QuickSpecs
Overview
1.
(2) 5.25" external bays and (2) 3.5" internal bays
2.
(1) 3.5" external bay for optional HP 16-in-1 Media
Card Reader, diskette drive, or other 3.5" device
3.
300-watt power supply
4.
Rear I/O: (6) USB 2.0, (1) standard serial port, (1)
optional serial port, (1) optional parallel port, (2) PS/2,
(1) RJ-45, (1) VGA, (1) audio in, (1) audio out
Microtower
5.
6.
7.
8.
9.
DA - 12863 U.S. QuickSpecs — Version 3 — 4/2/2008
HP Compaq dc5800 Business PC
HP recommends
Windows Vista
(1) full-height PCI slot, (2) full-height PCIe x1 slots, (1) full-
height PCIe x16 (ADD2/SDVO) slot
Front I/O: (2) USB 2.0, headphone and microphone, Dual
Color Diagnostic LEDs
2-Button Scroll Mouse (PS/2, Optical Scroll Mouse (PS/2 or
USB), or USB Laser Mouse
HP Standard Keyboard (PS/2 or USB) or HP USB
Smartcard Keyboard
Monitor (sold separately)
®
Business
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP Compaq dc5800

Summary of Contents for HP Compaq dc5800

  • Page 1 (1) full-height PCI slot, (2) full-height PCIe x1 slots, (1) full- height PCIe x16 (ADD2/SDVO) slot (1) 3.5” external bay for optional HP 16-in-1 Media Front I/O: (2) USB 2.0, headphone and microphone, Dual Card Reader, diskette drive, or other 3.5” device...
  • Page 2 QuickSpecs HP Compaq dc5800 Business PC Overview Small Form Factor (1) 3.5” external bay for optional HP 16-in-1 Media Card Front I/O: (2) USB 2.0, headphone and microphone, Reader, diskette drive, or other 3.5” device; Dual Color Diagnostic LEDs (1) 3.5” internal bay (1) 5.25”...
  • Page 3 Overview At A Glance The HP Compaq dc5800 offers a stable solution with mainstream features and flexibility that exceed basic business requirements Intel® Q33 Express chipset, Intel Core™ 2 Duo processors, Intel Core 2 Quad processors, and Intel Graphics Media Accelerator 3100 integrated graphics Embedded TPM1.2 compliant security module* (Vista Bit-Locker ready)

  • Page 4: Configurable Components - Select Models (Localized By Regions)

    QuickSpecs HP Compaq dc5800 Business PC Configurable Components - Select Models (localized by Regions) Model Key and Example NOTE: This diagram is an example that illustrates how to read the model number. It is not intended to give every available configuration choice specified in the body of this document and may include references to modules that are out of date and no longer available.

  • Page 5: Standard Features And Configurable Components

    InterVideo WinDVD 5.0 (select models) HP ProtectTools security software suite Easy Media Creator 9 (select models) Value-added Software HP Client Configuration Manager, Basic Edition HP Client Catalog for Microsoft SMS (available for free HP Client Manager for Altiris HP Systems Software Manager download from the Web http://www.hp.com/...
  • Page 6 NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
  • Page 7 HP recommends dual-channel symmetric configurations for maximum performance. For best performance, add the same amount of total memory to each channel and do not mix speeds.
  • Page 8 QuickSpecs HP Compaq dc5800 Business PC Standard Features and Configurable Components Microtower and Small Form Factor Maximum Memory* Supports up to 8-GB of DDR2 SYNCH DRAM. Slot 1 is black and must always be populated. Not all memory configurations possible are represented below.
  • Page 9 QuickSpecs HP Compaq dc5800 Business PC Standard Features and Configurable Components Expandability Microtower Small Form Factor PCI slots 1 full-height 1 low-profile Max power per slot PCIe x1 slot Max power per slot PCIe x16 slot (also 1 full-height 1 low-profile...
  • Page 10 QuickSpecs HP Compaq dc5800 Business PC Standard Features and Configurable Components Storage – Drive Support Microtower Small Form Factor Media Card 5.25” Serial 3.5” Serial Media Card 5.25” Serial 3.5” Serial Reader or ATA Devices ATA Devices Reader or ATA Devices...
  • Page 11 One or more of the 1.44-MB Diskette Drive following depending on Media Reader form factor (see Storage HP 16-in-1 Media Reader (USB connection on the system board) – Drive Support section above) Optical Drives SATA DVD-ROM Drive SATA CD-RW/DVD-ROM Combo Drive...
  • Page 12 USB 2-Button Laser Mouse PS/2 2-Button Optical Scroll Mouse USB 2-Button Optical Scroll Mouse Miscellaneous HP FireWire / IEEE 1394 PCI Card (full height) HP FireWire / IEEE 1394 PCI Card (low profile) serial port adapter serial port adapter (low profile)

