- Page 1 GPS NAVIGATION SYSTEM MAIN USER MANUAL MOBILE HOME VERSION ENGLISH...
- Page 2 Thank you for choosing our product as your navigator. Start using your device right away. This document is the detailed description of the navigation software. You can easily discover the software while you are using it; however, we still recommend that you read this manual to fully understand the screens and features.
-
Page 3: Table Of Contents
Table of contents 1 Warnings and Safety information .................6 2 Getting started......................7 2.1 Navigation menu ......................8 2.2 Buttons and other controls on the screen............... 8 2.2.1 Using keyboards ........................ 10 2.2.2 Beyond single screen tap ....................11 2.3 Map screen........................11 2.3.1 Navigating on the map....................... - Page 4 3.1.6 Selecting a recent destination from the History ..............45 3.1.7 Entering the coordinate of the destination ................. 46 3.1.8 Building a route from the list of destinations (Create Route) ..........47 3.2 Viewing the entire route on the map ................48 3.3 Checking route parameters and accessing route related functions ......
- Page 5 7 Copyright note.......................75...
-
Page 6: Warnings And Safety Information
It is important that you look at the display only when it is safe to do so. If you are the driver of the vehicle, we recommend that you operate ZE-NC620DMH before you start your journey. Plan the route before your departure and stop if you need to change the route. -
Page 7: Getting Started
2 Getting started ZE-NC620DMH is optimised for in-car use. You can use it easily by tapping the screen buttons and the map with your fingertips. When using the navigation software for the first time, an initial setup process starts automatically. Do as follows: The language of the application is taken from the language settings of ZE-NC620DMH. -
Page 8: Navigation Menu
Tap the button to enlarge the map to the full screen. 2.2 Buttons and other controls on the screen When you are using ZE-NC620DMH, you usually tap buttons on the touch screen. You only need to confirm selections or changes if the application needs to restart, it needs to perform a major reconfiguration, or you are about to lose some of your data or settings. - Page 9 • Slider When a feature can be set Drag the handle to different values in a to move the range, ZE-NC620DMH slider to its new shows an indicator on a position. gauge that displays and • Tap the slider sets the value.
-
Page 10: Using Keyboards
2.2.1 Using keyboards You only need to enter letters or numbers when you cannot avoid it. You can type with your fingertips on the full-screen keyboards and you can switch between various keyboard layouts, for example English, Greek or numerical. Task Instruction Switching to another keyboard layout, for... -
Page 11: Beyond Single Screen Tap
2.3 Map screen 2.3.1 Navigating on the map The Map screen is the most frequently used screen of ZE-NC620DMH. A small live map is displayed on the Navigation menu, as a part of the button. - Page 12 To enlarge this small map and open the Map screen, tap This map shows the current position (the Vehimarker, a blue arrow by default), the recommended route (an orange line), and the surrounding map area. When there is no GPS position, the Vehimarker is transparent. It shows your last known position.
-
Page 13: Position Markers
2.3.2 Position markers 2.3.2.1 Vehimarker and Lock-on-Road When your GPS position is available, ZE-NC620DMH marks your current position with the Vehimarker. By default, this marker is a blue arrow, but you can change this icon in Settings. When on-road navigation is selected, the Vehimarker may not show your exact GPS position and heading. -
Page 14: Objects On The Map
2.3.3 Objects on the map 2.3.3.1 Streets and roads ZE-NC620DMH shows the streets in a way that is similar to how the paper road maps show them. Their width and colours correspond to their importance: you can easily tell a motorway from a small street. -
Page 15: Lane Information And Signposts
Bear right. Turn sharp left. Keep left. Continue straight in the intersection. Go left on the roundabout, 3rd exit (next manoeuvre). Enter roundabout (second next manoeuvre). Enter motorway. Exit motorway. Board ferry. Leave ferry. Approaching a waypoint. Approaching the destination. 2.3.3.3 Lane information and Signposts When navigating on multilane roads, it is important to take the appropriate lane in order to follow the recommended route. -
Page 16: Junction View
Tap any of them to display it on the map and add it as a waypoint to your route if needed. If you want to display other types of Places for the exits, you can change the icons in Visual Guidance settings (page 71). 2.3.3.6 3D object types ZE-NC620DMH supports the following 3D object types: Type Description 3D terrain... -
Page 17: Elements Of The Active Route
3D buildings 3D block representation of full city building data containing actual building size and position on the map. 2.3.3.7 Elements of the active route ZE-NC620DMH shows the route in the following way: Symbol Name Description Current GPS position and Your current position displayed on the map. - Page 18 Zooming in and out Changes how much of the map is displayed on the screen. ZE-NC620DMH uses high-quality vector maps that let you examine the map at various zoom levels, always with optimised content. It always displays street names and other text with the same font size, never upside-down, and you only see the streets and objects that you need.
