- Page 1 RS-232C Protocol Manual For LCD Projectors PT-L711, PT-L701, PT-L701SD, PTL511, and PT-L501 Version 1.0...
-
Page 2: Revision List
Revision List Date Revision Number Description 07/02/2001 Manual first release Panasonic Broadcast and Television Systems Company 3330 Cahuenga Blvd. West Los Angeles, CA 90068 Phone 323-436-3500 Web Site http\\www.panasonic.com... -
Page 3: Table Of Contents
T able of Content Introduction _________________________________________________ 5 Connection __________________________________________________ 6 Communication Parameters _________________________________ 6 Address level______________________________________________ 6 RS-232C Connection _______________________________________ 6 Cable Specifications ________________________________________ 7 Communication ______________________________________________ 8 Command Format _________________________________________ 8 Replies___________________________________________________ 9 The Command List___________________________________________ 10 Command Explanation _______________________________________ 14... - Page 4 Query Auto YPbPr (QAY) ________________________________ 53 5.41 Query Background Color (QBC) __________________________ 54 5.42 Query Clock Phase Level (QCP) ___________________________ 55 5.43 Query Dot Clock Level (QDC)_____________________________ 56 5.44 Query Input Display (QDI) _______________________________ 57 Panasonic RS-232 Protocol for LCD Projector...
- Page 5 5.71 Query White Balance Red (QWR) _________________________ 84 5.72 Query Lamp On Time (Q$L) ______________________________ 85 5.73 Query Lamp On Condition (Q$S) __________________________ 86 5.74 Brightness (VBR) _______________________________________ 87 5.75 Contrast (VCN) _________________________________________ 88 Panasonic RS-232 Protocol for LCD Projector...
- Page 6 5.86 V-Position (VVP)________________________________________ 99 5.87 White Balance Blue (VWB) ______________________________ 100 5.88 White Balance Green (VWG) ____________________________ 101 5.89 White Balance Red (VWR) ______________________________ 102 ASCII CODE TABLE _______________________________________ 103 List of Signals______________________________________________ 107 Panasonic RS-232 Protocol for LCD Projector...
-
Page 7: Introduction
1 Introduction This document describes the commands and data formats to control by RS-232C, from a controller to the Panasonic projector. This document should be used in conjunction with the Operation Instructions. Information furnished in this document, is believed to be accurate and reliable. -
Page 8: Connection
The address level of this Projector corresponds to address level 0 within the MIS standard. This unit does not support multiple machine control from a single communication port. Address level 0 only one projector and the address information is eliminated 2.3 RS-232C Connection Connector is Dsub 9pin (Female) as seen from the outside Pin # Signal... -
Page 9: Cable Specifications
2.4 Cable Specifications Use a RS-232C 9 pin to 9 pin straight cable. Pins 4,7 and 8 are internally shorted together in the projector. Panasonic RS-232 Protocol for LCD Projector... -
Page 10: Communication
Command and its parameter should be separated by a ”:” colon (Hex’3A’). When a command that does not require parameters is sent, then the separating colon can be eliminated. Example of a command string [STX] [ETX] Command with Parameter [STX] [ETX] Command without Parameter Panasonic RS-232 Protocol for LCD Projector... -
Page 11: Replies
[STX]Q$L:0000[ETX]. Parameter information will be replied only in the case of a Question type command. Check the com mand list for the specific information. Example of Commands sent to the Projector. Projector Controller [STX]IIS:RGB1[ETX] After IIS Command [STX]IIS[ETX] has Executed Panasonic RS-232 Protocol for LCD Projector... -
Page 12: The Command List
Digital Zoom Down Digital Zoom Up Input Select Keystone Auto Keystone Auto RGB Input Auto Set-up Auto YPbPr Background Color Cursor Down Cursor Left Cursor Right Cursor Up Enter Function 1 Freeze Gamma Set Input Display Panasonic RS-232 Protocol for LCD Projector... - Page 13 Query Auto RGB Input Query Auto Set-up Query Volume Level Query Auto YPbPr Query Background Color Query Clock Phase Level Query Dot Clock Level Query Input Display Query Function Query Horizontal Frequency Query Vertical Frequency Query Freeze Panasonic RS-232 Protocol for LCD Projector...
- Page 14 Query V-Position Level Query Contrast Level Query Sharpness Level Query Tint Level Query Video Size Level Query White Balance Blue Query White Balance Green Query White Balance Red Query Lamp on Time Query Lamp On Condition Panasonic RS-232 Protocol for LCD Projector...
- Page 15 The Command Command Description Brightness Contrast Color Clock Phase Dot Clock H-Position Picture Mode Signal Mode Set Sharpness Video Size S1 Signal Tint V-Position White Balance Blue White Balance Green White Balance Red Panasonic RS-232 Protocol for LCD Projector...
