  • Page 1 REFRIGERATOR- FREEZER ZFK 62/23 RF INSTRUCTION BOOKLET 2222 156-11/1...
  • Page 2: General Safety

    This product should be serviced by an authorised ZANUSSI Service Centre, and only genuine spare parts should be used. Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning.
  • Page 3: Environment Protection

    Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. Avoid damaging the cooling unit, especially at the rear near the heat exchanger.
  • Page 4: Table Of Contents

    Description of the appliance Installation Positioning Rear spacers The electrical connections Technical specification Door reversal directions Operation Setting the temperature Ambient temperature switch The freezer compartment Freezing fresh food Thawing Making ice cubes Health and safety guidelines Fresh food refrigeration Dual purpose meat box Positioning the door shelf Drink dispenser...
  • Page 5: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE A -Thermostat control for fridge and freezer compartments B -Dairy compartment C -Can storage shelfs with egg trays D -Drink dispenser E -Bottle storage shelf F -Freezer calender (recommended storage times for frozen foods) and produce storage card (write on / wipe off card for recording what has been stored in the freezer and when) G -Freezing fresh foods H -Storing frozen food...
  • Page 6: Installation

    Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
  • Page 7: Before Using

    The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which accompanies your instruction manual.
  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY* GROSS CAPACITY NET CAPACITY STAR RATING * This figure is based on standard test results in accordance with European Standard EN153. Actual consumption will depend on how the appliance is used and where it is located. Height Width 54.5 cm...
  • Page 9: Door Reversal Directions

    Door reversal directions Unplug the appliance from the power supply before carrying out the below-mentioned operations. Remove the ventilation grill (D). Unscrew the bottom hinge (E). Remove the freezer door by releasing it from the middle hinge (H). Unscrew the middle hinge. Remove the fridge door by releasing it from the top hinge pin (A).
  • Page 10: Operation

    Setting the temperature The temperature inside the refrigerator and freezer is regulated by a single thermostat with 6 temperature positions and one «OFF» ( O ) position. Position 1 = minimum cold Position 6 = maximum cold Turn the thermostat dial to the required position; the intermediate position is usually the most suitable.
  • Page 11: Health And Safety Guidelines

    HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
  • Page 12: Fresh Food Refrigeration

    Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them.
  • Page 13: Drink Dispenser

    Drink dispenser The container for cooling drinks (Fig. 9) is located in the door of the fridge. It is easily removed from its runners for filling and cleaning by pushing it upwards from the left side and then by pulling sharply outwards.
  • Page 14: Cool Check Temperature Guide

    During everyday use a fridge door is opened many times and as a result temperature fluctuation may occur. A Zanussi fridge is designed to cope with any changes in temperature but under certain conditions the temperature guide in the appliance may show TOO WARM.
  • Page 15: Defrosting

    Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. Important Fig. 12 To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the fruit and vegetable drawer.
  • Page 16: Maintenance And Cleaning

    Unscrew the light cover and then pull it outward toward the middle of the cabinet. Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Zanussi Service Centre). Replace the light cover by sliding it into its original Fig. 13 position and replacing the screw.
  • Page 17: What Happens If Something Goes Wrong

    Other points to check... If, after the above checks, there is still a fault, call your local Zanussi Service Centre, whose address can be found in the accompanying Customer Care Booklet, and can also be found in your local telephone directory under «Z». Please make sure you give the model and serial number of the appliance.
  • Page 18: Peace Of Mind For Twelve Months

    This guarantee is in addition to your statutory and other legal rights. We, Zanussi Ltd., undertake that if, within twelve months of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials,...
