Page 2: Table Of Contents
CONTENTS Installation ........... 3 Previewing all tracks......8 DIN Front-Mount (Method A)....3 Repeating the same track ....8 Installing the unit ....... 3 Playing all tracks in random....8 Selecting tracks by AS/PS/Navi-SCH Removing the unit ......3 button ..........8 DIN Rear-Mount (Method B) ....3 Display information......8 Using the detachable control panel .. -
Page 3: Installation
INSTALLATION Notes: After inserting the holder into the dashboard, Choose the mounting location where the unit select the appropriate tab according to the will not interfere with the normal driving thickness of the dashboard material and bend function of the driver. them inwards to secure the holder in place. -
Page 4: Using The Detachable Control Panel
USING THE DETACHABLE CONTROL PANEL Precautions when handling To Detach the Control panel Do not drop the control panel. 1. Press the release button ( ) on the front Do not put pressure on the display or control panel and pull off the control panel. buttons when detaching or re-installing the control panel. -
Page 5: Wiring Connection
WIRING CONNECTION FOR 4X40W SYSTEM... -
Page 6: Operation
OPERATION (tune/seek/track down/up button) LOCATION OF KEYS (release button) 3.Mic (pick up) 5.PAIR/MOD 6.T-MENU 7.LCD 8.5 DIR- 9.4 SHF 10.1 PAU 11.1-6 preset buttons 12.2 SCN 13.3 RPT /MUTE 15.6 DIR+ 16.USB interface 17. 9 PTY 18. # SCAN/CON 19. 0 DISP 20. -
Page 7: Display Information
OPERATION Press it for several seconds again to release this SELECTING STATION Shortly press button or button to function, and “LOUD” will disappear. activate automatic seek function. Press for DISPLAY INFORMATION several seconds until “MANUAL” appears on the Press DISP button (19) to operate as the display, the manual tuning mode is selected. -
Page 8: Usb Operation
OPERATION REPEATING THE SAME TRACK RDS Setting Press RPT button (13) shortly to continuously Press and hold PTY button (17) to enter repeat the same track. Press it again to stop repeat. RDS Setting mode. Then shortly press PTY Press and hold RPT button (13) to repeat all button (17) to select the item you want to change, tracks in the current directory. -
Page 9: Display Information
OPERATION times. The unit searches file or directory from BLUETOOTH OPERATION current directory by TUNE/SEEK/TRACK PREPARING FOR OPERATION UP/DOWN buttons. The current directory (1) When use Bluetooth, please make sure the name is displayed for a second and the mobile phone supports Bluetooth function. currently playing file name is displayed (2) For the different kind of mobile phone, (selected). -
Page 10: T-Menu
OPERATION seconds to let the unit reconnection automatically the number you stored in it will be displayed or press and hold CON button (18) for several on LCD. seconds to reconnect. During reconnection, LCD 3) Preview the speed list will show “CONN TRY” several times and then show “CONN OK”... -
Page 11: Making An Outgoing Call
OPERATION 2) Making an outgoing call by inputting the phone number manually. Press button (4) on the front panel. Use 0~9, *, # buttons to enter the phone number you want to dial. Then press button (4) again will call the number. Note: if you input the wrong number, shortly press CLR button (24) will clear it. -
Page 12: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power : 4X40watts Current Drain : 15 Ampere (max.) USB/SD/MMC PLAYER Signal to Noise Ratio : More than 60 dB Channel Separation... -
Page 13: Trouble Shooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition switch is not If the power supply is connected No power.
