- Page 1 ® XA8800MNu INSTRUCTIONS POWER AMPLIFIER...
-
Page 2: Important Safety Instruction
XA8800MNu Chapter 1 Important Safety Instruction CAUTION Dangerous Voltage The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Before Use
22. Never operate this product in an explosive atmosphere. 1.2 Check Accessory Unpack your XA8800MNu power amplifier and keep all packing materials for future transport or service, locate and remove all accessory items from the accessory box within the controller shipping carton. -
Page 4: Product Features
POWER POWER XA8800MNu is a mono power amplifier, with full symmetric current negative feedback structure. This model offers the user quality sound reproduction and elegant styling also features excellent look. The amplifying circuitry design follows the well appraised current negative feedback structure, featuring the full symmetric and full complementary circuit. -
Page 5: Front Panel
XA8800MNu Chapter 2 Introduction 2.2 Front Panel POWER The power supply on-off button Press this button, the current will be put through; press it again, the current will be cut off. Power Indicator After getting through, this indicator will wink for 8 seconds and then light. - Page 6 XA8800MNu Chapter 3 Operation Instruction 3.1 Connection Pre-Amplifier NO.: NO.: Right Channel Left Channel XA8800MNu Power Amplifier Connection to Power Supply 1.Before using this machine, you have to connect it to sound sources (such as CD player, DVD player, SACD player) by signal cable.
-
Page 7: Troubleshootings
Speaker wire to channels has exchanged or positive negative reversed Notice: if you have been confronted any problems when using this product or have any suggestion to tell us, please visit the wesite of xindak: http://www.xindak.com , you may access our instant technique support here. -
Page 8: Specifications
XA8800MNu Specifications Chapter 4 4.1 Dimensions Unit: mm POWER... - Page 9 XA8800MNu Specifications Chapter 4 4.2 Specifications < Power output 160W/ch (8ohm Load) < Rated p ower consumption 240W/ch < Frequency response 10Hz - 100KHz < Signal-to-noise ratio 100dB Typical(A Weight) < Distortion <0.03% < Dimensions (W×D×H) 240mm ×148 ×430 <...
- Page 10 No.126, Section 2, East 1 Round Chengdu, Sichuan, China P.C. 610051 You can find your nearest authorized distributor and more product information on our website: www.xindak.com © 2006 XD3.834.065 SMS...
