Vented Box Volume; Band-Pass Box Volume; Frequency Response @ 2.83V; Cone Excursion @ 275W - Infinity Reference 1060w Technical Data

VENTED BOX VOLUME

(INCLUDES DRIVER/PORT DISPLACEMENTS)
Reference 1060w
(side view)
3
V = 1.75 ft (49.56 liters)
BOX
VENTED ENCLOSURE

FREQUENCY RESPONSE @ 2.83V

dBSPL
110
105
100
95
In-Car
12 dB LP @ 80Hz
90
85
Out-of-Car
80
75
70
65
60
20 Hz 30 40 50 60
VENTED ENCLOSURE

CONE EXCURSION @ 275W

M
30m
20m
10m
5m
2m
1m
500u
200u
100u
50u
20u
10u
5u
20 Hz 30 40 50 60
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, NY 11797, USA www.infinitysystems.com
Reference 1060w 10" Woofer – Technical Data
Port
length = 4-3/4"
f B = 35.0Hz
121mm
diameter = 3"
77mm
70 80 90 100 200
70 80 90 100 200

BAND-PASS BOX VOLUME

(INCLUDES DRIVER/PORT DISPLACEMENTS)
Reference 1060w
(side view)
3
V = 1.00 ft (28.32 liters)
REAR
BAND-PASS ENCLOSURE
FREQUENCY RESPONSE @ 2.83V
dBSPL
110
105
100
In-Car
12 dB LP @ 80Hz
95
90
85
Out-of-Car
80
75
70
65
60
20 Hz 30 40
300
BAND-PASS ENCLOSURE
CONE EXCURSION @ 275W
M
30m
20m
10m
5m
2m
1m
500u
200u
100u
50u
20u
10u
5u
300
20 Hz 30 40
Port
f B = 50Hz
diam. = 4"
102mm
V = 1.0 ft
FRONT
(28.32 liters)
50 60 70 80 90 100
50 60 70 80 90 100
length =
7-7/8"
200mm
3
200 300
200 300