  • Page 13: After-Market Options (Availability May Vary By Region)

    RZ363A#ABA Communications Wireless LAN HP Wireless A+G PCI Card (North America only) EA118AA HP Wireless A+G PCI Card (WW except North America) PZ928AA HP BT450 USB Bluetooth Wireless Printer and PC Adapter IPQ639A NICs Broadcom NetXtreme Gigabit Ethernet PCIe NIC Card...
  • Page 14 HP LP2465 24-inch Widescreen LCD Monitor EF224A4#ABA HP LP3065 30-inch Widescreen LCD Monitor EZ320A4#ABA Business Widescreen LCD Monitor with Integrated Speakers HP L1908wm 19-inch Widescreen LCD Monitor with Built in Integrated KA214AA#ABA Speakers Business GSA Monitors 3PO Offering Business Touchscreen LCD Monitor...
  • Page 15 Removable Storage Diskette and Digital Drives HP 1.44-MB External USB Diskette Drive DC141B HP 1.44-MB Internal Diskette Drive AH053AA Multimedia HP 16-in-1 Media Card Reader with PCI Card EM718AA Security Kensington lock PC766A HP ProtectTools security software suite KN740AA HP 2007 Wall Mount/Security Sleeve...
  • Page 16 PA716A Accessories HP Parallel Port Adapter KD061AA Belken USB to Serial Adapter EM449AA HP FireWire / IEEE 1394 PCI Card PA997A DVI to DVI Cable DC198A 5.25" Blank Bezel Kit (Carbonite 50/Bulk Pack) DC177B Local Area Network (LAN) cable, Ethernet cable...

  • Page 17: Technical Specifications

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications Unit Environment and Operating Microtower Small Form Factor Conditions General Unit Operating Guidelines Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is operated within the specified operating range.
  • Page 18 Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification. Security – HP BIOS offers a robust and flexible set of security features to help the system administrator secure their systems from removal of sensitive data, and help prevent access by unauthorized users.
  • Page 19 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications Serviceability Features of System Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions) Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:...

  • Page 20: Technical Specifications - Audio

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Audio High Definition Audio Type Integrated High Definition Stereo Yes – 4-channel ADI 1884 codec Codec Audio Jacks Front microphone-In (150-K ohm Input Impedance) Rear Line-In/Microphone input (150-K ohm Input Impedance, function is...

  • Page 21: Technical Specifications - Communications

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Communications Integrated Intel Connector RJ-45 82566DM Gigabit Controller Intel Nineveh Gigabit platform LAN Connect Networking Controller Network Connection Memory Integrated 96KbB on chip buffer memory Data rates supported 10/100/1000 Mbps Compliance IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3 ab and 802.3u compliant,...
  • Page 22 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Communications Network transfer rate 10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 20 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 200 Mbps 1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus) Environmental Operating temperature 32°...
  • Page 23 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Communications HP Wireless A+G PCI Dimensions 4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm) Weight 0.268 lb (65 g) Controller Atheros AR5414X chipset system interface PCI Spec 2.2 Network standard IEEE 802.11a/b/g...
  • Page 24 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Communications 2006 Agere PCI 56K Data Transmission Technology speeds: 56,000 Kbps maximum downstream data, International controllerless SoftModem NOTE: 56 Kbps technology refers to download speeds only and requires compatible modems at server sites.

