Summary of Contents for Zanussi FLD606
-
Page 1: Washing Machine
LAVADORA WASHING MACHINE FLD 606-FLD 806 MANUAL DE USO USER MANUAL 132995230... - Page 2 Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged.
-
Page 3: Table Of Contents
Contents Warnings 25-26 Maintenance Bodywork Disposal Detergent dispenser drawer Drain filter Tips for environmental protection 26 Water inlet filter Emergency emptying out Technical specifications Frost precautions Installation Something not working? 42-43 Unpacking Positioning Water inlet Water drainage Electrical connection Door reversal Your new washing machine Description of the appliance Detergent dispenser drawer... -
Page 4: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • Leave the porthole door slightly ajar when the appliance is not in use. This preserves the door •... -
Page 5: Disposal
Child safety • Keep all detergents in a safe place out of children’s reach. • Children are often not aware of how dangerous • Make sure that children or pets do not climb into electrical appliances can be. When the machine is the drum. -
Page 6: Technical Specifications
Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 60 cm MAXIMUM LOAD Cotton 4,5 kg Synthetics Delicates Woollens SPIN SPEED 600 rpm max. (FLD 606) 800 rpm max. (FLD 806) POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2200 W MINIMUM FUSE PROTECTION 10 A... -
Page 7: Installation
Installation Unpacking 6. Plug the open holes with the plugs which you will find in the envelope containing the instruction booklet. All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. -
Page 8: Water Drainage
The inlet hose must not be lengthened. If it is too Electrical connection short and you do not wish to move the tap, you will This machine is designed to operate on a 220-230 V, have to purchase a new, longer hose specially single-phase, 50 Hz supply. -
Page 9: Door Reversal
Door reversal The opening direction of the outer door on this washing machine can be reversed. To carry out this operation, proceed as follows: 1) Disengage the end of the opening stop (1) from the door and turn it through 90° to remove it from its seat (Fig. -
Page 10: Your New Washing Machine
Your new washing machine This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. • The temperature selector dial will allow you to choose the most suitable temperature for your laundry. •... -
Page 11: Use
Control panel 1 Programme chart 5 On/Off button It will help you to choose the most suitable washing Press this button to start the machine. The same programme for your laundry. button is used to switch the machine off. Before selecting a programme or changing an 2 Spin speed reduction button ongoing programme the machine must be switched off by depressing the On/Off button. -
Page 12: Washing Hints
Synthetics: drum no more than half full; Washing hints Delicate fabrics and woollens: drum no more than one third full. Sorting the laundry Washing a maximum load makes the most efficient use of water and energy. Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. -
Page 13: Detergents And Additives
Ball point pen and glue: moisten with acetone (*), The bleaching agent (chlorine) can be used only for lay the garment on a soft cloth and dab the stain. white or fast coloured cotton and linen items. Pour it into the compartment marked Lipstick: moisten with acetone as above, then treat stains with methylated spirits. -
Page 14: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 15: Operating Sequence
4. Select the temperature Operating sequence Turn the selector dial to the required temperature setting. Before washing your first load of laundry, we FLD 606 FLD 806 recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. -
Page 16: At The End Of The Programme
7. At the end of the programme The machine stops automatically. The mains on light goes out. If you have selected a programme which ends with the water of the last rinse left in the tub (option drain the water before opening the door. Select programme “R”... -
Page 17: Washing Programmes
Programme table Washing programmes for cotton and linen Load: 4.5 kg Addi- Consumptions* tional Programme Temp. Fabrics func- Energy Water Duration tions min. 60°-90° WHITES WITH PREWASH, for example work garments, sheets, household linen, underwear, towels 40°-60° FAST COLOUREDS WITH PREWASH, for example sheets, terry cloths, tablecloths 60°-90°... -
Page 18: Washing Programmes
Programme table Washing programmes for synthetics, mixed fabrics, delicates and wool Load: 2 kg, wool 1 kg Addi- Consumptions* tional Programme Temp. Fabrics func- Energy Water Duration tions min. 30°-60° SYNTHETICS WITH PREWASH, for example underwear, coloured items, shirts, blouses SYNTHETICS WITHOUT PRE- 30°-60°... -
Page 19: Maintenance
Maintenance 1. Bodywork 3. Drain filter Clean the outside of the machine with warm water The drain filter collects threads and small objects and a neutral, non-abrasive household detergent. inadvertently left in the laundry. Check regularly that Rinse with clean water and dry with a soft cloth. the filter is clean. -
Page 20: Emergency Emptying Out
5. Emergency emptying out If the water is not discharged (outlet pump is blocked, filter or drain hose are clogged), proceed as follows to empty out the machine: • pull out the plug from the power socket; • close the water tap; •... -
Page 21: Something Not Working
Something not working? Problems which you can resolve yourself. Problem Possible cause • The door is not firmly closed. • The machine does not start up: • The machine is not plugged in or there is no power at the socket. •... - Page 22 Problem Possible cause • Spinning starts late or the • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in machine does not spin: the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
