GLOBALSAT GPS Engine Board
Hardware Data Sheet
Product No : ET-314AC
Version 2.2
Globalsat Technology Corporation
16F., No. 186, Jian-Yi Road, Chung-Ho City, Taipei
Hsien 235, Taiwan
Tel: 886-2-8226-3799 Fax: 886-2-8226-3899
E-mail :
service@globalsat.com.tw
Website:
www.globalsat.com.tw
Issue Date
APPR
CHECK
PREPARE
Ray
Luwalk
Jeff
2010/04/01
2010/4/1
- 1 -
