Mackie C200 Specifications

C200
Featuring legendary Mackie sound quality and durability, the
lightweight C Series 2-way Precision Passive loudspeakers
deliver optimum performance in portable PA, stage
monitor and permanent installation applications. The C200
is a full-range portable loudspeaker providing high-output,
ultra-wide dispersion and low-distortion performance in a
compact, composite molded enclosure.
A heat-treated titanium compression driver directs pristine
highs through an exponential high-frequency waveguide,
allowing for ultra-wide dispersion of highs and mids. This
allows the C200 to deliver clear, smooth sound to audience
members up to 45° off axis.
The custom-designed high-power 10-inch woofer with a
2-inch voice coil allows the driver to run cooler, delivering
consistent performance even after long hours of use at near
peak volumes.
The crossover in the C200 is a unique Low Impedance
Compensated Crossover (LICC) design with an asymmetrical
slope. With EQ and crossover points meticulously chosen so
that beamwidth patterns match in both drivers, C200
loudspeakers offer natural sound at all volume levels.
The center of gravity, handle locations, handle design,
position of fly-points and ease of use have been
ergonomically designed. There is also an integrated pole
mount on the bottom of the cabinet and a weather-resistant
steel grille. The asymmetrical trapezoidal cabinet has been
designed to provide an ideal floor monitoring position.
The cabinet is constructed of high-pressure injected
polypropylene. The enclosure features reinforcement ribbing
and structural strengthening resulting in a strong, super-
rigid design providing ideal acoustical characteristics.
APPLICATIONS
Small club/band PA systems, houses of worship,
DJs, vocal/band monitor wedges, gymnasiums, banquet
halls, conference rooms and many, many more.
C200
FEATURES:
2-way portable Precision Passive loudspeaker system
■
500W peak / 200W RMS power handling at 8
■
10" long-throw low-frequency transducer with
■
2" voice coil
High-output 1.4" titanium compression driver
■
Ultra-wide, smooth dispersion via HF horn design
■
Integrated Low Impedance Compensated Crossover (LICC)
■
with full driver protection
Lightweight for ultimate portability (26 lb / 11.8 kg)
■
Asymmetrical trapezoidal cabinet for floor monitor
■
positioning
Stand / Pole-mountable
■
Flyable via optional hanging bracket kit
■
PRECISION PASSIVE
LOUDSPEAKER
1/6 PAGES
