AcuBrite 21-NAV
User Guide
AcuBrite 21-NAV
User Guide

Overview

ACUBRITE ™ 21-NAV
ACUBRITE ™ 21-NAV, the high-performance, rugged touch monitor, is specially
engineered to survive from the most demanding working environment. Housed in a
milled billet aluminum case, the slim-profile ACUBRITE ™ 21-NAV is light weight
Sunlight Readable
and watertight. The front-mounted sunlight readable touch screen makes the
Marine Certified Monitor
industrial rugged
monitor vividly and user-friendly. In addition, the high power
efficiency and low heat design guarantee the stability and longevity required for
mission critical deployment.
User's Guide
Edition 1.0
Main Features
- 1000 nits Sunlight Readable LCD
- Long Life, Low Power Consumption LED Backlight
- Wide Operating Temperature
- Picture In Picture Function
- Advanced Optical Bonding (AOT)
- High Shock & Vibration Resistance
- Resistive Touch Support
- IP65 Facial Waterproof
- 9-36V DC Input
Application:
- Marine
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACUBRITE 21-NAV and is the answer not in the manual?

Questions and answers

Related Manuals for Acura Embedded ACUBRITE 21-NAV

Summary of Contents for Acura Embedded ACUBRITE 21-NAV

  • Page 1 AcuBrite 21-NAV User Guide AcuBrite 21-NAV User Guide Overview ACUBRITE ™ 21-NAV ACUBRITE ™ 21-NAV, the high-performance, rugged touch monitor, is specially engineered to survive from the most demanding working environment. Housed in a milled billet aluminum case, the slim-profile ACUBRITE ™ 21-NAV is light weight Sunlight Readable and watertight.
  • Page 2 AcuBrite 21-NAV User Guide AcuBrite 21-NAV User Guide Rear connections CONNECTIONS AND CONTROL FEATURES 1.Fuse 2. Power Input 3. DVI-1 Input 4.DVI-2 Input 5. VGA-Input 6. VGA-2 Input 7. CVBS-1 Input (Composite Video ) AV Input 8. CVBS-2 Input 9. CVBS-3 Input 10.

  • Page 3: Control Panel

    AcuBrite 21-NAV User Guide AcuBrite 21-NAV User Guide Control panel / DOWN It works as menu item selection use, the “UP”KEY can be used as “RIGHT” KEY and the “DOWN” KEY can be used as “LEFT”KEY. PIP (1~10) Picture You can press “RIGHT /LEFT” key to move PIP...
  • Page 4 AcuBrite 21-NAV User Guide AcuBrite 21-NAV User Guide DVI 1 & 2’s setting screen: RGB1 & 2’s setting screen: DVI Setting Item Description: ・ CONTRAST ――― Contrast adjustment ・ R_LEVEL ――― Red Color level Adjustment RGB Setting Item Description: ・ G_LEVEL ―――...
  • Page 5 AcuBrite 21-NAV User Guide AcuBrite 21-NAV User Guide PIP Sub-menu setting screen: NIGHT MODE KEY When you press the “NIGHT MODE” KEY, the dimming will be down to under 0.5 nit directly. And if you press “BRIGHTNESS” KEY or “VR” knob at this moment, it will be no function until you press the “NIGHT MODE”...

  • Page 6: Technical Support

    Location: _________________________________ Serial Number: ____________________________ VIN Number: ______________________________ With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special Unit Number: ____________ customer service unit has been set up specifically to cater to our esteemed customers' needs.
