Summary of Contents for Zanussi ZDTL 200
- Page 1 User manual Dishwasher ZDTL 200...
-
Page 2: Table Of Contents
Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document. -
Page 3: Safety Information
Safety information • Under no circumstances should you attempt In the interest of your safety and to ensure the to repair the machine yourself. Repairs car- correct use, before installing and first using the ried out by inexperienced persons will cause appliance, read this user manual carefully, in- injury or serious malfunctioning. -
Page 4: Control Panel
Installation or if the control panel, work top or plinth area are damaged such that the inside of the ap- • Check your dishwasher for any transport pliance is freely accessible. Contact your damage. Never connect a damaged ma- local Service Force centre, in order to avoid chine. -
Page 5: Setting Mode
Setting mode the appliance MUST be in setting mode. If a programme light is illuminated and End of The appliance is in setting mode when all programme light is illuminated with fixed light, programme lights are off and End of pro- the last performed programme is still set. - Page 6 Programme selection/cancel button • Starting the washing programme: 1. Press the On-Off button. 2. Press the Programme selection/cancel button once, the light of the last performed washing pro- gramme illuminates and the End of programme light flashes. 3. Press the Programme selection/cancel button as many times as necessary to illuminate the light corresponding to the desired programme.
-
Page 7: Washing Programmes
Indicator lights Salt Illuminates when the special salt has run out. Is never illuminated while a washing programme is running. 4. After a few seconds: Audible signals – programme light A turns off Audible signals have been introduced to help –... -
Page 8: First Use
Programme Degree of soil Type of load Programme description Normal 65° Normal soil Crockery, cutlery, pots Prewash and pans Main wash 2 intermediate rinses Final rinse Drying Light soil Crockery and cutlery Main wash Final rinse 65° A 30' Normal soil Crockery and cutlery Prewash BIO 50°... -
Page 9: Set The Water Softener
IMPORTANT! – Fill up the salt and rinse aid container. – Adjust the water hardness setting to the If the drying results are not satisfactory we rec- highest level and perform 1 normal washing ommend that you: programme without loading any dishes. 1. -
Page 10: Use Of Dishwasher Salt
Setting the water softener manually (see table) The water softener is factory set at position 2. Set switch to position 1 or current level set. The flashing is repea- Setting the water softener ted with a pause of a few seconds. electronically (see table) Examples: 5 flashes, pause, 5 flashes, pause, etc... - Page 11 Unscrew the cap. Only before filling with Using the funnel provided, salt for the first time, fill pour in the salt until the the salt container with wa- container is filled with salt. ter. IMPORTANT! Immediately start a complete programme. IMPORTANT! Water will overflow from the container as salt is added.
-
Page 12: Use Of Rinse Aid
Use of rinse aid Open the lid. Fill up with rinse aid. The Clean up any rinse aid maximum level for filling is which overflows. Close indicated by "max" the lid and press until it locks. IMPORTANT! CAUTION! Top up the rinse aid when the light on the control panel Never fill the rinse aid dispenser with any other sub- illuminates. - Page 13 • Before loading the dishes, you should: – To avoid damage to glasses, they must not touch. – Remove all left over food and debris. – Lay small objects in the cutlery basket. – Soften remnants of burnt food in pans •...
- Page 14 Load cutlery. For best re- Place knives and other The cutlery basket is in two parts which can be sepa- sults we recommend you items of cutlery with sharp rated to give greater loading flexibility. To separate to use the cutlery grid pro- points or edges with their the two parts, slide them horizontally in opposite di- vided (if the size and di-...
-
Page 15: Use Of Detergent
Adjusting the height of the upper basket If washing very large plates you can load them in the lower basket after moving the upper bas- ket to the higher position. Maximum height of the dishes in : upper basket lower basket With upper basket raised 22 cm 33 cm... -
Page 16: Unloading The Dishwasher
Open the lid. Fill in the detergent in Observe the dosing lev- compartment A. els. For programmes with pre- When using detergent Close the lid. wash add an additional tablets: place detergent detergent dose in com- tablets in compartment A. partmentB. -
Page 17: Care And Cleaning
Care and cleaning Cleaning the filters IMPORTANT! NEVER use the dishwasher without filters. In- correct repositioning and fitting of the filters will produce poor washing results. Turn the handle about 1/4 Clean filters A, B and C Remove filter A from the turn anticlockwise and re- thoroughly under running base of the washing com-... -
Page 18: Environmental Concerns
Internal cleaning unavoidable, empty the machine, close the ap- pliance door, disconnect the water inlet pipe Ensure that the seals around the door, the de- and empty it. tergent and rinse aid dispensers are cleaned regularly with a damp cloth. Moving the machine We recommend every 3 months to run the wash If you have to move the machine (moving house... -
Page 19: What To Do If
correctly, you will help prevent potential nega- recycling of this product, please contact your tive consequences for the environment and local council, your household waste disposal human health, which could otherwise be service or the shop where you purchased the caused by inappropriate waste handling of this product. - Page 20 Fault code and malfunction Possible cause and solution The programme does not start. • The dishwasher door has not been properly closed. Close the door. • The main plug is not plugged in. Insert the mains plug. • The fuse has blown in the household fuse box. Replace the fuse.
-
Page 21: Technical Data
The wash results are not satisfactory There are streaks, milky spots or a bluish coating on • Decrease rinse aid dosing. glasses and dishes Water drops have dries onto glasses and dishes • Increase rinse aid dosing. • The detergent may be the cause. Contact the de- tergent manufacturer’s consumer care line. -
Page 22: Hints For Test Institutes
Consumption values Programme Programme duration (in Energy consumption (in Water (litres) minutes) kWh) Rinse and Hold Hints for test institutes Testing in accordance with EN 60704 must be aid dispenser have been filled with salt and carried out with appliance fully loaded and us- rinse aid respectively and using the test pro- ing the test programme (see "Consumption gramme (see "Consumption values"). -
Page 23: Installation
Installation Levelling WARNING! Any electrical and/or plumbing work required to Good levelling is essential for correct closure install this appliance should be carried out by a and sealing of the door. qualified electrician and/or plumber or compe- When the appliance is correctly levelled, the tent person. -
Page 24: Drain Hose
If the water inlet hose leaks, the safety valve Therefore do not immerse the water inlet hose cuts off the water supply. or the safety valve in water. Take care when installing the water inlet hose . Place the water inlet hose in such a way that it is always lower than the bottom edge of the safety valve. -
Page 25: Electrical Connection
Electrical connection This could constitute a fire hazard through over- heating. If necessary, have the domestic wiring system CAUTION! socket replaced. In case that the electrical ca- Safety standards require the appliance to be ble has to be replaced, contact your local Serv- earthed. - Page 28 www.electrolux.com 117971240-012008...
