Cub Cadet 7284 Engine Parts Manual

Compact tractor 7000 series
Hide thumbs Also See for 7284:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
Engine
Parts Manual
S
7000
ERIES
COMPACT TRACTOR
MODEL 7284
CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 [www.cubcadet.com]
PRINTED IN U.S.A.
FORM NO. 769-01160
(3/04)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7284 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet 7284

Summary of Contents for Cub Cadet 7284

  • Page 1 Engine Parts Manual 7000 ERIES COMPACT TRACTOR MODEL 7284 CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 [www.cubcadet.com] PRINTED IN U.S.A. FORM NO. 769-01160 (3/04)
  • Page 2 HH245-7473U 245-7473 400S403C-11 2004/02/11 The information given within this parts book was correct at the time of printing and is subject to change without notice. Always refer to your local Perkins outlet for the latest information. Only fully trained personnel should carry out servicing of engines.
  • Page 3 Contents Introduction Pg. 4 How To Use Your Parts Book Pg. 4 Engine Breakdown Pg. 5 Symbol Descriptions Pg. 7 Parts Lists & Illustrations Pg. 11 Parts Index Pg. 85...
  • Page 4 Introduction The build list of your engine, found on the front page of this parts book, provides a unique reference to the components fitted to your engine; therefore this parts book is only applicable to this particular engine Always quote your build list and engine serial number when contacting your Perkins outlet. How to use your Parts Book This parts book has been designed to provide you with all the information you need to identify parts to service your engine.

  • Page 5: Table Of Contents

    Engine Breakdown Section Page Section Page Cylinder Block Water Pump A1AH F1AH Pistons & Rings Cooling System A1AH F4AK Connecting Rods Pulleys A1AH F8LH Crankshaft & Bearings Sump A1AH G1KH Cylinder Head Assembly Oil Filter B1AH G1KH Rocker Shaft Assembly Oil Leak-Off Pipes B1AH G1KH...
  • Page 6 Engine Breakdown Section Page Instrumentation Q1DH Inlet Manifold S1BH Exhaust Z1AK Filler Z1NK Miscellaneous Z3CK Electrical Z3EH Miscellaneous Z3EK Page 6...
  • Page 7 Page 7...
  • Page 8 Page 8...
  • Page 9 Symbols and Notes Symbol Description å From Engine Number ç Upto Engine Number é Repairs and Replaces è See Appropriate Section - Reference Number ê Alternative Ñ Order Ú Remanufactured Part ƒ New for Old Part Û Number of Teeth ˚...
  • Page 10 Cylinder Block Plate A A1AH Page 10...

  • Page 11: Cylinder Block

    Cylinder Block Plate A A1AH Item Part No. References Qty. Description Notes Ñ (LONG ENGINE) CYLINDER BLOCK KIT 153-5382 PLUG 153-5384 PLUG 153-5381 PLUG 153-5385 PLUG (064400010) CORE PLUG 153-5387 PLUG 221-1136 PLUG 231-8817 BUSH (030500616) DOWEL (030501025) DOWEL 153-5390 BALL BEARING 153-5391 PLUG...
  • Page 12 Pistons & Rings Plate A A1AH Page 12...

  • Page 13: Pistons & Rings

    Pistons & Rings Plate A A1AH Item Part No. References Qty. Description Notes 231-3885 PISTON AND RING KIT Ñ 231-3885 PISTON 231-3888 PISTON RING KIT 153-5540 GUDGEON PIN (036500021) CIRCLIP (036500021) CIRCLIP Page 13...
  • Page 14 Connecting Rods Plate A A1AH Page 14...

  • Page 15: Connecting Rods

    Connecting Rods Plate A A1AH Item Part No. References Qty. Description Notes 231-3870 CONROD KIT Ñ 231-3870 CONROD Ñ 231-3870 153-5537 CON ROD BOLT (020109075) CON ROD NUT 153-5536 BUSH 231-8814 BIG END SHELL BEARING 231-8814 BIG END SHELL BEARING Page 15...
  • Page 16 Crankshaft & Bearings Plate A A1AH Page 16...

