Insignia NS-BIPCD01 Quick Setup Manual

Features
Congratulations on your purchase of a
high-quality Insignia product. Your Front
Boom Box with iPod Dock/CD is
designed for reliable and trouble-free
performance. Use this guide for initial
setup.
antenna
Package contents
• Boom box with iPod Dock/CD
• AC power adapter
• Quick Setup Guide
POWER
"Made for iPod" and "Made for iPhone" mean that an
electronic accessory has been designed to connect
SOURCE
specifically to iPod or iPhone, respectively, and has been
certified by the developer to meet Apple performance
PRESET
standards. Apple is not responsible for the operation of
MEMORY
this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with
VOL +/-
iPod or iPhone may affect wireless performance.
Before using your new product, please read these
instructions to prevent any damage.
Back
CD door
Speakers
DC 9V jack Headphone jack
FM rod
Bottom
Speakers
batteries
AUX IN jack
Handle
iPod
compartment
iPod holder
PLAY/PAUSE
STOP
REPEAT
RANDOM
LCD Display
Battery door/compartment
- -
+ +
6 "C"
- -
+ +
- -
+ +
Boom Box with iPod Dock/CD
Introduction
Please read these instructions carefully before using this product and retain them in a safe place for
future reference.
Power supply
This product can be powered by either the included AC power adapter (100/240V, 50-60Hz), or by
six "C" size alkaline batteries.
Using batteries
1 Open the battery compartment on the bottom of your boom box.
2 Insert 6 "C" size alkaline batteries (not supplied) into the battery compartment, observing the correct
polarity as indicated inside the battery compartment.
3 Close the battery compartment.
Notes: Ensure the compartment cover is securely fitted. When you replace the batteries, make sure you replace them all at the
same time and with the same type of battery. If the product is not to be used for an extended period of time, the batteries should
be removed to prevent any possible damage to the product from corrosive leakage which will invalidate the warranty. When the
batteries reach 20% of capacity, a low battery icon flashes to let you know to change batteries.
Using AC
1 Plug one end of the AC power adapter into the DC 9V jack on the back of your boom box.
2 Plug the other end into an AC power outlet.
Powering your boom box
1 Press the POWER button to turn the boom box ON.
2 Press POWER again to turn the boom box OFF when finished listening.
Controlling the volume
Press the VOLUME +/- buttons to the desired level.
Listening to an external audio device
1 Using an audio cable with a 3.5 mm stereo plug (not provided), connect the external audio
equipment to the AUX IN jack on the back panel of your boom box.
2 Repeatedly press the SOURCE button until AUX appears in the display. Audio plays through the speakers.
Using headphones
Use headphones with a 3.5 mm plug (you may need to buy an adapter if your headphones are different).
The speakers are automatically switched off when the headphones are being used.
Caution: Listening to high volume sound for long periods of time can damage your hearing.
Listening to the radio
1 Press the POWER button to turn the boom box ON. The LCD display turns on.
2 Repeatedly press the SOURCE button until the FM mode is selected.
Example: FM mode
3 Press the / buttons to tune to the desired station.
Auto Tuning
Press the / buttons momentarily and release. The tuner will move up or down by 0.2 MHz
continually until stop at next/previous exist station.
Manual Tuning
Press and hold the / buttons until the display approaches your desired station. Tap the buttons
repeatedly until the display shows the exact frequency.
4 When you have finished listening, press the POWER button to turn the boom box OFF.
Quick Setup Guide
l
NS-BIPCD01
