Use and Care Manual
N58L00001.eps N58FCFEFA2.eps N58RCCBBC5.eps N58BAAAAB2.eps
N58SKDJBD1.eps N58TCAAAB0.eps N58CAAAAC3.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241622001.eps W241660401.eps S241622001.eps
S241660401.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GLHS68EESB0 GLHS68EESB3 GLHS68EESB5
Series
R134a Gallery
Color
stain/blk
Volts
115
Wiring Diagram
241622001
Owner's Guide
241622401
Market
North America
Energy Guide
241649206
Service Data Sheet 240389620
Publication No.
5995439576
05/06/15
(EN/SERVICE/DCS)
357
R134a Gallery
R134a Gallery
stain/blk
stain/blk
115
115
241660401
241660401
241622401
241622401
North America
North America
241649206
241649206
240389623
240389623
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GLHS68EE
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire GLHS68EESB0
Summary of Contents for Frigidaire GLHS68EESB0
- Page 1 Product No. GLHS68EESB0 GLHS68EESB3 GLHS68EESB5 Series R134a Gallery R134a Gallery R134a Gallery Color stain/blk stain/blk stain/blk Volts Wiring Diagram 241622001 241660401 241660401 Owner's Guide 241622401 241622401 241622401 Market North America North America North America Energy Guide 241649206 241649206 241649206 Service Data Sheet 240389620...
-
Page 2: Freezer Door
Publication No: 5995439576 GLHS68EE FREEZER DOOR N58FCFEFA2 06/05... - Page 3 GLHS68EE Publication No: 5995439576 FREEZER DOOR Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 240390606 A - - Gasket-frzr door, black, magnetic 241569806 - B C Gasket-frzr door, black, magnetic 240334201 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995439576 GLHS68EE REFRIGERATOR DOOR 06/05... - Page 5 GLHS68EE Publication No: 5995439576 REFRIGERATOR DOOR Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 240390605 A - - Gasket-refr door, black, magnetic 241569805 - B C Gasket-refr door, black, magnetic 240323002 A B C...
- Page 6 Publication No: 5995439576 GLHS68EE CABINET N58BAAAAB2 06/05...
- Page 7 GLHS68EE Publication No: 5995439576 CABINET Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 240435908 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test...
- Page 8 Publication No: 5995439576 GLHS68EE SHELVES 140A N58SKDJBD1 06/05...
- Page 9 GLHS68EE Publication No: 5995439576 SHELVES Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 241510604 A B C Trim-basket 240350668 A B C Shelf-freezer, glass, lower 240350667 A B C Shelf-freezer, glass, upper...
- Page 10 Publication No: 5995439576 GLHS68EE CONTROLS N58TCAAAB0 06/05...
- Page 11 GLHS68EE Publication No: 5995439576 CONTROLS Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft...
- Page 12 Publication No: 5995439576 GLHS68EE SYSTEM N58CAAAAC3 06/05...
- Page 13 GLHS68EE Publication No: 5995439576 SYSTEM Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System...
-
Page 14: Ice And Water Dispenser
Publication No: 5995439576 GLHS68EE ICE & WATER DISPENSER 06/05... - Page 15 GLHS68EE Publication No: 5995439576 ICE & WATER DISPENSER Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker...
-
Page 16: Ice Container
Publication No: 5995439576 GLHS68EE ICE CONTAINER 37A 34 34 33 N58YDAAAC0 06/05... - Page 17 GLHS68EE Publication No: 5995439576 ICE CONTAINER Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 241561301 A B C Container-ice, bucket only 5304404346...
-
Page 18: Ice Maker
Publication No: 5995439576 GLHS68EE ICE MAKER INSTALLATION PARTS N58I115T 06/05... - Page 19 GLHS68EE Publication No: 5995439576 ICE MAKER Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C...
- Page 20 Publication No: 5995439576 GLHS68EE ICE MAKER INSTALLATION PARTS N58I115T 06/05...
- Page 21 GLHS68EE Publication No: 5995439576 ICE MAKER Model Index: A GLHS68EES (GLHS68EESB0) B GLHS68EES (GLHS68EESB3) C GLHS68EES (GLHS68EESB5) POS. NO PART NO. DESCRIPTION 240363601 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2)
-
Page 22: Wiring Schematic
Publication No: 5995439576 GLHS68EE WIRING SCHEMATIC ( L I N E ) ( N E U T R A L ) D A M P E R M OTO R E VA P. FA N D E F R O S T C O I L H E AT E R T H E R M . - Page 23 GLHS68EE Publication No: 5995439576 WIRING SCHEMATIC 06/05 # Functional Parts * Non-Illustrated Parts...
-
Page 24: Wiring Diagram
Publication No: 5995439576 GLHS68EE WIRING DIAGRAM LT. B L U Y E L / R E D D I O D E D I O D E S E E C O M P R E S S O R W I R I N G G R N / Y E L P U R P L E... - Page 25 GLHS68EE Publication No: 5995439576 WIRING DIAGRAM 06/05 # Functional Parts * Non-Illustrated Parts...
