- Page 1 Opto 232 Adapter Applications and Operation Manual...
- Page 2 Opto 232 Adapter RS-232 Bi-Directional Optically Isolated Adapter • Introduction The Opto232 is designed specially for the VSI-Pro but will work with any RS-232C device. It basically separates the ground signal from the transmitting device to the receiving device by optical LED devices.
- Page 3 VSI-Pro Connection In most cases the Opto232 can plug in line with all the stan- dard cash register cables from AVE. It also can plug directly to the DB9F connector on the rear of the VSI-Pro. A standard CR-802 cable which is a DB9M to DB9F 9 conductor exten- sion cable can also work between the VSI-Pro and the Op- to232 or between the Opto232 and the register.
- Page 4 VSI-Pro. If you are using the TXD output of the VSI-Pro to the DVR, Reg- com, Networker or Vnetworker then you should use an AVE “Multifunction Cable Adapter” directly on the rear of the VSI- Pro and then use the Opto232 after that connection to the cash register.
- Page 5 • Connector Pin Out and Assignments DB9M to VSI-Pro Side 1 – N/C 2 – TXD 3 – RXD 4 – DTR Connected to power the Opto232 5 – GND 6 – DSR Connected to power the Opto232 7 – RTS N/C 8 –...
- Page 6 Opto 232 Adapter 2.1mm X 5.5mm DC Coax Jack Hydra Regcom Page 6...
- Page 7 Multi - Function Cable Opto 232 Cash Register Use Standard Emulate / Tap Cable Vnetworker Networker / Regcom VSI-Pro Opto 232 with DVR, Networking, Regcom CR-802 or VSI-Pro Plug Direct RS232 Adapter Opto 232 VSI-Pro Opto 232 & USB232 Page 7...
- Page 8 & Powered PIN 4 - 6 VSI-Pro CR-802 or Plug Direct Gender Opto 232 Changer VSI-Pro to PC Opto 232 Powered by PC PIN 7 - 8 & Powered PIN 4 - 6 VSI-Pro CR-802 or Plug Direct Power Supply...
- Page 9 Power Supply Emulate / Protocol Use Standard Emulate / Tap Cable Opto 232 VSI-Pro Opto 232 VSI-Pro CR-802 Opto 232 Cash Register Use Standard CR-802 or Emulate/ Tap Cable Plug Direct Vnetworker VSI-Pro with Vnetworker & Opto 232 Page 9...
- Page 10 Notes _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ Page 10...
- Page 11 Notes _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ _____________________________________ Page 11...
- Page 12 ASIA AVE (Thailand) Company Limited 147 Soi Onnut 44 (Sampheenong Villa), Sukhumvit Road., Suanluang, Suanluang, Bangkok 10250, Thailand. Tel : 02-331-3964/ 02-331-9285/ 02-742-0221 Fax : 02-331-9365 Email: ave@avethailand.com Website : www.avethailand.com NORTH AMERICA AVE USA 2000 West Governors Circle, Suite E...