-
Page 16: Command Explanation
Other information that is helpful concerning this command. Projector Model to Command Compatibility Model PT-L711U PT-L701U PT-L701SDU PT-L501U PT-L511U Number Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 17: Audio Volume Down (Aud)
5 times. The range is from 0 to 63 Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 18: Audio Volume Up (Auu)
5 times. The range is from 0 to 63 Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 19: Audio Volume Set (Avl)
063 would be maximum volume. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 20: Control Panel (Cpk)
Sending CPK:0 can disable the buttons Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 21: Digital Zoom Down (Dzd)
Zoom Mode. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 22: Digital Zoom Up (Dzu)
Zoom Mode. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 23: Input Select (Iis)
If an unused input is selected the Background will be displayed. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 24: Keystone (Kst)
Command to escape the Keystone Adjustment Mode. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 25: Auto Keystone (Oak)
Keystone Adjustment when the Auto Set-up (OAS) is done. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 26: Auto Rgb Input (Oar)
RGB Input Adjustment when the Auto Set-up (OAS) is done. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 27: Auto Set-Up (Oas)
Off, that item will be skipped. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 28: Auto Ypbpr (Oay)
YPbPr Adjustment when the Auto Set-up (OAS) is done. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 29: Background Color (Obc)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 30: Cursor Down (Ocd)
This command is used to Navigate Menus and for some Adjustments Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 31: Cursor Left (Ocl)
This command is used to Navigate Menus and for some Adjustments Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 32: Cursor Right (Ocr)
This command is used to Navigate Menus and for some Adjustments Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 33: Cursor Up (Ocu)
This command is used to Navigate Menus and for some Adjustments Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 34: Enter (Oen)
This command is used to Navigate Menus and for some Adjustments Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 35: Function 1 (Ofc)
RM100 wireless remote control unit. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 36: Freeze (Ofz)
This command will capture a still image and display it. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 37: Gamma Set (Ogs)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 38: Input Display (Oid)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 39: Installation (Oil)
[STX]OIL[E TX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 40: Index Window (Oix)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 41: Keystone (Oks)
Normal is 0. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 42: Language (Olg)
[STX]OLG:ENG[ETX] All menus will show in English. Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 43: Lamp Power (Olp)
Lamp will increase. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 44: Menu (Omn)
This command is used to bring up the Menu. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 45: Rgb Format (Orf)
YPbPr is on this command may not be accessible. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 46: Resizing (Orz)
LCD Panels. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 47: Shutter (Osh)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 48: Standard (Ost)
Examples of Use [STX]OST[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 49: Power Off (Pof)
Standby Mode. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 50: Power On (Pon)
This is done to protect the Lamp. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 51: Query Auto Keystone (Qak)
Examples of Use [STX]QAK[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 52: Query Auto Rgb Input (Qar)
Examples of Use [STX]QAR[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 53: Query Auto Set-Up (Qas)
Examples of Use [STX]QAS[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 54: Query Volume Level (Qav)
Examples of Use [STX]QAV[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 55: Query Auto Ypbpr (Qay)
Examples of Use [STX]QAY[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 56: Query Background Color (Qbc)
Examples of Use [STX]QBC[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 57: Query Clock Phase Level (Qcp)
Examples of Use [STX]QCP[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 58: Query Dot Clock Level (Qdc)
Examples of Use [STX]QDC[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 59: Query Input Display (Qdi)
Examples of Use [STX]QDI[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 60: Query Function (Qfc)
Examples of Use [STX]QFC[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 61: Query Horizontal Frequency (Qfh)
The response from the projector is in kHz. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 62: Query Vertical Frequency (Qfv)
The response from the projector is in Hz. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 63: Query Freeze (Qfz)
Examples of Use [STX]QFZ[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 64: Query H-Position Level (Qhp)
Examples of Use [STX]QHP[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 65: Query Input Signal (Qin)
Examples of Use [STX]QIN[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 66: Query Index Window (Qix)
Examples of Use [STX]QIX[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 67: Query Keystone (Qks)
Examples of Use [STX]QKS[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 68: Query Language (Qlg)
