- Page 1 Geschirrspüler ZKS 5650 IL Dishwasher Bedienungsanleitung Seite 2 Instruction book page 21...
-
Page 2: Table Of Contents
Contents Safety instructions Maintenance and cleaning Cleaning the filters Disposal Prolonged periods of non-operation Frost precautions Economical and ecological dishwashing Moving the machine Installation instructions What to do, when... Building-in Service and spare parts Levelling Fixing to adjacent units Hints for test centres Water supply connections Water inlet hose with safety valve Water outlet hose connection... -
Page 3: Safety Instructions
Safety instructions It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 4: Installation Instructions
Installation instructions Any electrical and/or plumbing work required to install Water supply connections this appliance should be carried out by a qualified This dishwasher may be fed with either hot (max. 60°) or cold electrician and/or plumber or competent person. water. -
Page 5: Water Outlet Hose Connection
Water outlet hose connection Electrical connection The end of the drain hose can be connected in the following Information concerning the electrical connection is given on the ways: rating plate on the edge of the dishwasher’s door. 1. To the sink outlet spigot, securing it to the underside of the Before plugging the appliance into the wall socket, make sure work surface. -
Page 6: Description Of The Appliance
Description of the appliance Upper basket stop Water hardness dial Salt container Detergent dispenser Control panel Rating plate Rinse aid dispenser Filters Lower spray arm 10. Upper spray arm 11. Upper basket IN153 The control panel Function buttons "3 in 1" button On/Off button Programme selection buttons Indicator lights... -
Page 7: Audible Signals
Audible signals Audible signals have been introduced to help indicate which operations the dishwasher is performing: - Setting of the water softener - End of programme - Something not working with the machine Deactivation/activation of the audible signals (The dishwasher must be switched off) Factory setting: audible signals activated 1. -
Page 8: Prior To Using For The First Time
Prior to using for the first time Before using your dishwasher for the first time: b) Setting electronically (The dishwasher must be switched off) 1. Ensure that the electrical and water connections comply The dishwasher is factory set at level 5. with the installation instructions 2. -
Page 9: Filling With Dishwasher Salt
Filling with dishwasher salt Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in a dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting one of the complete washing programmes. -
Page 10: Rinse Aid
Rinse aid If you are using dishwasher detergent that already contains rinse aid, the detergent including the rinse aid must be Rinse aid is automatically added during the last rinse, ensuring placed in the detergent compartment. thorough rinsing, and spot and streak free drying. In this case the rinse aid dispenser must be deactivated in The dispenser, which is positioned inside the door, holds about orderto avoid a double dosage. -
Page 11: In Daily Use
In daily use Check if it’s necessary to refill with dishwasher salt or rinse Loading cutlery and dishes Sponges, household cloths and any object that can Load cutlery and dishes into the dishwasher. absorb water may not be washed in the dishwasher. Fill with dishwasher detergent . -
Page 12: The Cutlery Basket
The cutlery basket The upper basket The upper basket is designed for plates (dessert plates, Long bladed knives stored in an upright position are a saucers, dinner plates of up to 26 cm in diameter), salad potential hazard. bowls, cups and glasses. Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket. -
Page 13: Use Of Detergent
Use of detergent Only use detergents specifically designed for use in dishwashers. Using no more then the correct amount of detergent contributes to reducing pollution. Please observe the manufacturer’s dosing and storage recommendations as stated on the detergent packaging. Fill with detergent 1. -
Page 14: Different Kinds Of Detergent
Different kinds of detergent Detergent tablets Use of "3 in 1" combi detergents Detergent tablets of different brands dissolve at different General advice speeds. For this reason some detergent tablets cannot These products are detergents with integrated and combined dissolve and develop their full cleaning power during short detergent/rinse-aid and salt functions. -
Page 15: Washing Programmes
Washing programmes Programme Degree of soil Press the Cycle description (3) Consumption values programme Programme Energy Water type of load button consumption consumption duration (in minutes) (in kWh) (in litres) Hot prewash Main wash up to 70°C Heavy soil. 2 warm rinses 80 - 90 1,7 - 1,9 23 - 25... -
Page 16: Starting A Washing Programme
Starting a washing programme In this fully integrated appliance the controls are located on the 6. End of the washing programme top of the door. When selecting a programme, the door needs The dishwasher will automatically stop and an audible to be open. -
Page 17: Maintenance And Cleaning
Maintenance and cleaning Clean the external surfaces of the machine and control panel Attention! with a damp soft cloth. If necessary use only neutral Under no circumstances may the dishwasher be used without detergents. Never use abrasive products, scouring pads or filters. -
Page 18: What To Do, When
What to do, when... Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the instructions given here, without calling out an engineer..a flashing fault code appears The dishwasher will not start or stops during operation. Open the dishwasher door. -
Page 19: Service And Spare Parts
...the wash results are not satisfactory The dishes are not clean The wrong washing programme has been selected. The dishes were arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded. The spray arms do not rotate freely due to wrong arrangement of the load. -
Page 20: Hints For Test Centres
Hints for test centres Testing in accordance with EN 60704 must be carried out with appliance fully loaded and using the test programme (see "Washing programmes" chart). Test in accordance with EN 50242 must be carried out when the salt dispenser and rinse aid container have been filled with salt and rinse aid respectively and using the test programme (see "Washing programmes"... - Page 21 Änderungen vorbehalten 09/04 152960 23/0 Subject to change without notice...
