- Page 1 TL93* Digital Series...
-
Page 2: Table Of Contents
Quick Menu ................25 External Control Setup ............43 Selecting channels ..............25 Device Name Setup ..............44 The Time Display – analogue only .........25 Using Toshiba Places ..............44 Stereo and Bilingual transmissions .........25 Using YouTube™ ................45 Using 3D functions ................26 Using Hybrid TV Standard Using the 3D glasses .............26... - Page 3 Labeling video input sources ..........64 Digital Audio Output ............64 Using REGZA-LINK ................65 Enable REGZA-LINK ...............65 TV Auto Power ................65 Auto Standby ................65 REGZA-LINK input source selection ........65 REGZA-LINK one touch play ..........66 REGZA-LINK system standby ..........66 Toshiba PC compatible with REGZA-LINK ....66...
-
Page 4: Installing Your Tv
INSTALLING YOUR TV Safety Precautions DO NOT REMOVE ANY FIXED COVERS AS THIS WILL EXPOSE DANGEROUS AND ‘LIVE’ PARTS. This equipment has been designed and THE MAINS PLUG IS USED AS A DISCONNECTING DEVICE manufactured to meet international safety standards AND THEREFORE SHOULD BE READILY OPERABLE. -
Page 5: Installation And Important Information
INSTALLING YOUR TV Installation and important information Where to install Locate the television away from direct sunlight and strong Fixing strap lights. Soft, indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen. Place the TV on a stable, level surface that can support the weight of the TV. - Page 6 3D images. Therefore, to avoid injury do not place your TV near open Contact the Toshiba Call Center for repair of your 3D stairwells, balconies, or wires. glasses. Also do not sit near objects that could be broken if •...
-
Page 7: Exclusion Clause
Any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with associated equipment; Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following: loss of profit, interruption of business, the loss of recorded data whether caused during normal... -
Page 8: The Remote Control
INSTALLING YOUR TV The remote control 16 To access the “TOSHIBA PLACES” Top Page When network is not connected, an error message will be displayed. Simple at-a-glance reference of your remote control. 17 To access Media Player Menu 18 To call up text services... -
Page 9: Connecting Your Tv
CONNECTING YOUR TV Connecting external equipment Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from the wall socket. ILLUSTRATION SHOWS 40TL933. HDMI 4 INPUT HEADPHONE jack Power cord LAN port SCART (EXT 1) HDMI 1/2/3 INPUTS... -
Page 10: Connecting An Hdmi® Device
CONNECTING YOUR TV Connecting an HDMI® device HDMI’s ARC (Audio Return Channel) feature The HDMI input on your television receives digital audio and uncompressed digital video from an This feature enables the audio signal of the TV to be sent to the AV amplifier via the HDMI cable. It HDMI source device. -
Page 11: Regza-Link Connection
HDMI standard. • This function is available when one PC and one AV amplifier • This feature is limited to models incorporating Toshiba’s are connected separately. However, it may not operate REGZA-LINK. However, Toshiba is not liable for those properly if the PC is connected via the AV amplifier. -
Page 12: Connecting A Computer
CONNECTING YOUR TV Connecting a computer To connect a PC to the HDMI terminal When connecting a PC to the HDMI terminal on the television, With either an RGB/PC or an HDMI connection, you use an HDMI-to-DVI adaptor cable. can watch your computer’s display on the If connecting a PC with an HDMI terminal, use an HDMI cable television. -
Page 13: Connecting A Home Network
To connect the TV to a home network with an internet connection - Wireless The LAN port allows your Toshiba TV to connect to Please refer to “Wireless Setup” section on page 39. your home network. You can use this revolutionary... -
Page 14: Controls And Input Connections
The USB 2 socket has to be used with the “TOSHIBA Dual Band Using the menu system WLAN Adaptor WLM-20U2” in order to access a wireless network. -
Page 15: Menu Structure
Media Player USB Media Player Menu USB Media Player Network Media Player Menu Network Media Player Connected TV Jump to Toshiba Places Toshiba Places NOTE: This menu item is subject to change without notice. Function On Timer Menu On Timer... -
Page 16: Setting Up Your Tv
SETTING UP YOUR TV Startup Application Press OK, and the Network Type screen will appear. Press to select Wired or Wireless. Before switching on the TV, make sure your decoder/media recorder, if applicable, is in Network Type standby. To set up the television, use the buttons Please select a network type. - Page 17 SETTING UP YOUR TV In step 9, when you select Manual Setup; The Advanced Network Setup screen will appear. Press OK, and the Manual Setup screen will appear. When the DHCP function of the router connected Press to select Network Name and press OK. with this TV is On, you can set Auto Setup to On or The Software Keyboard window will appear (page 43).
