Wall Mounting (Optional)

To obtain a wall-mounting kit or height adjustment base, contact ViewSonic
dealer. Refer to the instructions that come with the base mounting kit. To convert your LCD
display from a desk-mounted to a wall-mounted display, do the following:
Step 1. Verify that the power button is turned Off, then disconnect the power cord.
Step 2. Lay the LCD display face down on a towel or blanket.
Step 3. Remove the two screws attaching the base.
Step 4. Attach the mounting bracket from the VESA compatible wall mounting kit (100 mm
Step 5. Attach the LCD display to the wall, following the instructions in the wall-mounting
Downloaded from
www.Manualslib.com
x 100 mm distance), using screws of correct length.
kit.
manuals search engine
For use only with UL Listed Wall Mount Bracket
Step 3. Two screws
attaching the base
7
or your local
®
Step 4. Four VESA
screw holes
