SpeedStream 5400 Series SOHO DSL Router
1 Introduction
®
The SpeedStream 5400 Series 4 Port Ethernet SOHO DSL router is designed for the small
office or home office (SOHO) that needs to share DSL access across a small network. The
®
SpeedStream 5400 Series SOHO DSL router provides four IEEE 802.3/802.3u 10/100BaseT
switch (Ethernet) LAN interfaces toward the local user equipment, and a single ATM-based DSL
interface toward the public network.
Four PCs or workstations can be directly attached to the switch ports, or multiple local devices
can be attached via an external Ethernet hub or switch.
®
The SpeedStream 5400 Series SOHO DSL router supports full routing based functionality.
Among the features supported by the SpeedStream
DNS Relay, NAT, NAPT, UPnP, RFC 2364, RFC 2516, RFC 2864 (Bridged and Routed),
PPPoE Relay/Bridging, static routes, VPN pass-through, and a stateful-inspection firewall with
Denial of Service (DoS) protection.
.
1.1 Legend
Value Description
Yes Supported
No Not Supported
N/A Not Applicable
2 Power, Mechanical, Packaging
2.1 Power
Feature
Input
Output
External AC power supply
External power switch
Power consumption
Efficient Networks, Inc.
®
5400 Series SOHO DSL router are: DHCP,
120VAC, 300mA, 60 Hz
12V/1A
Yes
No
10 watts maximum
Confidential
Comments
Revision 1.3
Page 2 of 12