-
Page 18: Ant/Cable In (If Available)
SETTING UP YOUR TV Press OK. If your country supports Network Guide, Press to view the DTV (digital channel) or ATV The Guide Type screen will appear. (analogue channel) lists. Guide Type to move through the list to select a channel, and then press OK to view. -
Page 19: Auto Tuning
SETTING UP YOUR TV With the exception of DTV Scan Type and DTV Modulation Press to select Auto Tuning and press OK. items, all of the following items will have 2 operating modes. The first is Auto where the values for each item are preset by System Setup the system. -
Page 20: Atv Manual Tuning
SETTING UP YOUR TV ATV Manual Tuning In the System Setup menu, press to select ATV Manual Tuning and press OK. Tuning System Setup Menu Language English The television can be tuned-in manually using ATV Manual Country Tuning. For example, you might use the feature if the television Germany cannot be connected to a media recorder/decoder with a SCART Ant/Cable In... -
Page 21: Skip
SETTING UP YOUR TV Skip Each signal will show on the television. If it is not your media recorder, press again to restart the To prevent certain channels from being viewed, positions can be search. skipped. When your media recorder signal is found, press Select ATV Manual Tuning from the System Setup move along to Station. -
Page 22: Sorting Positions
SETTING UP YOUR TV DTV Manual Tuning Sorting positions Channels may be moved and saved to the position of your NOTE: This feature varies depending on the Ant/Cable In choice. setting. Select ATV Manual Tuning from the System Setup Manual Tuning menu. -
Page 23: Manual Tuning For Dvb-C
SETTING UP YOUR TV DTV Settings Manual Tuning for DVB-C When Ant/Cable In is set to Cable, DTV Manual Tuning items are as follows: Channels Frequency – input a specific frequency to be scanned The channel order may be changed to suit your personal Modulation –... -
Page 24: Standby Channel Update
SETTING UP YOUR TV Move — Press the GREEN button to activate the Analogue switch-off Move feature. Press the buttons to select the This is a digital television which is integrated to allow the use channel you wish to move and press OK to check. of both digital and analogue services. -
Page 25: Controls And Features
CONTROLS AND FEATURES General controls Selecting channels To select a channel, use the numbered buttons on the remote control. Quick Menu Channels can also be selected using P and P Quick Menu helps you access some options quickly, such as To display on-screen information such as channel, input mode Picture Mode, Picture Size, More Information, Sleep Timer or stereo/mono signal, press... -
Page 26: Using 3D Functions
“When using the 3D glasses” section on page 6. protective films from the lenses. Viewing 3D programming requires the following: • TOSHIBA 3D Glasses FPT-AG02G Turn the 3D glasses on TL933RB series: Supplied with the power switch. TL933/TL936 series: Not supplied NOTE: If the infrared data communication between the •... -
Page 27: Viewing 3D Images
CONTROLS AND FEATURES Viewing 3D images Switching display mode or selecting 3D format Incoming video signals can either be in 2D or 3D format. A 2D signal can be viewed in either 2D or 3D, and 3D can be viewed in There are four modes for watching TV. - Page 28 CONTROLS AND FEATURES To select 3D format from the Quick menu in 3D To select 2D format from the Quick menu in 2D mode: mode: Press QUICK to display the Quick Menu. Press QUICK to display the Quick Menu. Press to select 3D Settings and press OK.