  • Page 17: Crankshaft & Bearings

    Crankshaft & Bearings Plate A A1AH Item Part No. References Qty. Description Notes 231-2799 CRANKSHAFT KIT Ñ 231-2799 CRANKSHAFT 153-5517 CRANKSHAFT GEAR (030509020) (030300816) 231-2800 MAIN BEARING KIT 231-2801 BEARING CAP Ñ 231-2801 BEARING CAP Ñ 231-2801 BEARING CAP (010810840) SCREW (030500612) DOWEL...
  • Page 18 Cylinder Head Assembly Plate A B1AH Page 18...

  • Page 19: Cylinder Head Assembly

    Cylinder Head Assembly Plate A B1AH Item Part No. References Qty. Description Notes 231-2072 CYLINDER HEAD ASSEMBLY Ñ 231-2072 CYLINDER HEAD 230-9126 INSERT 231-2070 INLET VALVE 153-5555 EXHAUST VALVE 153-5559 VALVE STEM SEAL 153-5554 VALVE STEM SEAL 153-5558 VALVE SPRING 153-5556 COTTER 153-5557...
  • Page 20 Rocker Shaft Assembly Plate A B1AH Page 20...

  • Page 21: Rocker Shaft Assembly

    Rocker Shaft Assembly Plate A B1AH Item Part No. References Qty. Description Notes 231-2184 ROCKER SHAFT ASSEMBLY ROCKER SHAFT BRACKET 231-2183 ROCKER ARM SHAFT (015100410) SCREW 156-6948 PLUG 156-6950 O RING 153-5579 LEVER 153-5577 LEVER 153-5586 SPRING 153-5595 WASHER 153-5587 ADJUSTING SCREW 153-5590 231-2208...
  • Page 22 Timing Case Plate A C1LH Page 22...
  • Page 23 Timing Case Plate A C1LH Item Part No. References Qty. Description Notes è (FOLLOWING TIMING GEAR CASE 153-5962 SCREW 165-2139 SCREW 165-2140 SCREW 153-5960 215-2619 TIMING CASE JOINT Page 23...
  • Page 24 Timing Case Plate B C1LH Page 24...

  • Page 25: Timing Case C1Lh

    Timing Case Plate B C1LH Item Part No. References Qty. Description Notes 238-1174 TIMING GEAR CASE (030300414) 231-3821 LEVER 183-3568 SPRING 154-1641 SPRING 154-1401 (052100070) O RING (036800008) SNAPRING 183-3570 LEVER (010110630) SCREW 153-5960 197-7909 SHAFT (052100030) O RING (036800005) CIRCLIP 154-1412 STAY...
  • Page 26 Timing Case Plate C C1LH Page 26...

  • Page 27: Timing Case

    Timing Case Plate C C1LH Item Part No. References Qty. Description Notes 139-5511 ANTI-TAMPER CAP 158-7936 SCREW 162-2207 è (FOLLOWING BOLT è (FOLLOWING BOLT ASSEMBLY Footnotes HIGH IDLE SETTING Page 27...
  • Page 28 Stop Solenoid Control Plate A C1LH Page 28...

  • Page 29: Stop Solenoid Control

    Stop Solenoid Control Plate A C1LH Item Part No. References Qty. Description Notes 217-7111 BOLT ASSEMBLY (020109176) 153-7987 WASHER (052109100) O RING 212-0745 BOLT 212-0747 CIRCLIP 211-7739 ANTI-TAMPER CAP Ñ 211-7739 ANTI-TAMPER CAP (064209053) END CAP 217-7115 ANTI-TAMPER CAP 191-9296 BOLT 153-7987 WASHER...
  • Page 30 Camshaft & Gears Plate A C1LH Page 30...

  • Page 31: Camshaft & Gears

    Camshaft & Gears Plate A C1LH Item Part No. References Qty. Description Notes 153-7984 GEAR - IDLER/OIL PUMP Ñ 153-7984 GEAR (030509018) DOWEL 154-1679 SPRING Ñ 153-7984 VANE 154-1677 BUSH 153-7985 WASHER (120026610) CAMSHAFT ASSEMBLY Ñ (120026610) CAMSHAFT 183-3606 SPACER 183-3645 CAMSHAFT GEAR (034100508)
  • Page 32 Fuel Injection Pump Plate A D1AH Page 32...

