- Page 1 REFRIGERADOR CONGELADOR FRIDGE-FREEZER ZFK 22/10 LP LIBRO DE INSTRUCCIONES INSTRUCTION BOOKLET 2222 138-76...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. - Page 3 Please fill in the necessary details on the Card Appliance height: Certificate and send it to the Zanussi Centre covering 1700 mm the area in which the appliance is to be installed. (See list of Zanussi network centres).
-
Page 4: Table Of Contents
CONTENTS Installation Servicing Location Cleaning the interior Door reversibility Fitting door panels Technical specification Electrical connection Control panel Use of the freezer Storing of frozen foods Fast freezing Warning light Freezing of fresh foods Storage of frozen food Thawing Ice cube trays Use of the refrigerator Operation Air circulation... -
Page 5: Installation
INSTALLATION If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock on the door or lid, be sure to make that spring lock unusable before you discard the old appliance. This will prevent it from becoming a death-trap for a child. -
Page 6: Cleaning The Interior
Important It is essential that the appliance be connected to an efficient earth tap. For this purpose the supply cable plug incorporates a special earth contact. If the sockets of your domestic wiring system are not earthed, have the appliance connected to a separate earth wire by a qualified electrician in accordance with existing safety regulations. -
Page 7: Door Reversibility
Door reversibility Fig. 2 Unplug the appliance from the power supply before carrying out the below-mentioned operations. Remove the ventilation grill (D). Unscrew the bottom hinge (E). Remove the freezer door by releasing it from the middle hinge (H). Unscrew the middle hinge. D071 Remove the fridge door by releasing it from the top hinge pin (A). -
Page 8: Technical Specification
TECHNICAL SPECIFICATION The technical data is indicated in the rating plate on the left side inside the appliance. Electrical connection Before plugging in, ensure that the voltage and frequency shown on the serial number plate correspond to your domestic power supply. Voltage can vary by 6% of the rated voltage. -
Page 9: Use
Control panel (Fig. 6) A B C Fig. 6 A - Freezer pilot light B - SUPER operating control light C - Temperature warning light D - Freezer compartment thermostat knob E - NORMAL/SUPER knob F - Refrigerator compartment thermostat knob G - Refrigerator pilot light USE OF THE FREEZER Freezer operation can be halted by turning knob (D) -
Page 10: Storage Of Frozen Food
on the fast-freeze setting for at least 24 hours before pictures of different types of food followed by a the food is put in the freezer. Once the food has been figure. These figures indicate the maximum storage placed in the freezer, the freezing operation can be time, in months, for each type of food. -
Page 11: Thawing
Thawing Air circulation Before being used, deep-frozen and frozen food can Your appliance is fitted with a fan inside the be thawed out either in the refrigerator or at room refrigerator compartment. To tun it on, press the temperature, depending on the time available for this switch (A-Fig. -
Page 12: Fresh Food Refrigeration
Fresh food refrigeration To obtain the best performance: do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Position food so that air can circulate freely round it. Useful hints: Meat (all types): wrap in polythene bags and place on the glass shelf above the vegetable drawer. -
Page 13: Positioning The Door Shelves
Positioning the door shelves To permit storage of food packages of various sizes, Fig. 9 the door shelves can be adjusted in height. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required (Fig. -
Page 14: Defrosting
Defrosting Fig. 11 Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough (Fig. 11) into a special container on the back of the appliance, where it evaporates. -
Page 15: Maintenance
MAINTENANCE Interior light Unplug the appliance before carrying out any maintenance operation. The light bulb inside the refrigerator compartment can be reached as follows: Periodic cleaning - unscrew the light cover securing screw, - unhook the moving part as shown in the figure. Wash the interior with lukewarm water and sodium Fig.
