ground. Note: Do not use the running boards, front and rear hinge assemblies, running board motors, or the running board underbody mounts to lift the vehicle with the...
  • Page 298 Roadside Emergencies 9. Remove the jack and fully tighten the lug nuts in the order shown. Refer to Wheel lug nut torque specifications later in this chapter for the proper lug nut torque specification. Stowing the flat/spare tire Note: Failure to follow spare tire stowage instructions may result in failure of cable or loss of spare tire.

  • Page 299: Lug Nut Torque

    20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.

  • Page 300: Jump Starting

    Roadside Emergencies Note: Inspect the wheel pilot hole prior to installation. If there is visible corrosion in wheel pilot hole, remove loose particles by wiping with clean rag and apply grease. Apply grease only to the wheel pilot hole surface by smearing a “dime” (1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger.
  • Page 301 Roadside Emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect from any electrical surges.
  • Page 302 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to the ground stud located toward the front of the vehicle (forward of the battery) on the radiator support.
  • Page 303 Roadside Emergencies Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts.
  • Page 304 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 305: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If the vehicle’s battery is discharged, refer to Automatic transmission operation in the Driving chapter for directions on how to move the gearshift lever out of the P (Park) position, for proper towing.
  • Page 306 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.

  • Page 307: Customer Assistance

    Relationship Center at 1-800-521-4140. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 308 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 309 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
  • Page 310 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
  • Page 311 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 312 Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.

  • Page 313: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. 2008 Mountaineer (mnt)

  • Page 314: Reporting Safety Defects (Canada Only)

    Customer Assistance To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153); go to http://www.safercar.gov; or write to: Administrator NHTSA 400 Seventh Street, SW Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from http://www.safercar.gov.

  • Page 315: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 316 Cleaning • After polishing chrome bumpers, apply a coating of Motorcraft Premium Liquid Wax (ZC-53-A), available from your authorized dealer, or an equivalent quality product to help protect from environmental effects. WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
  • Page 317 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high pressure fluid could penetrate the sealed parts and cause damage. •...
  • Page 318 Cleaning 4.6L V8 ENGINE PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
  • Page 319 Cleaning • The wiper blades can be cleaned with isopropyl (rubbing) alcohol or Motorcraft Premium Windshield Washer Concentrate (ZC-32-A), available from your authorized dealer. This washer fluid contains special solution in addition to alcohol which helps to remove the hot wax deposited on the wiper blade and windshield from automated car wash facilities.
  • Page 320 Cleaning If a staining liquid like coffee/juice has been spilled on the instrument panel or on interior trim surfaces, clean as follows: 1. Wipe up spilled liquid using a clean, white, cotton cloth. 2. Apply Motorcraft Deluxe Leather and Vinyl Cleaner (ZC-11-A) [In Canada use Motorcraft Multi-Purpose Cleaner (CXC-101)] to the wiped area and spread around evenly.
  • Page 321 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
  • Page 322 Cleaning Motorcraft Dusting Cloth Mitt (ZC-47) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S. only) (ZC-20) Motorcraft One Step Wash and Wax Concentrate (ZC-6-A) Motorcraft Premium Glass Cleaner (Canada only) (CXC-100) Motorcraft Premium Liquid Wax (ZC-53-A) Motorcraft Premium Windshield Washer Concentrate (ZC-32-A) Motorcraft Professional Strength Carpet &...

  • Page 323: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS • Use the scheduled maintenance information to track routine service. • Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. • Your authorized dealer can provide parts and service. PRECAUTIONS WHEN SERVICING YOUR VEHICLE •...
  • Page 324 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.

  • Page 325: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Engine oil filler cap 2. Engine oil dipstick (out of view) 3. Brake fluid reservoir 4. Power distribution box 5. Battery 6. Power steering fluid reservoir 7.
  • Page 326 Maintenance and Specifications 4.6L V8 engine 1. Air filter assembly 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Power distribution box 6. Battery 7. Power steering fluid reservoir 8. Radiator cap 9. Engine coolant reservoir 10.
  • Page 327 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
  • Page 328 Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.