  • Page 33: Fuel Injection Pump

    Fuel Injection Pump Plate A D1AH Item Part No. References Qty. Description Notes (131017940) FUEL INJECTION PUMP Ñ (131017940) FUEL INJECTION PUMP 205-4728 CONNECTION 205-4726 BOLT 205-4727 GASKET 205-4727 GASKET (011310620) SCREW 153-5960 ˙ SHIM Ñ (SERVICE OPTION) 238-1210 SOLENOID 153-6412 WASHER Service Options...
  • Page 34 High Pressure Fuel Pipes Plate A D1AH Page 34...

  • Page 35: High Pressure Fuel Pipes

    High Pressure Fuel Pipes Plate A D1AH Item Part No. References Qty. Description Notes FUEL INJECTION PIPE - NO 1 231-7702 FUEL INJECTION PIPE - NO 2 231-7703 FUEL INJECTION PIPE - NO 3 231-7704 153-6393 DAMPER 153-6393 DAMPER (010110625) SCREW 153-5960 Page 35...
  • Page 36 Atomisers Plate A D1AH Page 36...

  • Page 37: Atomisers

    Atomisers Plate A D1AH Item Part No. References Qty. Description Notes 231-7739 ATOMISER LEAK-OFF PIPE (067200078) CLIP (068209026) FUEL INJ PUMP RETURN PIPE (067200078) CLIP 232-0290 CONNECTOR 153-6415 WASHER (131406470) ATOMISER Ñ (131406470) BODY 232-0793 WASHER 154-2716 GASKET Page 37...
  • Page 38 Cold Start System Plate A E1AH Page 38...

  • Page 39: Cold Start System

    Cold Start System Plate A E1AH Item Part No. References Qty. Description Notes 155-8075 CABLE 231-2836 GLOW PLUG (023100004) 231-2836 GLOW PLUG (023100004) 231-2836 GLOW PLUG (023100004) 231-2841 CONNECTOR Page 39...
  • Page 40 Water Pump Plate A F1AH Page 40...

  • Page 41: Water Pump

    Water Pump Plate A F1AH Item Part No. References Qty. Description Notes (145017840) WATER PUMP Ñ (145017840) WATER PUMP Ñ (145017840) SCREW Ñ (145017840) JOINT Ñ (145017840) PLATE Ñ (145017840) PLUG 231-7853 WATER PUMP JOINT 153-5960 154-1823 HOSE 154-1824 CLIP 154-1824 CLIP (145216510)

  • Page 42: F4Ak

    Cooling System Plate E F4AK Page 42...

  • Page 43: Cooling System

    Cooling System Plate E F4AK Item Part No. References Qty. Description Notes 183-3539 (011310614) SCREW Page 43...

  • Page 44: F8Lh

    Pulleys Plate A F8LH Page 44...

  • Page 45: Pulleys

    Pulleys Plate A F8LH Item Part No. References Qty. Description Notes 153-5963 WATERPUMP PULLEY (080109049) FANBELT Page 45...
  • Page 46 Sump Plate A G1KH Page 46...

  • Page 47: Sump

    Sump Plate A G1KH Item Part No. References Qty. Description Notes 153-6830 SUMP 153-6833 SCREW 165-3605 PLUG 153-6832 WASHER 219-4669 GASKET 153-6837 STRAINER (011310612) SCREW 180-6117 OIL PIPE 153-6835 O RING Page 47...
  • Page 48 Oil Filter Plate A G1KH Page 48...

  • Page 49: Oil Filter

    Oil Filter Plate A G1KH Item Part No. References Qty. Description Notes (198416820) DIPSTICK 229-5150 DIPSTICK TUBE 153-6841 O RING (011310612) SCREW 153-6879 CONNECTION 220-1523 OIL FILTER CANISTER Page 49...
  • Page 50 Oil Leak-Off Pipes Plate A G1KH Page 50...