-
Page 19: Quick Menu
Additional options Tap this button to open a list of additional features like saving the Cursor as a Favourite destination, or searching for Places around the Cursor. Select destination Tap this button to select the Cursor as a new destination. route automatically calculated. - Page 20 More / Settings / This button opens the route related settings. Route Settings (page More / Settings / This button opens the map related settings. Map Settings (page Tap the Current This button opens a special screen with information about Street field on the the current position and a button to search for nearby Map screen...
-
Page 21: Checking The Details Of The Current Position (Where Am I?)
Find / Find Places With this function you can search for Places of Interest in (page 32) various different ways. My Route / More / This button opens the Map screen and starts simulating Simulate Navigation the active route. Tap the top of the This button opens the GPS Information screen with Map screen when satellite position and signal strength information. - Page 22 • In the middle of the screen you can see whether the position is current, or the time left since it was last updated. • Address details (when available) of the current position are also displayed at the bottom. You can also perform some actions on this screen: to save the current position as a Favourite destination.
-
Page 23: On-Road Navigation
3 On-road navigation When first started, ZE-NC620DMH calculates routes using the road network of the high quality vector maps provided with the product. You can set up your route in different ways: • If you need a route for immediate navigation, you can select the destination and start navigating to it right away (normal navigation). -
Page 24: Entering An Address
Navigation menu. In the Navigation menu, tap the following buttons: By default, ZE-NC620DMH proposes the country and city/town where you are. If needed, tap , enter the first few letters of the country name on the keyboard, and select one country from the list of results. - Page 25 • The most likely street name is always shown in the input field. To accept it, tap • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears automatically, tap ).
-
Page 26: Entering The Midpoint Of A Street As The Destination
Tip! If you know that you will use this destination frequently, before tapping to confirm the destination, put it on the list of your Favourites first: tap then , give a name for the new Favourite, and tap to save the location. The map with the destination returns automatically. -
Page 27: Selecting An Intersection As The Destination
Instead of entering the house number, tap . The midpoint of the street is selected as the destination. A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. - Page 28 • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears automatically, tap ). Select the street from the list. Enter the intersecting street name: •...
-
Page 29: Selecting A City/Town Centre As The Destination
3.1.1.4 Selecting a city/town centre as the destination The city/town centre is not the geometric centre of the city/town but an arbitrary point the map creators have chosen. In towns and villages, it is usually the most important intersection; in larger cities, it is one of the important intersections. -
Page 30: Entering An Address With A Postal Code
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 3.1.1.5 Entering an address with a postal code All of the above address searching possibilities can be performed with entering the postal code instead of the city/town name. - Page 31 Start entering the street name on the keyboard. Find the street you need: • The most likely street name is always shown in the input field. To accept it, tap • If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears automatically, tap ).
-
Page 32: Tips On Entering Addresses Quickly
3.1.2 Selecting the destination from the Places of Interest You can select your destination from the Places of Interest included with ZE-NC620DMH. Using the same screen, you can find a Place in different ways: •... -
Page 33: Quick Search For A Place Of Interest
3.1.2.1 Quick search for a Place of Interest The Quick search feature lets you quickly find a Place by its name. The search is always carried out • along the recommended route if it exists or • around your current location if there is no destination given. Start the Quick search function: •... -
Page 34: Searching For A Place Of Interest Using Preset Categories
If necessary, tap the map somewhere else to modify the destination. The Cursor ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. After a short summary of the route parameters, the map appears showing the entire route. - Page 35 • If the current position is not available either (no GPS signal), they are searched around the last known position. • • If an active route exists, restaurants are searched along the route. • If there is no active route (destination is not selected), they are searched around the current position.
-
Page 36: Searching For A Place Of Interest By Category
3.1.2.3 Searching for a Place of Interest by category You can search for Places of Interest by their categories and subcategories. If you are on the Map screen, tap to return to the Navigation menu. In the Navigation menu, tap the following buttons: Select the area around which the Place should be searched for: •... - Page 37 Select one of the main Place categories (e.g. Accommodation) or tap to list all Places around the selected location or along the route. Select one of the Place subcategories (e.g. Hotel or Motel) or tap to list all Places in the selected main category around the selected location or along the route.
-
Page 38: Searching For A Place Of Interest By Name
11. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen. 12. - Page 39 • to search for a place around the destination of the active route. (The result list will be ordered by the distance from the destination.) • to search along the active route, and not around a given point. This is useful when you search for a later stopover that results in a minimal detour only, such as searching for upcoming petrol stations or restaurants.
