- Page 1 GEFRIERSCHRANK CONGELATEUR DIEPVRIEZER FREEZER ZI 7120 F BEDIENUNGSANLEITUNG MODE D’EMPLOI GEBRUIKSAANWIJZING INSTRUCTION BOOKLET 2222 119-75...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Environment Protection
Installation During normal operation, the condenser and compressor at the back of the appliance heat up considerably. For safety reasons, minimum ventilation must be as shown in the relevant Figure. Attention: keep ventilation openings clear of obstruction. If the appliance is transported horizontally, it is possible that the oil contained in the compressor flows in the refrigerant circuit. -
Page 4: Table Of Contents
CONTENTS Installation Positioning Cleaning the interior Instructions for totally built-in appliances Electrical connection Technical specification Control panel Operation Temperature regulatio Fast freezing Warning light Internal thermometer Freezing fresh food Storage of frozen food Thawing Ice-cube production Defrosting Maintenance Periodic cleaning Periods of non-operation Customer service... -
Page 5: Installation
INSTALLATION If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock Important (latch) on the door or lid, be sure to make that It is essential that the appliance be connected to an spring lock unusable before you discard the old efficient earth tap. -
Page 6: Instructions For Totally Built-In Appliances
Instructions for totally built-in appliances Fig. 1 50 mm Dimensions of the recess Height 880 mm Depth 550 mm Width 560 mm min. The appliance’s door has been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. - Page 7 Press in the joint covers between the appliance and the kitchen unit. Fig. 5 D019 Apply covers (B) on joint cover lugs and into hinge Fig. 6 holes. D013 Position the runners (H) at the top and bottom of the Fig.
-
Page 8: Electrical Connection
Remove the little plates and make the holes with a diam. of 2 mm. Replace the little plates over the Fig. 9 runners and screw in the screws provided (3.5x16 mm). For the alignment of the kitchen unit door, if necessary, use the clearance size of the slotted holes. -
Page 9: Use
The freezer is marked with the symbol, which means that the compartment is suitable for freezing fresh food, long-term storage of frozen food, and making ice cubes. Control panel B C D E A. Temperature adjustment knob B. NORMAL/SUPER (quick freezing) switch C. -
Page 10: Internal Thermometer
Internal thermometer This indicates the internal temperature of the freezer. It may indicate a temperature above –18°C when °C large quantities of food are placed inside for freezing or when the door is left open for a long time. Blue: normal Red: alarm Freezing fresh food The 4-star freezer (... -
Page 11: Storage Of Frozen Food
Storage of frozen food Thawing When first starting-up or after a period out of use, let Deep-frozen or frozen food, prior to being used, can the appliance run for at least three hours on the fast be thawed in the refrigerator compartment or at room freeze setting before putting the products in the temperature, depending on the time available for this compartment. -
Page 12: Defrosting
Defrosting The freezer compartment, however, will become progressively covered with frost. This should be removed with the special plastic scraper provided, whenever the thickness of the frost exceeds 4 mm. During this operation it is not necessary to switch off the power supply or to remove the foodstuffs. -
Page 13: Maintenance
MAINTENANCE Periods of non-operation Unplug the appliance before carrying out any maintenance operation. When the appliance is not in use for long periods, take the following precautions: Warning remove the plug from the wall socket; This appliance contains hydrocarbons in its cooling unit;...