  • Page 51: Oil Leak-Off Pipes

    Oil Leak-Off Pipes Plate A G1KH Item Part No. References Qty. Description Notes 231-7864 OIL PIPE 153-5936 WASHER 153-5936 WASHER 153-6881 BOLT Page 51...
  • Page 52 Relief Valve Plate A G1KH Page 52...

  • Page 53: Relief Valve

    Relief Valve Plate A G1KH Item Part No. References Qty. Description Notes 154-1942 RELIEF VALVE 153-6853 O RING 153-6847 ROTOR 153-6848 COVER Ñ (SERVICE OPTION) 1 SHIM 153-6849 SPRING 153-6850 COLLAR 153-6851 CIRCLIP Service Options 160-4150 ˚ (+)0.10MM SHIM ˙ ˚...
  • Page 54 Lift Pump Plate A H1JK Page 54...

  • Page 55: Lift Pump

    Lift Pump Plate A H1JK Item Part No. References Qty. Description Notes 176-7712 LIFT PUMP 176-7719 O RING 6I-0846 SCREW Page 55...
  • Page 56 Flywheel Assembly Plate A J1CH Page 56...

  • Page 57: Flywheel Assembly

    Flywheel Assembly Plate A J1CH Item Part No. References Qty. Description Notes 153-6864 FLYWHEEL Ñ 153-6864 FLYWHEEL 153-6865 STARTER RING 153-6866 SCREW Page 57...
  • Page 58 Flywheel Housing Plate A J1CH Page 58...

  • Page 59: Flywheel Housing

    Flywheel Housing Plate A J1CH Item Part No. References Qty. Description Notes (TPN768) BACKPLATE 153-6868 SCREW 153-6375 SCREW Page 59...
  • Page 60 Starter Group Plate B K1PK Page 60...

  • Page 61: Starter Group

    Starter Group Plate B K1PK Item Part No. References Qty. Description Notes 138-6754 é 138-7454 STARTERMOTOR (A) 1.4 KW (010311045) BOLT 155-8085 154-1399 WASHER 154-2403 WASHER Footnotes BREAKDOWN HAS YET TO BE ADVISED. STARTER MOTOR Page 61...
  • Page 62 Exhaust Manifold Group Plate D L1CK Page 62...

  • Page 63: Exhaust Manifold Group

    Exhaust Manifold Group Plate D L1CK Item Part No. References Qty. Description Notes 183-4332 EXHAUST MANIFOLD 153-6860 EXHAUST MANIFOLD GASKET 153-6861 SCREW 153-5960 Page 63...
  • Page 64 Alternator Plate A N1BH Page 64...

  • Page 65: Alternator

    Alternator Plate A N1BH Item Part No. References Qty. Description Notes 183-4029 ALTERNATOR 183-4033 BRACKET (011510855) SCREW (011511040) SCREW 154-1399 WASHER 183-4030 LEVER 165-2140 SCREW (011510840) SCREW 168-9002 WASHER 183-4031 SPACER 154-1244 SCREW Page 65...
  • Page 66 Engine Lifting Plate A O1AK Page 66...

  • Page 67: Engine Lifting

    Engine Lifting Plate A O1AK Item Part No. References Qty. Description Notes 153-6374 PLATE 153-6375 SCREW 153-6374 PLATE 153-6375 SCREW Page 67...
  • Page 68 Auxiliary Drive Plate A P1PK Page 68...

  • Page 69: Auxiliary Drive

    Auxiliary Drive Plate A P1PK Item Part No. References Qty. Description Notes 177-3308 CRANKSHAFT PULLEY (020800018) (034100508) WOODRUFF KEY 154-1882 PLATE 153-6494 JOINT (052300600) O RING (010310865) BOLT 153-5592 Page 69...
  • Page 70 Instrumentation Plate A Q1DH Page 70...

  • Page 71: Instrumentation

    Instrumentation Plate A Q1DH Item Part No. References Qty. Description Notes 217-5792 ADAPTOR 153-5936 WASHER 153-5936 WASHER (TPN485) OIL PRESSURE SWITCH (385720510) WATER TEMPERATURE SENSOR (064400010) CORE PLUG Page 71...
  • Page 72 Inlet Manifold Plate A S1BH Page 72...

