Insignia NS-BIPCD03 Quick Setup Manual

Features
Congratulations on your purchase of a
high-quality Insignia product. Your
Top
Boombox with Dock for iPhone 5 is
(skip forward/
designed for reliable and trouble-free
tune up) button
performance. Use this guide for initial
SOUND button
setup.
(skip back/tune
Package contents
down) button
• Boombox
PLAY MODE
• AC power adapter
• User Guide
SOURCE button
• Quick Setup Guide
(power) button
(stop) button
(play/pause)
"Made for iPod" and "Made for iPhone" mean that an
electronic accessory has been designed to connect
specifically to iPod or iPhone, respectively, and has been
Left speaker
certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with
Back
iPod or iPhone may affect wireless performance.
Before using your new product, please read these
instructions to prevent any damage.
LCD display
SOUND
button
P L AY M O D E
SOURCE
button
iPod/iPhone
iPod/iPhone USB jack
DC IN jack AUX IN jack
Repeat mode
Sound source
FM AUX CD iPod REPEAT ALL RANDOM
Track or file number,
playing time, and
operating information
Boombox with Dock for iPhone 5
Handle
FM antenna
VOL– button
PRESET button
PRESET
VOL+ button
VOL +
MEMORY MEMORY button
CD compartment
OPEN
LCD display
Right speaker
Lightning
connector dock
Battery compartment
Low battery indicator
indicator
Stereo indicator
STEREO
FLAT
JAZZ
Sound mode
POP
CLASSIC
ROCK
Introduction
Please read these instructions carefully before using this product and retain them in a safe place for
future reference.

Power supply

This product can be powered by either the included AC power adapter (9V 2.2A) which is included in
the package, or by six "C" size alkaline batteries (not included).
Installing the batteries
1 Open the battery compartment on the bottom of your boom box.
2 Insert 6 "C" size alkaline batteries (not supplied) into the battery compartment. Make sure to match
the + and - on each battery to the + and - signs in the battery compartment.
3 Close the battery compartment until it clicks into place.
Connecting the AC adapter
1 Insert the small connector at the end of the AC power adapter cable into the DC IN jack on the back
of your boombox.
2 Plug the AC power adapter into a wall power outlet.
Turning on your boombox
• Press (power) on the top of your boombox.
Selecting the mode (source)
• Press SOURCE repeatedly on the top of your boombox to select FM, iPod DOC, iPod USB, CD or
AUX. The source you select appears on the display.

Volume control

• After you select the mode you want, press VOL+ or VOL– to set the volume to a comfortable level.
Using Radio mode
• Radio mode is the default mode on your boombox the first time you turn it on. Thereafter, your
boombox will turn on to the last mode selected when you turned it off.
Listening to the radio
1 Press the POWER button to turn the boombox ON. The LCD display turns on.
2 Repeatedly press SOURCE until "FM" lights on the display.
Tuning to a station
1 Press (power) on the top of your boombox.
2 Press SOURCE repeatedly to select the FM mode.
3 Press or to tune the radio up or down and select the station you want. When a strong FM
signal is received, Stereo appears on the display.
4 Adjust the volume to a comfortable level by pressing either the VOL+ or VOL- button.
5 To scan to a higher or lower frequency, press and hold
automatically scans to the next station.
6 Press (power) to turn off the boombox.
Quick Setup Guide
l
NS-BIPCD03
or for one second. The radio
