Frigidaire GLHS68EF Factory Parts Catalog
Frigidaire glhs68ef: supplementary guide
Hide thumbs
Also See for GLHS68EF:
- Factory parts catalog (24 pages) ,
- Factory parts catalog (24 pages)
Table of Contents
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389623
N58L00001.eps N58FCFEFA3.eps N58RCFAAA0.eps N58BAAAAB5.eps
N58SKDJBD13.eps N58TCAAAB3.eps N58CAAAAC11.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241660401.eps S241660401.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
GLHS68EFB1 GLHS68EFQ1 GLHS68EFW1 GLHS68EFPB1 GLHS68EFPW1
R134a Gallery R134a Gallery R134a Gallery R134a Gallery
black
bisque
white
115
115
115
241660401
241660401
241660401
241695101
241695101
241695101
North America North America North America North America
241649232
241649232
241649232
240389623
240389623
Publication No.
5995464103
06/03/27
(EN/SERVICE/DCS)
137
R134a Gallery
black smooth
white smooth
115
115
241660401
241660401
241695101
241695101
North America
241649233
241649233
240389623
240389623
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GLHS68EF
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire GLHS68EF
Summary of Contents for Frigidaire GLHS68EF
- Page 1 241660401 241660401 241695101 241695101 241695101 241649232 241649232 241649233 240389623 240389623 240389623 SIDE-BY-SIDE REFRIGERATOR Model No. GLHS68EF Publication No. 5995464103 06/03/27 (EN/SERVICE/DCS) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved. R134a Gallery white smooth 241660401 241695101 North America 241649233...
-
Page 2: Freezer Door
Publication No: 5995464103 Stainless Handle Stainless Handle Stainless Handle 03/06 GLHS68EF FREEZER DOOR N58FCFEFA3... - Page 3 218755503 240352102 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GLHS68EF FREEZER DOOR A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A - - D - Gasket-frzr door, black, magnetic - B C - E...
-
Page 4: Refrigerator Door
Publication No: 5995464103 03/06 GLHS68EF REFRIGERATOR DOOR Stainless Handle N58RCFAAA0... - Page 5 218396700 215503200 218755402 218755503 # Functional Parts * Non-Illustrated Parts GLHS68EF REFRIGERATOR DOOR A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A - - D - Gasket-refr door, black, magnetic - B C - E...
- Page 6 Publication No: 5995464103 03/06 GLHS68EF CABINET N58BAAAAB5...
- Page 7 240479601 5303321321 5304414035 5303321319 # Functional Parts * Non-Illustrated Parts GLHS68EF CABINET A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Cover-air duct A B C D E...
- Page 8 Publication No: 5995464103 03/06 GLHS68EF SHELVES 140A N58SKDJBD13...
- Page 9 240430501 140A 240430503 240585404 240582701 # Functional Parts * Non-Illustrated Parts GLHS68EF SHELVES A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Trim-basket A B C D E...
- Page 10 Publication No: 5995464103 03/06 GLHS68EF CONTROLS N58TCAAAB3...
- Page 11 240397502 199* 240398401 240397601 # Functional Parts * Non-Illustrated Parts GLHS68EF CONTROLS A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Fan Blade, red, evaporator fan A B C D E Washer, "slinger", nylon, evap fan shaft...
- Page 12 Publication No: 5995464103 GLHS68EF SYSTEM N58CAAAAC11 03/06...
- Page 13 5303316859 5304421068 240553501 5303918222 5303918328 # Functional Parts * Non-Illustrated Parts GLHS68EF SYSTEM A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Condenser A B C D E...
-
Page 14: Ice And Water Dispenser
Publication No: 5995464103 GLHS68EF ICE & WATER DISPENSER 03/06... - Page 15 5304421831 5304421850 5303918256 5304426535 # Functional Parts * Non-Illustrated Parts GLHS68EF ICE & WATER DISPENSER A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
-
Page 16: Ice Container
Publication No: 5995464103 03/06 GLHS68EF ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 241561502 215005100 241551601 241561601 # Functional Parts * Non-Illustrated Parts GLHS68EF ICE CONTAINER A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Auger-ice A B C D E...
-
Page 18: Ice Maker
Publication No: 5995464103 GLHS68EF ICE MAKER 03/06... - Page 19 241523503 55 # 240531101 218709100 # Functional Parts * Non-Illustrated Parts GLHS68EF ICE MAKER A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
- Page 20 Publication No: 5995464103 GLHS68EF ICE MAKER 03/06...
- Page 21 218888001 241583301 241587402 241696501 # Functional Parts * Non-Illustrated Parts GLHS68EF ICE MAKER A GLHS68EF (GLHS68EFB1) B GLHS68EF (GLHS68EFQ1) C GLHS68EF (GLHS68EFW1) D GLHS68EF (GLHS68EFPB1) E GLHS68EF (GLHS68EFPW1) DESCRIPTION A B C D E Screw-shoulder A B C D E...
-
Page 22: Wiring Schematic
Publication No: 5995464103 GLHS68EF WIRING SCHEMATIC 03/06... -
Page 23: Wiring Diagram
GLHS68EF Publication No: 5995464103 WIRING DIAGRAM 03/06 # Functional Parts * Non-Illustrated Parts...