Examples of Use [STX]QLG[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 69: Query Lamp Power (Qlp)
Examples of Use [STX]QLP[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 70: Query Picture Mode (Qpm)
Examples of Use [STX]QPM[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 71: Query Power Condition (Qpw)
Examples of Use [STX]QPW[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 72: Query Rgb Format (Qrf)
Examples of Use [STX]QRF[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 73: Query Resizing (Qrz)
Examples of Use [STX]QRZ[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 74: Query Signal Mode (Qsg)
The response from the projector will be the present signaled displayed. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 75: Query Shutter (Qsh)
Examples of Use [STX]QSH[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 76: Query Installation (Qsp)
Examples of Use [STX]QSP[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 77: Query Brightness (Qvb)
Examples of Use [STX]QVB[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 78: Query Color Level (Qvc)
Examples of Use [STX]QVC[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 79: Query V-Position Level (Qvp)
Examples of Use [STX]QVP[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 80: Query Contrast Level (Qvr)
Examples of Use [STX]QVR[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 81: Query Sharpness Level (Qvs)
Examples of Use [STX]QVS[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 82: Query Tint Level (Qvt)
Examples of Use [STX]QVT[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 83: Query Video Size Level (Qvz)
Examples of Use [STX]QVZ[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 84: Query White Balance Blue (Qwb)
Examples of Use [STX]QWB[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 85: Query White Balance Green (Qwg)
Examples of Use [STX]QWG[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 86: Query White Balance Red (Qwr)
Examples of Use [STX]QWR[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 87: Query Lamp On Time (Q$L)
Examples of Use [STX]Q$L[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 88: Query Lamp On Condition (Q$S)
Active the unit is in the process of powering off. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 89: Brightness (Vbr)
This command is available for all inputs. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 90: Contrast (Vcn)
This command is available for all input signals Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 91: Color (Vco)
This command is for the S-Video, Video and YPbPr inputs. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 92: Clock Phase (Vcp)
This command is available for the RGB signal only. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 93: Dot Clock (Vdc)
This command is available for the RGB signal only. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 94: H-Position (Vhp)
Examples of Use [STX]VHP:098[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 95: Picture Mode (Vpm)
HDTV sources and Dynamic be used for Computer sources. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 96: Signal Mode Set (Vsg)
In Auto Mode the Projector will auto detect the input. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 97: Sharpness (Vsr)
This command is available for all inputs. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 98: Video Size (Vsz)
This will make the picture larger or smaller. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 99: S1 Signal (Vs1)
Chroma channel. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 100: Tint (Vtn)
Video inputs that are NTSC and NTSC 4.43 only. Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 101: V-Position (Vvp)
Examples of Use [STX]VVP:088[ETX] Notes Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 102: White Balance Blue (Vwb)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 103: White Balance Green (Vwg)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 104: White Balance Red (Vwr)
Projector Model to Command Compatibility PT-L701SDU Model PT-L711U PT-L701U PT-L511U PT-L501U PT-L701XSDU Number PT-L711XU PT-L701XU PT-L511XU PT-L501XU Command Acceptance (Yes if Command can be used, No if command cannot be used) Panasonic RS-232 Protocol for LCD Projector... -
Page 105: Ascii Code Table
0001 1001 End of Medium (Ctrl-Y) 0001 1010 Substitute (Ctrl-Z) 0001 1011 Escape (Ctrl-[) 0001 1100 File Separator (Ctrl-\) 0001 1101 Group Separator (Ctrl-]) 0001 1110 Record Separator (Ctrl-^) 0001 1111 Unit Separator (Ctrl-_) Panasonic RS-232 Protocol for LCD Projector... - Page 106 0011 0010 0011 0011 0011 0100 0011 0101 0011 0110 0011 0111 0011 1000 0011 1001 0011 1010 0011 1011 < 0011 1100 0011 1101 > 0011 1110 0011 1111 0100 0000 0100 0001 Panasonic RS-232 Protocol for LCD Projector...
- Page 107 0101 0011 0101 0100 0101 0101 0101 0110 0101 0111 0101 1000 0101 1001 0101 1010 0101 1011 0101 1100 0101 1101 0101 1110 0101 1111 0110 0000 0110 0001 0110 0010 0110 0011 Panasonic RS-232 Protocol for LCD Projector...
- Page 108 0110 1111 0111 0000 0111 0001 0111 0010 0111 0011 0111 0100 0111 0101 0111 0110 0111 0111 0111 1000 0111 1001 0111 1010 0111 1011 0111 1100 0111 1101 0111 1110 0111 1111 Delete Panasonic RS-232 Protocol for LCD Projector...
-
Page 109: List Of Signals
1024 X 768i 65.549 86.000 1024 X 768 68.678 94.500 1024 X 768 35.520 44.897 1024 X 768 80.030 105.000 1024 X 768 96.726 130.000 MXGA 1120 X 760 50.108 60.153 1152 X 864 63.995 71.184 Panasonic RS-232 Protocol for LCD Projector... - Page 110 31.469 59.940 YPbPr 720p 1280 X 720 45.000 60.000 YPbPr HDTV 1920 X 1080i 33.750 60.000 YPbPr/RGB NTSC/M-NTSC/PAL- Video/S- 768 X 480i 15.734 59.940 Video Video/S- PAL/PAL -N/SECAM 768 X 576i 15.625 50.000 Video Panasonic RS-232 Protocol for LCD Projector...