  • Page 329: Engine Oil

    Maintenance and Specifications 4. To attach the new wiper to the wiper arm, align the cross pin and keyway (denoted with the arrows) and firmly press the wiper blade into the wiper arm until an audible snap is heard. ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil.
  • Page 330 Maintenance and Specifications • 4.6L V8 engine 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is between the lower and upper holes, the oil level is acceptable, DO NOT ADD OIL. •...
  • Page 331 Maintenance and Specifications • 4.6L V8 engine • Oil levels above the upper hole may cause engine damage. Some oil must be removed from the engine by an authorized dealer. 7. Put the dipstick back in and ensure it is fully seated. Adding engine oil 1.
  • Page 332 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
  • Page 333 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.

  • Page 334: Battery

    Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
  • Page 335 Maintenance and Specifications Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.

  • Page 336: Engine Coolant

    Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information.
  • Page 337 Maintenance and Specifications • 4.0L V6 engine • 4.6L V8 engine • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application). • Refer to scheduled maintenance information for service interval schedules.
  • Page 338 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine...
  • Page 339 Maintenance and Specifications For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool. Add the proper mixture of coolant and water to the “FULL COLD” level. For all other vehicles which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant.
  • Page 340 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
  • Page 341 Maintenance and Specifications • Decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage. • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive.
  • Page 342 Maintenance and Specifications • Engine Oil Overheat Mode: The (Engine coolant temperature) indicator will be on. The instrument cluster has no separate oil temperature indicator. Along with the (Engine coolant temperature) indicator, the engine coolant temperature gauge will read in the Hot (H) area. Oil overheat can be triggered in severe driving conditions, such as towing heavy loads over mountainous terrain in extreme hot temperatures.

  • Page 343: Fuel Information

    Maintenance and Specifications WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 344 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
  • Page 345 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt)
  • Page 346 Maintenance and Specifications The fuel system may be under pressure. Remove fuel filler cap slowly. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in personal injury.
  • Page 347 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
  • Page 348 Maintenance and Specifications ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy.
  • Page 349 Maintenance and Specifications Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
  • Page 350 Maintenance and Specifications • You may want to turn off the speed control in hilly terrain if unnecessary shifting between the top gears occurs. Unnecessary shifting of this type could result in reduced fuel economy. • Warming up a vehicle on cold mornings is not required and may reduce fuel economy.
  • Page 351 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
  • Page 352 Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
  • Page 353 Maintenance and Specifications If the Service engine soon indicator remains on, have your vehicle serviced at the first available opportunity. Although some malfunctions detected by the OBD-II may not have symptoms that are apparent, continued driving with the Service engine soon indicator on can result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and lead to more costly repairs.
  • Page 354 Maintenance and Specifications POWER STEERING FLUID Check the power steering fluid. Refer to scheduled maintenance information for the service interval schedules. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
  • Page 355 Use only fluid that meets Ford specifications. Refer to the Maintenance product specifications and capacities section in this chapter. 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt)

  • Page 356: Air Filter(S)

    Maintenance and Specifications DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Turn off the power running boards, if equipped, before working under the vehicle, jacking or placing any object under the vehicle. Never place your hand between the extended running board and the vehicle. A moving running board may cause injury. If the original universal joints are replaced with universal joints equipped with grease fittings, lubrication will be necessary.
  • Page 357 Maintenance and Specifications Changing the air filter element • 4.0L Engine • 4.6L Engine 1. Release the clamps that secure the air filter housing cover. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the air filter housing. 4.

  • Page 358: Part Numbers

    PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.

  • Page 359: Maintenance Product Specifications And Capacities

    Maintenance and Specifications 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)
  • Page 360 Maintenance and Specifications 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)
  • Page 361 Maintenance and Specifications 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)
  • Page 362 Maintenance and Specifications 2008 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

  • Page 363: Engine Data

    Maintenance and Specifications ENGINE DATA Engine 4.0L SOHC V6 4.6L 3V V8 engine engine Cubic inches Required fuel 87 octane 87 octane Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8 Ignition system EDIS Coil on Plug Spark plug gap 0.052–0.056 inch 0.040–0.050 inch (1.32–1.42 mm) (1.02–1.27 mm) Compression ratio 9.7:1...
  • Page 364 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
  • Page 365 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.

  • Page 366: Accessories

    GENUINE MERCURY ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Mercury Accessories are available for your vehicle through your local Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 367 Accessories Roof rail cross bars Trailer hitch drawbars, wiring harnesses and accessories TripTunes™ Advanced portable audio connection Peace of mind Mobile-Ease™ hands-free communication system Remote start Vehicle security systems Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...

  • Page 368: Index
