AcuTab-M7
Rugged Tablet PC
User's Guide
Acura Embedded Systems Inc.
Features
•
Platform: Intel® Cedar Trail Platform (N2600+NM10)
•
GPU: Intel ATOM N2600 1.6GHz Dual core
•
Chipset: Intel® NM10 Express Chipset
•
System Memory: 2GB DDRIII 800 SO-DIMMM
•
Storage: 1 x 32G SATA Slim Half-Size Solid State Disk
•
LCD Panel: 7-inch LED Backlight Screen
7" XGA (1280x800) 400nits LCD, or 500nit
•
Touch Panel 5-wire Resistive Touch Screen
•
Audio: -1 x High Quality Speaker (2W)
-Internal Microphone : 1 x in front Bezel
•
TPM: 1x Compatible with TPM1.2 (option)
•
Communication : 10/100Mbps Ethernet
Wi-Fi IEEE 802.11 a/b/g/n ; Bluetooth 4.0
•
GPS Positioning: GPS/QZSS, GLONASS
50 channel all-in-view tracking
•
Webcam:
Front - 2 Mega-pixel Camera
Rear - 5 Mega-pixel Camera with LED Flash light
•
External I/O:
2 x USB 2.0 (type-A), 1x Micro SD slot, 1x RS232
•
Power Adapter :
AC Input, 100V ~ 240VAC, 50~60Hz
DC Output, 19VDC@3.42A, 65W
•
Battery
Internal Battery - Smart Lithium Polymer Battery, 2900mAH, 7.5V
Mechanical & Environmental
•
Physical Characteristics :
Dimension & Weight : 225 x 168 x 26.5mm ; 850g
•
Rugged Design
Drop : 5ft drop
Vibration : Operating : MIL-STD-810G Method 514.6 Category 4 Fig 514.6C-3
Mechanical Shock : Operating : 20g, 11ms, Terminal sawtooth
Non-operating : 40g, 11ms, Terminal sawtooth
•
Water/Dust Resistance : IP65
•
Environment : Operation temperature : -20°C to +50°C
Storage Temperature : -30°C to +70°C
Humidity : 5-95% without condensation
1
Advertisement
Table of Contents
Related Manuals for Acura Embedded AcuTab-M7
Summary of Contents for Acura Embedded AcuTab-M7
- Page 1 Mechanical Shock : Operating : 20g, 11ms, Terminal sawtooth Non-operating : 40g, 11ms, Terminal sawtooth • Water/Dust Resistance : IP65 • Environment : Operation temperature : -20°C to +50°C Storage Temperature : -30°C to +70°C Acura Embedded Systems Inc. Humidity : 5-95% without condensation...
- Page 2 QR, Aztec, EAN.UCC composite. Viewing AcuTab-M7 Before starting to set up AcuTab-M7, get familiar with the locations and purpose of controls, connectors and I/O ports, which are illustrated in the figures below. When placed upright, the front panel of AcuTab-M7 appears as shown in below.
- Page 3 Camera / 2 Mega-pixel (Front-facing) Switch the computer power on and off, or resumes whenever it is in Suspend mode The built-in camera can be used as a communication device for allowing you to (by OS define). capture images, record videos, and have video chats. It is 2M pixels and can be used for transmitting live image through network for video conference.
-
Page 4: About The User Interface
Please press F1 or F4 function keys to trigger to scan the barcode when the optional barcode scanner snap-on module is installed. AcuTab-M7 has numbers of applications on the control panel for executing specific command. It provides you to adjust brightness, volume, launch webcam, switch monitor If your system does not install this module, these buttons can be programmable to (via docking) and RF device ON/OFF. -
Page 5: System Status Information
If there is no module in the system, there will be no status scale in the following status bar. For battery capacity status: AcuTab-M7 is equipped with one internal battery and one optional external battery. The system information shown on the left shows you the... -
Page 6: Brightness Control
Brightness Control For brightness adjustment, press the Brightness icon. You can click to reduce or increase the audio volume incrementally. Also, you can slide the scale bar to set the audio volume. You can tick the Mute to mute the audio. When you press it, the brightness control panel is appeared as follows: Launch Webcam Utility For Webcam Launch, press the Webcam... - Page 7 Press this soft button (via hotkey utility menu) to enable or disable Wi-Fi, Bluetooth, WWAN, or GPS devices. When you press the RF ON/OFF soft button, the screen pops-up the option list for your selection. You can see all functions in this option list have been ticked. To close any device function, please touch the option to close the execution as shown in the following graphics.
-
Page 8: Using The External Audio System
A keyboard is an input device; a mouse is a pointing device. Please connect these two devices as graphics shown below to interact with your system. Using the External Audio System At the right side of AcuTab-M7, you will find the headphone jack for connecting 3.5mm 4-conductor TRRS (stereo-plus-mic) headphone jack. Bios Setup Program This system comes with a chip from Phoenix BIOS that contains the ROM Setup information for your system. -
Page 9: Advanced Bios Features
The system will automatically displays the information of Total Memory. Advanced BIOS Features For Advanced Settings, it lets you define the device configuration when system booting. The Standard CMOS Setup screen is displayed above. Each feature may have one or more option settings. -
Page 10: Boot Management Setup
“Save changes?” Select [OK] to save all changes. Technical Support With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been set up specifically to Exit Control cater to our esteemed customers' needs.
