Panasonic PT-L735NT Spec File

Ultra portable wireless lcd projector

Download this manual

S P E C

PRODUCT NO.: PT-L735NT

PRODUCT NAME: Ultra Portable Wireless LCD Projector

MAJOR FEATURES

• Bright

- High 2600 ANSI lumens brightness

• Easy wireless presentations

- Easy-to-use settings

- Useful "Live" mode

- PC-free SD card presentation

• Time-saving

- One-touch auto setup

- Automatic input signal detector

- Speed start

- Direct power off

- Momentary switch

F I L E

• Superior sound performance

- Whisper-quiet operation (28 dB)*

- Powerful 5W x 2 stereo speakers

• Secure

- Password and control lock

- Custom startup screen

- Text superimposing

• Convenient

- H/V keystone correction

- Auto power offf

- RGB2-in/RGB1-out switchable

- Blackboard mode

- 1 -

* In low lamp power mode

Table of Contents

Page 1: Major Features
S P E C F I L E PRODUCT NO.: PT-L735NT PRODUCT NAME: Ultra Portable Wireless LCD Projector MAJOR FEATURES • Bright • Superior sound performance - High 2600 ANSI lumens brightness - Whisper-quiet operation (28 dB)* • Easy wireless presentations...
Page 2: Specifications
S P E C F I L E PT-L735NT Micro-Portable LCD Projector Specifications Power supply: 100 – 240 V AC, 50/60 Hz Power consumption: 280 W (5 W in standby mode with fan stopped) Optical system: Dichroic mirror separation/prism synthesis system...
Page 3 S P E C F I L E PT-L735NT Micro-Portable LCD Projector Dimensions (W x H x D): 248 x 115 x 359 mm (9-25/32˝ x 4-17/32˝ x 14-5/32˝) (not including protruding parts) Weight: 4.2 kg (9.3 lbs.) Operating environment: Temperature: 0°...
Page 4 S P E C F I L E PT-L735NT Micro-Portable LCD Projector Dimensions unit: mm (inch) Note: This illustration is not drawn to scale. 16 (5/8˝) 248 (9-25/32˝) 359 (14-5/32˝) Terminals USB connector Serial RGB1 input RGB2 input/RGB1 output Audio output...
Page 5: Standard Setting-Up Positions
S P E C F I L E PT-L735NT Micro-Portable LCD Projector Standard setting-up positions unit: mm A: Distance to screen E: Height from the edge of screen to center of lens NOTE: Illustrations show the projector installed using optional ceiling bracket.