- Page 40 Using the keyboard, start entering the name of the Place. 10. After entering a few letters, tap to open the list of Places with names containing the entered character sequence. 11. (optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour.
-
Page 41: Selecting Nearby Assistance From 'Where Am I
3.1.2.5 Selecting nearby assistance from 'Where Am I?' You can quickly search for nearby assistance from the 'Where Am I?' screen. On the Map screen, tap to open the Quick menu. , and then Preset search categories appear, all for searching around the current position (or around the last known position if the current position is not available): •... -
Page 42: Selecting A Map Location As The Destination
If necessary, tap the map somewhere else to modify the destination. The Cursor ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. After a short summary of the route parameters, the map appears showing the entire route. -
Page 43: Selecting The Destination From Your Favourites
3.1.4 Selecting the destination from your Favourites You can select a location that you have already saved as a Favourite to be your destination. Adding a location to the list of Favourite destinations is described on page 54. Access the list of Favourites: •... -
Page 44: Selecting One Of The Most Likely Destinations (Smart History)
3.1.5 Selecting one of the most likely destinations (Smart History) The destinations that you have set earlier appear in the History list. Two of those recent destinations are shown in the Destination menu for easy access. Smart History offers these locations based on your navigation habits, using parameters like the current time of day, the day of week, and the current location. -
Page 45: Selecting A Recent Destination From The History
3.1.6 Selecting a recent destination from the History The destinations that you have set earlier appear in the History. Access the History: • If you are on the Map screen, tap and then tap • If you are in the Navigation menu, tap and then tap The list of recent destinations appears. -
Page 46: Entering The Coordinate Of The Destination
3.1.7 Entering the coordinate of the destination You can also select a destination by entering its coordinate. Do as follows: If you are on the Map screen, tap to return to the Navigation menu. In the Navigation menu, tap You can enter the latitude and longitude values in any of the following formats: decimal degrees;... -
Page 47: Building A Route From The List Of Destinations (Create Route)
3.1.8 Building a route from the list of destinations (Create Route) You can also build your route destination by destination from the My Route menu. If you are on the Map screen, tap to return to the Navigation menu. In the Navigation menu, tap There is only one line in the list of route points, the start point of the route, normally the current GPS position. -
Page 48: Viewing The Entire Route On The Map
. The active route is displayed in its full length on the map together with additional information and controls. 3.3 Checking route parameters and accessing route related functions You can check different parameters of the route recommended by ZE-NC620DMH. If you are on the Map screen, tap to return to the Navigation menu. -
Page 49: Modifying The Route
3.4 Modifying the route When navigation is already started, there are several ways to modify the active route. The following sections show some of those options. 3.4.1 Selecting a new destination when already having a route: New Route, Waypoint or Final Destination If you already have a recommended route and you select a new destination as described in the above sections, the application will ask you whether to start a new route, add a new waypoint (intermediate destination) to the route or append the newly selected destination at... -
Page 50: Pausing The Active Route
• to reorder the list. 3.4.3 Pausing the active route You do not need to pause the active route: when you start driving again, ZE-NC620DMH restarts the voice instructions from your position. 3.4.4 Cancelling the active route To cancel the navigated route, do one of the following: •... -
Page 51: Checking Route Alternatives For An Existing Route
Select one of the route alternatives and tap to return to the previous screen. ZE-NC620DMH recalculates the route. The orange line now shows the new recommended route. 3.4.6 Checking route alternatives for an existing route To recalculate the active route with a different route planning method, you can modify the Route settings (page 66). -
Page 52: Changing The Vehicle Used In Route Planning
Select one of the route alternatives then tap and hold for a few seconds to return to the Map screen. ZE-NC620DMH recalculates the route. The orange line now shows the new recommended route. 3.4.7 Changing the vehicle used in route planning To recalculate the active route for a different vehicle, do as follows. -
Page 53: Changing The Road Types Used In Route Planning
• • • ZE-NC620DMH recalculates the route optimised for the new vehicle type. The orange line now shows the new recommended route. 3.4.8 Changing the road types used in route planning To recalculate the active route with different road type preferences, do as follows. These changes can also be made in Settings (page 66). -
Page 54: Saving A Location As A Favourite Destination
NC620DMH plans the best toll-free route. • - ZE-NC620DMH includes ferries in a planned route by default. However, a map does not necessarily contain information about the accessibility of temporary ferries. You might also need to pay a fare on ferries. -
