Crown COMMERCIAL AUDIO SERIES Quick Start Manual

CROWN COMMERCIAL AUDIO SERIES MIXER-AMPLIFIER
®
ONE ROOM WITH A PAGING MICROPHONE using 180MA or 1160MA
Speakers with 70V transformers
Amp Config
DIP switch detail
1 OFF
2 ON
3 OFF
4 OFF
5 OFF
6 OFF
7 PHANTOM ON
8 NO FUNCTION
COM
To AC power
TWO ROOMS WITH INDEPENDENT PAGING using 280MA
Mic 1 mutes room-1 TV tuner. Mic 2 mutes room-2 CD player.
Room 2
Speakers with 70V transformers
Amp Config
DIP switch detail
AC
1 OFF
2 ON
3 OFF
4 OFF
5 OFF
6 ON
7 PHANTOM OFF
8 NO FUNCTION
COM
Mute switch
in room-2 mic
QUICK-START GUIDE
Paging mic mutes CD player.
Speakers with 70V transformers
100V Amp Config DIP switch
70V
COM
Priority-switch
detail
Switch in mic mutes CD player
CH 1
Speakers with 70V transformers
11 on, 12 off, 19 off, 20 on
AMP2 AMP1
100V
100V
Amp Config DIP switch
70V 70V
COM COM
Priority-Switch
detail
CH 1 AMP 1
CH 5 AMP 2
Mute switch in room-1
mic mutes TV tuner
Room 1
Input Routing switch detail
4 3
8
Room 1
paging mic
(dynamic)
(OVER)
Detail
MIC
CD player
audio cable
4 3 2 1
CD player
(phantom-powered shown)
Detail
MIC
TV tuner
TV tuner
audio cable
Detail
2 1
7 6 5
Room 2
paging mic
(dynamic)
CD player
Detail
MIC
–
–
To mic
Paging mic
MIC
–
–
To mic
