American Standard Connoisseur 4600.100 Specification Sheet

4600.100 Shown.

GENERAL DESCRIPTION:

Cast brass body with stamped brass escutcheon. Pull-out
swing spray spout. Hose is 4'10" long. Washerless 47mm
ceramic disc valve cartridge.
Complete with two integral check valves. 2.2 gpm/8.3L/min.
maximum flow rate. Fitting can be mounted with or without
supplied escutcheon plate (escutcheon size 10-7/8"L x 2-
1/2"W).
SUGGESTED SPECIFICATION:
Single control kitchen combi faucet shall feature a cast brass body with pull-out spray spout with two check valves. Shall also
feature washerless ceramic disc valve cartridge. Fitting shall be American Standard Model # 4600.100.____
35 to 38mm
(1-3/8 to 1-1/2)
DIA. MOUNTING
HOLE
276mm
(10-7/8)
3/8" O.D. copper supplies.
SINGLE CONTROL KITCHEN COMBI FAUCET
MODEL NUMBER:
4600.100 Kitchen Combi Faucet
Combi body with spray and hose. Escutcheon plate (use is
optional).
203mm
(8)
127mm
(5)
51mm
(2) MAX.

PRODUCT FEATURES:

Brass and Copper Waterway:
durability & long life.
Memory Postion Valving:
off at preferred temperature setting without readjusting handle
position each time.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Ceramic Disc Valve Cartridge:
valve control and a lifetime of drip-free, maintenance-free
performance.
Integral Check Valves:
Pull-out Spray Spout:
spray. Simplifies even the most difficult cleaning tasks.
Choice of Finishes:
Wide range of durable finishes.
235mm
(9-1/4)
127mm
(5)
Highest quality materials for
Allows user to turn valve on and
Assures smooth, precise
Prevents back flow.
Switches water flow from a stream to a
178mm
(7)