-
Page 29: Setting The Auto Start Mode
CONTROLS AND FEATURES NOTE: Depending on the content, setting the 3D effect to a Setting the auto start mode high level may result in blurring of the image contours and background. Controls what the TV does when it detects a 3D signal. If you experience any abnormal sensation or feel fatigue or Press MENU / to highlight Setup icon. -
Page 30: Setting 3D Lock
CONTROLS AND FEATURES Setting 3D Lock Displaying 3D Important Info When this feature is set to On, you must enter 3D PIN code for In the Preferences menu, press to select 3D changing display mode. Setup and press OK. In the Preferences menu, press to select 3D Press to select 3D Important Info and press... -
Page 31: Sound Controls
CONTROLS AND FEATURES Sound controls Voice Enhancement Voice Enhancement emphasises the frequency range of the speaker’s voice, making it easier to catch what they are saying. Volume controls and sound mute In the Advanced Sound Settings menu, press Volume to select Voice Enhancement. Press + or –... -
Page 32: Audio Level Offset
CONTROLS AND FEATURES Audio Level Offset Headphone Settings Sometimes there can be large changes in volume when This setting is used to set the sound output when headphones are switching from a DTV 5.1ch to a DTV 2ch, an ATV channel, or an connected. -
Page 33: Widescreen Viewing
CONTROLS AND FEATURES Widescreen viewing Depending on the type of broadcast being transmitted, programmes can be viewed in a number of formats. Use this setting when watching a widescreen DVD, widescreen video tape or a 16:9 broadcast (when available). Due to the range of WIDE widescreen formats (16:9, 14:9, 20:9 etc.) black bars may be visible on the... - Page 34 CONTROLS AND FEATURES This setting will show the picture NATIVE without overscan, i.e. WYSIWYG. This setting will show the picture without overscan, i.e. WYSIWYG. PC NORMAL This option is only available when watching a PC signal source via HDMI or PC terminal. This setting will show the picture without overscan or side panels.
-
Page 35: Picture Controls
CONTROLS AND FEATURES Picture controls Picture preferences You can customize current picture mode settings as desired. For Most of the picture controls and functions are example, while selecting “Dynamic”, if you change the following available in both digital and analogue modes. items, such as Backlight, Contrast, Brightness, Colour, Tint, PLEASE NOTE: Features not available will be grayed Sharpness and the Advanced Picture Settings items, your... -
Page 36: Base Colour Adjustment
CONTROLS AND FEATURES Base Colour Adjustment Auto Brightness Sensor The Base Colour Adjustment feature allows the adjustment of When the Auto Brightness Sensor is activated, it will individual colours to suit personal preference. This can be useful automatically optimise the backlighting levels to suit ambient when using an external source. -
Page 37: Dnr - Digital Noise Reduction
CONTROLS AND FEATURES DNR – Digital Noise Reduction 4:3 Stretch DNR allows you to ‘soften’ the screen representation of a weak When 4:3 Stretch is activated, the size switching system signal to reduce the noise effect. changes 4:3 programmes into full screen picture. In the Preferences menu, press to select Select DNR from the Noise Reduction menu. -
Page 38: Using Your Home Network
Institute of Electrical and Austria Iceland Electronics Engineers. • The TOSHIBA Dual Band WLAN Adaptor is intended for use Belgium Liechtenstein with the TL93 series LCD TV’s and should not be used with... -
Page 39: Setting Up The Network
CONTROLS AND FEATURES Setting up the Network Assisted Setup In the Preferences menu, press to select You can select the Network Type. Network Setup and press OK. Press MENU / to highlight Setup icon. Press to select Wireless Setup and press OK. Press to highlight Preferences icon and press OK. - Page 40 CONTROLS AND FEATURES Wireless Information Press to select Authentication and press to select Open System, Shared Key, WPA-PSK or The settings configured in Wireless Setup can be confirmed. WPA2-PSK. Press QUICK to open the Quick Menu. Press to select Encryption and press Press to select Wireless Information and to select None, WEP, TKIP or AES.
