AcuTab-M

Quick Guide

Acura Embedded Systems Inc.

Main Features

Platform: Intel® Cedar Trail Platform (N2600+NM10)
GPU: Intel ATOM N2600 1.6GHz Dual core
Chipset: Intel® NM10 Express Chipset
System Memory: 2GB DDRIII 800 SO-DIMMM
Storage: 1 x 32G SATA Slim Half-Size Solid State Disk
LCD Panel: 10.4-inch LED Backlight Screen
10.4" XGA (1024x768) 340nits LCD + T/P(Polarizer + 1/4 λ+ AR)
Touch Panel
5-wire Resistive Touch Screen
Audio: -1 x High Quality Speaker (2W)
-Internal Microphone : 1 x in front Bezel
TPM:
1 x Compatible with TPM1.2 (option)
Communication :
- 10/100Mbps Ethernet (via adapter to mini USB port)
- Wi-Fi IEEE 802.11 a/b/g/n; Bluetooth 4.0
- 3G,4G LTE(Optional)
- Webcam:
Front - 2 Mega-pixel Camera
Rear - 5 Mega-pixel Camera with LED Flash light
- Automatic Focus
- Automatic white balance Power
Adapter :
AC Input, 100V ~ 240VAC, 50~60Hz
DC Output, 19VDC@3.42A, 65W
Battery
Internal Battery - Smart Lithium Polymer Battery, 3800mAH, 7.4V
Mechanical & Environmental
Dimension
Weight
Operation System
OS
Rugged Design
Drop
Water/Dust Resistance
Environment
Operation temperature
Storage Temperature
Humidity
277.8 x 206 x 26.5mm
1.1kg
Windows 7 Pro, WES7P 32bit
6ft drop ploywood on concrete
IP65
-20°C to +50°C
-30°C to +70°C
5-95% without condensation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AcuTab-M and is the answer not in the manual?

Questions and answers

Related Manuals for Acura Embedded AcuTab-M

Summary of Contents for Acura Embedded AcuTab-M

  • Page 1: Main Features

    277.8 x 206 x 26.5mm Weight 1.1kg Operation System Windows 7 Pro, WES7P 32bit Rugged Design Drop 6ft drop ploywood on concrete Water/Dust Resistance IP65 Acura Embedded Systems Inc. Environment Operation temperature -20°C to +50°C Storage Temperature -30°C to +70°C Humidity 5-95% without condensation...
  • Page 2 The built-in camera can be used as a communication device for allowing you to capture images, record videos, and have video chats. It is 2M pixels and transmitting Before starting to set up the AcuTab-M, get familiar with the locations and purposes of instant image through network for conference.
  • Page 3 [Setup] F1_EXE="c:\windows\explorer.exe" External Battery Connector F1_PARA="" To install the External Battery, please remove the cover of external battery connector before F1_PATH="" snap the battery pack into the external battery connector. F2_EXE="C:\Program Files\Windows Media Player\wmplayer.exe" Speaker F2_PARA="/prefetch: 1" Integrated stereo speaker for sound and audio output for your multimedia F2_PATH=""...

  • Page 4: System Status Information

    Enable or disable the User Interface DC-Jack To display the User Interface, please press the Fn button or point the Hotkey Utility icon Lets you connect the AC power adapter in supplying continuous power to AcuTab-M and located on Windows desktop. recharging the battery.
  • Page 5 For battery capacity status: AcuTab-M is equipped with one internal battery and one optional external battery. For System Information: The battery capacity status shown below advises you, that only one internal battery is...

  • Page 6: Powering On For The First Time

    For Webcam Launch, press the Webcam icon to launch the Webcam utility. Or can The Power/Resume button is found on the left side of the AcuTab-M. Press the Power/Resume button to start your system and check that if the Power LED turns on.

  • Page 7: Using A Sim Card

    If you cannot insert the card into the slot or you had inserted the card but it is not recognized by the AcuTab-M, please remove the card and insert it again. To prevent the damage made both on card and the slot, never forced an entry into To install the GPS Module: the slot with incorrect side.

  • Page 8: Main Screen Setup Utility

    Function Key (s) Function Description Moves cursor left to select Screens Moves cursor up or down to select items + / - To change option for the selected items Insert FFC cable of GPS module into connector slot. Screw to secure the GPS module onto the tablet.

  • Page 9: Advanced Bios Features

    Security Configuration System Date To set the date, highlight the Date field and then press +/- keys to set the current date. Follow the month, day and year format. System Time To set the time, highlight the Time field and then press +/- keys to set the current time. Follow the hour, minute, and second format.

  • Page 10: Exit Control

    Exit Control With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been Exit Saving Changes set up specifically to cater to our esteemed customers' needs.
