- Page 1 CONGELADOR FREEZER CONGELADOR ZIC 422/9 LIBRO DE INSTRUCCIONES INSTRUCTION BOOKLET MANUAL DE INSTRUÇÕES 2222 125-16/1...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
CONTENTS Installation Location Cleaning the interior Door reversibility Building-in instructions Electrical connection Technical specification Control panel Use of the freezer Frozen food storage Quick freezing Warning light Air circulation Freezing of fresh foods Storage of commercially frozen food Thawing Use of the refrigerator Fresh food refrigeration Movable shelves Defrosting... -
Page 4: Installation
INSTALLATION If this refrigerator featuring magnetic door seals is to replace an older appliance having a spring lock Important on the door or lid, be sure to make that spring lock It is essential that the appliance be connected to an unusable before you discard the old appliance. -
Page 5: Door Reversibility
Door reversibility (Fig. 1) D337 Fig. 1 Right opening Left opening Remove the pins (P) and (P1). Remove (P) from both sides and the door. Remove (A) from the left side and (B)-(C)-(D) from the right side. Refit (B)-(C)-(D) on the left side and (A) on the right side. -
Page 6: Building-In Instructions
Building-in instructions Fig. 2 Housing dimensions 50-min. cm Height 1780 mm Depth 550 mm Width 560 mm For appropriate venting, follow indications in Fig. 2. min. D027 Push appliance into housing until stop strip (A) Fig. 3 touches the kitchen unit. D023 If after having carried out the operation described in Fig. - Page 7 Press in the joint covers between the appliance and the kitchen furniture. Fig. 6 D098 Apply covers (B) on joint cover lugs and into hinge Fig. 7 holes. D096 Position the runners (H) at the top and bottom of the Fig.
-
Page 8: Electrical Connection
Remove the little plates and make the holes with a diam. of 2 mm. Replace the little plates over the Fig. 10 runners and screw in the screws provided (3.5x16 mm). For the alignment of the kitchen unit door, if necessary, use the clearance size of the slotted holes. -
Page 9: Use
Control panel (Fig. 12) Fig. 12 A. Pilot light B. SUPER operating control light C. Warning light D. NORMAL/SUPER Switch E. Thermostat knob (freezer compartment) Use of the freezer Warning light (C) The freezer is marked with the symbol, which This light warns when the temperature inside the means that the compartment is suitable for freezing freezer compartment has increased so much as to... -
Page 10: Freezing Of Fresh Foods
between 2 and 4. the wrapping adheres closely to the food and is well sealed. In this way, by avoiding contact with air, the It is also advisable not to turn the fan on if the colour, flavour and nutritional value of the foods temperature inside the compartment is cool enough: remain intact. -
Page 11: Thawing
Fresh food refrigeration for normal storage use. Avoid opening the door too frequently and when you To obtain the best performance: do open it, leave it open only for as long as is strictly necessary. do not store warm food or evaporating liquids in the A word of warning about ice lollies: they should not refrigerator;... -
Page 12: Movable Shelves
Movable shelves Fig. 14 The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. D040 Defrosting Fig. 15 Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motorcompressor stops. -
Page 13: Ice Cube Trays
If a thick layer of ice is formed it will be necessary to carry out complete defrosting as following: set the knob (E) to « O » or unplug the appliance from the mains socket; wrap frozen food in several layers of newspaper and place the food packages in a cool place. -
Page 14: Maintenance
MAINTENANCE Replacing the interior light bulb Unplug the appliance before carrying out any maintenance operation. The light inside the refrigerator compartment is easy to get at through the opening in the light holder. Periodical cleaning If the light does not go on when the door is open, check that it is screwed into place properly.