-
Page 41: Advanced Network Setup
CONTROLS AND FEATURES NOTE: Even if an AP for IEEE 802.11n is used when Encryption Highlight Auto Setup and press to select On. is set to WEP or TKIP, the Speed value might be low. It is recommended that Encryption be changed to AES (see IP Address Setup “Manual Setup”... -
Page 42: Dns Setup
CONTROLS AND FEATURES MAC Address DNS Setup You can view the fixed MAC address for the TV and for the NOTE: When the DHCP function of the router connected to Dual Band WLAN Adaptor, if one is installed. this TV is Off, set Auto Setup to Off, and manually set the DNS address(es). -
Page 43: Using The Software Keyboard
(see page 43). The maximum number of characters is 16. B b C c Moves the character highlight. CC cc NOTE: Toshiba does not guarantee normal operation with all Moves the cursor. connected devices. Moves the cursor to the head of a character string. -
Page 44: Device Name Setup
Highlight Done and press OK to save your setting. dedicated to this product. Third party internet services may change or be discontinued or restricted at any time. Toshiba makes no warranties, representations, or assurances about the content, availability or functionality of third-party content or services. -
Page 45: Using Youtube
MENU / to highlight Connected TV icon and press NOTE: You need to configure a home network before using highlight Toshiba Places icon and press OK. this feature (see page 13). BbC c Press MENU / to highlight Setup icon. -
Page 46: Using The Media Player
Select the connected USB device and press OK. You must obtain any required permission from copyright owners to download or use copyrighted Multi View will appear. content. TOSHIBA cannot and does not grant such permission. To select a file in the Multi View: Basic operation... -
Page 47: Viewing Photo Files (On A Dlna Certified™ Server Or Usb Device)
CONTROLS AND FEATURES Using the Media Player with a DLNA CERTIFIED™ Viewing photo files (on a DLNA Server CERTIFIED™ Server or USB device) You need to configure a home network before using There are three types of viewing modes. this feature (see page 13). Multi View (USB Photo) Press MENU / to highlight Media Player icon. - Page 48 CONTROLS AND FEATURES Single View To zoom in/out photos In this mode, only files located in the selected directory will be During the Single View mode or Slide Show mode, the zoom displayed. This view allows you to change the photo content function can be used.
-
Page 49: Viewing Movie Files (On A Dlna Certified™ Server Or Usb Device)
CONTROLS AND FEATURES To select a photo from Play List Viewing movie files (on a DLNA CERTIFIED™ Server or USB device) While in the Single View mode or Slide Show mode, you can select a different photo from the Play List. You can select movies from a Multi View of available files. - Page 50 CONTROLS AND FEATURES During playback: Resume Play (USB only) • Press to pause. You can resume playback from where it was last stopped. PAUSE may not be available depending on the contents or Press while playing the movie to memorize the stopped DMS.
- Page 51 CONTROLS AND FEATURES To register your TV to a DivX® account To playback DivX Plus HD content: This TV allows you to play back files purchased or rented from • To play in fast reverse or fast forward directions, press DivX®...