  • Page 25: Technical Specifications - Graphics

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Graphics Integrated Graphics 3D/2D Controller Microsoft DirectX® 9 based with support for Pixel Shader 2.0, 4:1 Media Accelerator 3100 anisotropic filtering, Gaussian texture filtering, shadow maps, volumetric textures, double-sided stencil buffers, and 4 pixel pipes.
  • Page 26 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Graphics DVI ADD2 Graphics Models HP ADD2 SDVO DVI-D Out Adapter Form Factor Low-profile card DVI-D Connector Digital connection only Dual Head Support Yes, when used with the integrated VGA connector...
  • Page 27 NVIDIA GeForce 8400 GS (256 MB SH) PCIe x16 Graphics Controller display resolutions and refresh rates NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP. DA - 12863 U.S. QuickSpecs — Version 3 — 4/2/2008...
  • Page 28 Board display options DMS59 + TV DMS59 supports either 2 VGA displays with the included cable or 2 DVII displays with optional HP DMS59 DVI Dual-head Connector Cable kit #DL139A TV connector is a 4-pin mini-DIN S-video connector Board configuration...
  • Page 29 Technical Specifications - Graphics NVIDIA GeForce 8400 GS (256 MB DH) PCIe x1 Graphics Controller display resolutions and refresh rates NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP. Analog Resolution...

  • Page 30: Technical Specifications - Hard Drives

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Hard Drives 7200 RPM Serial ATA 500-GB Capacity 500,107,862,016 bytes Hard Drives Height 1 in (2.54 cm) Width Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm) Interface Serial ATA (3.0 Gb/s)
  • Page 31 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Hard Drives 160-GB Capacity 160,041,885,696 bytes Height 1 in (2.54 cm) Width Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm) Interface Serial ATA (3.0 Gb/s) Synchronous Transfer...

  • Page 32: Technical Specifications - Input/Output Devices

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Input/Output Devices PS/2 Standard Physical Keys 104, 105, 106, 107, 109 layout (depending Keyboard characteristics upon country) Dimensions (L x W x H) 18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm) Weight 2 lb (0.9 kg) minimum...
  • Page 33 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Input/Output Devices HP PS/2 Optical Scroll Dimensions (H x L x W) 3.95 x 6.21 x 11.7 cm (1.56 x 2.44 x 4.61 in) Mouse Weight 4.44 oz (126 g) Environmental Operating temperature -32°...
  • Page 34 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Input/Output Devices HP USB Optical Scroll Dimensions (H x L x W) 1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm) Mouse Weight 0.27 lb (0.12 kg) Cable length 72.8 in (185 cm)
  • Page 35 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Optical Storage HP SATA SuperMulti Height 5.25-inch, half-height, tray-load LightScribe DVD Writer Orientation Either horizontal or vertical Drive Interface type SATA/ATAPI Disc capacity 8.5 GB DL or 4.7 GB standard Dimensions (W x H x D) 5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm) Weight (max) 2.6 lb (1.2 kg)

  • Page 36: Technical Specifications - Optical Storage

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Optical Storage SATA CD-RW/DVD- Height 5.25-inch, half-height, tray-load ROM Combo Drive Orientation Either horizontal or vertical Interface type SATA/ATAPI Disc capacity Single layer: Up to 4.7 GB (6 times capacity of CD-ROM) Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
  • Page 37 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Optical Storage Media Compatibility – CD-ROM DVD-ROM CD-R CD-RW DVD-ROM DVD-ROM DL DVD-RAM DVD+R DVD+R DL DVD+RW DVD-R DVD-RW DVD-R DL Access times Random DVD: < 140 ms (typical), CD: < 125 ms...

  • Page 38: Technical Specifications - Removable Storage

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Removable Storage HP 16-in-1 Media Card USB Interface USB 2.0 High-speed device Reader Advance protocol Supports hardware ECC (Error Correction Code) function support Supports hardware CRC (Cyclic Redundancy Check) function Supports MS 4-bit parallel transfer mode...

  • Page 39: Technical Specifications - Environmental Data

    QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Environmental Data Eco-Label This product has received or is in the process of being certified to the following approvals and may Certifications and be labeled with one or more of these marks:...
  • Page 40 This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of 1986). This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. This product is in compliance with the IEEE 1680 (EPEAT) standard at the GOLD level, see http://www.epeat.net...
  • Page 41 QuickSpecs HP Compaq dc5800 Business PC Technical Specifications - Environmental Data The EPE foam packaging material is made from 30 to 60% industrial recycled content. The corrugated paper packaging materials contain at least 80% post consumer recycled content. Minitower System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for the Minitower Desktop model is based on a typically configured product.
  • Page 42 European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances were virtually eliminated (virtually = to...
  • Page 43 Recycling HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers.
  • Page 44 Intel and Pentium are U.S. registered trademarks of Intel Corporation. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