  • Page 73: Inlet Manifold

    Inlet Manifold Plate A S1BH Item Part No. References Qty. Description Notes 238-1330 CYLINDER HEAD COVER 217-5859 BREATHER VALVE 217-5860 METRIC BOLT 231-3010 RETAINING PLATE 153-5939 GAUZE 217-5862 SCREW 231-3013 AIR INTAKE PIPE 231-3014 GASKET (011310620) SCREW 231-3020 GASKET 165-2139 SCREW 153-6861 SCREW...

  • Page 74: Z1Ak

    Exhaust Plate A Z1AK Page 74...

  • Page 75: Exhaust

    Exhaust Plate A Z1AK Item Part No. References Qty. Description Notes 153-7920 JOINT 168-9001 SCREW Page 75...
  • Page 76 Filler Plate A Z1NK Page 76...

  • Page 77: Filler

    Filler Plate A Z1NK Item Part No. References Qty. Description Notes 205-7713 FILLER (052100420) SEAL Page 77...

  • Page 78: Z3Ck

    Miscellaneous Plate E Z3CK Page 78...

  • Page 79: Miscellaneous

    Miscellaneous Plate E Z3CK Item Part No. References Qty. Description Notes (020900008) Page 79...
  • Page 80 Electrical Plate A Z3EH Page 80...

  • Page 81: Electrical

    Electrical Plate A Z3EH Item Part No. References Qty. Description Notes 197-8555 CONNECTION 183-4037 CONNECTOR Footnotes STARTER MOTOR Page 81...
  • Page 82 Miscellaneous Plate A Z3EK Page 82...
  • Page 83 Miscellaneous Plate A Z3EK Item Part No. References Qty. Description Notes 197-8547 LAMP Page 83...
  • Page 84 Parts Index Page 84...
  • Page 85 Parts Index Description Part No. Page Description Part No. Page ADAPTOR 217-5792 BREATHER VALVE 217-5859 ADJUSTING SCREW 153-5587 BUSH 153-5536 AIR INTAKE PIPE 231-3013 154-1677 ALTERNATOR 183-4029 231-8817 ANTI-TAMPER CAP 139-5511 CABLE 155-8075 211-7739 CAMSHAFT ASSEMBLY (120026610) 217-7115 CAMSHAFT GEAR 183-3645 154-1401 153-5573...
  • Page 86 Parts Index Description Part No. Page Description Part No. Page CRANKSHAFT PULLEY 177-3308 GASKET 154-2716 CYLINDER HEAD AS- 231-2072 205-4727 33, 33 SEMBLY 219-4669 CYLINDER HEAD COV- 238-1330 231-3014 231-3020 CYLINDER HEAD GAS- (111147560) GAUZE 153-5939 231-2073 GEAR - IDLER/OIL PUMP 153-7984 DAMPER 153-6393...
  • Page 87 Parts Index Description Part No. Page Description Part No. Page (020900008) PLATE 153-6374 67, 67 (023100004) 39, 39, 39 153-7990 133-5512 154-1882 153-5590 200-6454 153-5592 21, 69 PLUG (064510060) 153-5934 153-5381 11, 19 153-5960 23, 25, 33, 153-5382 35, 41, 41, 153-5384 41, 63 153-5385...
  • Page 88 Parts Index Description Part No. Page Description Part No. Page (011310614) 160-4152 (011310616) 160-4153 (011310620) 33, 73 161-1432 (011510840) 161-1433 (011510850) 161-1434 (011510855) 161-1435 (011511040) SNAPRING (036800008) (015100410) SOLENOID 238-1210 153-5575 SPACER 183-3606 153-5578 183-4031 153-5962 23, 41 SPRING 153-5586 153-6375 59, 67, 67 153-6849...
  • Page 89 Parts Index Description Part No. Page (145226460) THERMOSTAT HOUSING 231-7861 JOINT TIMING CASE JOINT 215-2618 215-2619 TIMING GEAR CASE 238-1174 VALVE CAP 153-5557 VALVE SPRING 153-5558 VALVE STEM SEAL 153-5554 153-5559 WASHER (026200008) 153-5595 153-5936 51, 51, 71, 71, 73 153-6412 153-6415 153-6832...