-
Page 52: Playing Music Files (On A Dlna Certified™ Server Or Usb Device)
CONTROLS AND FEATURES To set the repeat mode: Playing music files (on a DLNA CERTIFIED™ Server or USB device) Press QUICK to open the Quick Menu. You can listen to music from a Multi View of available files. Press to select Repeat. Multi View (USB Music) Press to select Off, All or 1. -
Page 53: Other Features
CONTROLS AND FEATURES Other features The timers Panel Lock Programme Timers – digital only Panel Lock disables the buttons on the television. All buttons on This feature will set the television to go to a specific channel at a the remote control can still be used. certain time. -
Page 54: On Timer
CONTROLS AND FEATURES To cancel the On Timer On Timer In the On Timer menu, select Enable On Timer. The feature allows you to set the television to turn on automatically to a preset channel at a certain time of day or after a certain length of time. -
Page 55: Energy Saving Settings
CONTROLS AND FEATURES Energy Saving Settings Digital on-screen information When viewing in digital mode, the on-screen Automatic Power Down information and programme guide provide access to programme details for all available channels. The TV will automatically turn itself off (standby) after 4 hours, if you do not operate the TV either from the remote control or the TV control panel. -
Page 56: Using Epg (Electronic Programme Guide)
CONTROLS AND FEATURES Using EPG (Electronic To display More Information Programme Guide) Press QUICK to open the Quick Menu. You can choose the desired EPG system between Press to highlight More Information and press OK. the Broadcast Guide or MediaGuide that needs a internet connection. -
Page 57: Genre Selection/Searching
Search Results. selected. Search keyboard. Default focus position is the current channel. Remote control key operation NOTE: • Toshiba does not take responsibility for the accuracy of :▲ :▼ :◄ :► content displayed. • Service Information may not be displayed or there may be little service information displayed depending on the area or the kind of broadcast. -
Page 58: Digital Settings - Parental Control
Rovi Guide system. Parental PIN Setup • Third party internet services are not provided by Toshiba, may change or be discontinued at any time and may be subject to internet service provider restrictions. Toshiba Press MENU / to highlight Setup icon. -
Page 59: Parental Setup
CONTROLS AND FEATURES Digital settings – Channel Parental Setup Options The Parental Control feature allows you to block programmes according to their rating levels. If a PIN has been set, you will need to enter it before adjusting the level. Selecting favourite channels In the DTV Settings menu, press to select... -
Page 60: Skip Channels
CONTROLS AND FEATURES Digital settings – other settings Skip channels This feature allows you to set channels that will be skipped when or P are used to tune. Subtitles Select the channel you want to skip in your channel In digital mode, this feature will show subtitles on the screen in list. -
Page 61: Common Interface
• Software update of a CI Plus CAM may occur automatically if instigated by the broadcaster. This could cause the TOSHIBA may offer upgrades for the TV’s software in the future. cancellation of any Reminders/Recordings during this The TV’s software is upgraded via the Network. -
Page 62: System Information And Reset Tv
Press OK to display the System Information. press OK. System Information Press to select Display Settings and press OK. TOSHIBA 2011 Press to select PC Setting and press OK. 6.8.05.1 Jan 19 2012 - 53. 5. 73. 5 MBOOT Version : xxxxxxxx... -
Page 63: Sampling Clock
CONTROLS AND FEATURES Input selection and AV Sampling Clock connections Adjusting the Sampling Clock alters the number of pulses per scan, this will clear vertical lines on the screen. See page 9 for a detailed image showing In the Display Settings menu, press to select recommended connections. -
Page 64: Labeling Video Input Sources
CONTROLS AND FEATURES Labeling video input sources Digital Audio Output These input labels are shown in the input selector. You can label When connecting a surround sound amplifier to the digital audio video inputs according to the devices you have connected to the output (Sony/Philips Digital Interface Format [S/PDIF]), the following options can be selected or adjusted. -
Page 65: Using Regza-Link
This is a new feature that uses CEC technology and amplifier) is connected to the HDMI input, you can select another allows you to control Toshiba REGZA-LINK REGZA-LINK device that is connected to the master HDMI device compatible devices from the television remote on the input source list. -
Page 66: Regza-Link One Touch Play
LINK Setup (see page 65). NOTE: This feature depends on the connected equipment and television state. Toshiba PC compatible with REGZA-LINK This feature automatically adjusts the suitable widescreen formats and picture preferences when connected to a Toshiba PC compatible with REGZA-LINK. -
Page 67: Text Services
List will save your four favourite pages. For further information on your particular text system(s), see the broadcast text index page or consult your local Toshiba Selecting modes dealer. The text character set will be automatically chosen by the language setting in the Setup menu. -
Page 68: Control Buttons
TEXT SERVICES Control buttons Below is a guide to the functions of the remote control text buttons. k To display the index/initial page: Press to access the index/initial page. The one displayed is dependant on the broadcaster. TEXT To display a page of text: Press TEXT to display text. -
Page 69: Problem Solving
PROBLEM SOLVING Questions and Answers What else can cause a poor picture? Below are the answers to some of the most Interference or a weak signal. Try a different common queries. television station. Manual Fine Tuning may help. Why is there no sound or picture? Select the ATV Manual Tuning menu. - Page 70 This normally requires a roof or loft aerial. If the text is unreadable or garbled, check the Make sure the TOSHIBA Dual Band WLAN Adaptor is aerial. Go to the main index page of the text service used (see page 13).
- Page 71 PROBLEM SOLVING Other problems Why doesn’t the Media Player feature operate? If your TV’s problem is not addressed in this Questions and Answers section or the recommended solution has not Make sure that devices are connected correctly. worked, do one of the following: Incorrect behaviour may occur with a USB Hub Turn off your TV.
-
Page 72: Information
INFORMATION License Information • Manufactured under license from Dolby • THIS PRODUCT IS LICENSED UNDER THE AVC PATENT Laboratories. PORTFOLIO LICENSE FOR THE PERSONAL AND Dolby and the double-D symbol are trademarks NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO of Dolby Laboratories. - Page 73 INFORMATION Cleaning the screen and cabinet… Turn off the power, and clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use any proprietary polishes or solvents on the screen or cabinet as this may cause damage. Disposal…...
-
Page 74: Information
INFORMATION Information Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from the wall socket. Signal information for Mini D-sub 15 pin connector Pin No. Signal name Pin No. Signal name Pin No. - Page 75 INFORMATION Acceptable video or PC signals through the HDMI terminals The HDMI inputs on this TV only accept VGA, SVGA, XGA, WXGA, and SXGA signal formats which are compliant with VESA as shown in the table below. Since some PCs and HDMI or DVI devices input signals which are different from the resolution and frequency described in the table below, the following phenomenon may occur;...
-
Page 76: Media Player Supported Format
INFORMATION Media Player Supported Format Media Media File Video codec Audio codec USB DMS Note Player Format Extention Photo JPEG .jpg JPEG •<USB> .jpeg Data compatibility: – JPEG Exif ver 2.2 Maximum viewable resolution: •JPEG .mpo 15360 × 8640 (Base-line) 1024 ×... - Page 77 INFORMATION Media Media File Video codec Audio codec USB DMS Note Player Format Extention Movie .mkv MPEG-1 Video MPEG-1/2 Layer2 MPEG-2 Video MPEG-1/2 Layer3 MPEG-4 part2 Dolby Digital (AC-3) H.264 (MPEG-4 AVC) L-PCM MPEG-2/4 LC AAC MPEG-4 HE-AAC RealMedia RealVideo 8,9,10 Dolby Digital (AC-3) .rmvb MPEG-2/4 LC AAC...
- Page 78 INFORMATION 3D Support Format (HDMI) Resolution Aspect ratio V.Fraquency H.Fraquency Pixel Clock Frequency 3D Structure 720 × 480p 16:9 59.940/60.000Hz 31.469/31.500kHz 27.000/27.027MHz Side by Side (Full) Side by Side (Half) Top and Bottom 720 × 576p 16:9 50.000Hz 31.250kHz 27.000MHz Side by Side (Full) Side by Side (Half) Top and Bottom...
- Page 79 INFORMATION 3D Support Format (DTV) Video Format Aspect ratio V.Fraquency 3D Structure 480i, 480p 16:9 59.940/60.000Hz Side by Side (Half) Top and Bottom 576i, 576p 16:9 50.000Hz Side by Side (Half) Top and Bottom 720p 16:9 59.940/60.000Hz Side by Side (Half) Top and Bottom 50.000Hz Side by Side (Half)
-
Page 80: Specifications And Accessories
Digital Audio Output (S/PDIF) Optical • 4 spacers for wall mounting LAN port RJ-45 Optional accessories • Toshiba 3D glasses : FPT-AG02G (for TL933 series) USB 1/USB 2 port Media Player • TOSHIBA Dual Band WLAN Adaptor Interface version: USB 2.0...