Page 55: Saving A Location As An Alert Point
to save the location as a new Favourite destination. 3.6 Saving a location as an alert point You can save any map location as an alert point (for example a speed camera or a railway crossing). Browse the map and select a location. The red Cursor appears there. Scroll down the list and tap On the newly opened screen, select the type of the alert point, the direction from which you expect the alert, and (if applicable) the speed limit for this alert point. -
Page 56: Editing An Alert Point
3.7 Editing an alert point You can edit a previously saved or uploaded alert point (for example a speed camera or a railway crossing). Browse the map and select the alert point to edit. The red circle appears around the alert point. -
Page 57: Off-Road Navigation
4 Off-road navigation When first started, ZE-NC620DMH calculates routes using the road network of the high quality vector maps provided with the product. You can switch the application to off-road mode in Navigation settings in one of the following ways: •... -
Page 58: Reference Guide
While driving without an active route: Smart Zoom will zoom in if you drive slowly and zoom out when you drive at high speed. 5.1.2 Daytime and night colour themes ZE-NC620DMH uses different colour themes during the day and during the night for both the map and the menu screens. •... -
Page 59: Green Routing
• : Results in a route with fewer turns and no difficult manoeuvres. With this option, you can make ZE-NC620DMH to take, for example, the motorway instead of a series of smaller roads or streets. •... -
Page 60: Road Safety Cameras And Other Proximity Alert Points
5.1.6 Speed limit warning Maps may contain information about the speed limits of the road segments. ZE-NC620DMH is able to warn you if you exceed the current limit. This information may not be available for your region (ask your local dealer), or may not be fully correct for all roads in the map. Speed warning can be fine-tuned in Sound and Warning settings (page 63). -
Page 61: Battery And Gps Position Quality Indicators
Devices with a built-in GPS receiver are permanently connected. On such devices, the icon does not appear in normal circumstances. ZE-NC620DMH is connected to the GPS receiver, but the signal is too weak and the receiver cannot determine the GPS position. GPS navigation is not possible. -
Page 62: Settings Menu
5.3 Settings menu You can configure the program settings, and modify the behaviour of ZE-NC620DMH. Tap the following buttons: The Settings menu has several options. Tap or scroll with your finger to see the full list. -
Page 63: Sound And Warnings
Button Description Adjust the sound volume, mute your device or change the voice guidance language. In addition, you can enable and set up different warnings and alerts. The content of the Quick menu (page 19) is fully customisable. Tap the button you want to change, and select its new function from the list. - Page 64 Maps may contain information about the speed limits of the road segments. ZE-NC620DMH is able to warn you if you exceed the current limit. This information may not be available for your region (ask your local dealer), or may not be fully correct for all roads in the map.
-
Page 65: Customise Quick Menu
This feature allows you to receive a warning when approaching a Road Safety Camera or other alert points like school zones or railroad crossings. You must ensure on your own liability that using this feature is legal in the country where you intend to use it. You can choose what alert point sources you want to use. -
Page 66: Route Settings
They can be enabled or disabled separately from toll roads. ZE-NC620DMH includes toll roads (pay roads where there is a per-use charge) in the routes by default. If you disable toll roads, ZE- NC620DMH plans the best toll-free route. - Page 67 ZE-NC620DMH excludes unpaved roads by default: unpaved roads can be in a bad condition and usually you cannot reach the speed limit on them. Vehicle profiles: When you first tap , you see the list of default vehicle profiles. You have...
-
Page 68: Vehicle Types
Set the actual weight of the vehicle. Select one or more hazard types if the vehicle carries dangerous material. Vehicle types: When creating a new vehicle profile, select one of the below vehicle types. Besides the below mentioned conditions, dimension, weight and freight hazard restrictions can also be taken into account when planning a route. -
Page 69: Map Settings
Results in a route with fewer turns and no difficult manoeuvres. With this option, you can make ZE-NC620DMH to take, for example, the motorway instead of a series of smaller roads or streets. 5.3.4 Map settings You can fine-tune the appearance of the Map screen. - Page 70 Button Description Switch the map view between a 3D perspective view and a 2D top- down view. Adjust the basic zoom and tilt levels to your needs. Three levels are available. Switch between daytime and night colour modes or let the software switch between the two modes automatically a few minutes before sunrise and a few minutes after sunset.
-
Page 71: Visual Guidance Settings
5.3.5 Visual guidance settings Adjust how the software helps you navigate with different kinds of route related information on the Map screen. The data fields in the corner of the Map screen can be customised. Tap this button and select the values you want to see. The values can be different when you navigate a route from when you are just cruising without a given destination. -
Page 72: Regional Settings
5.3.7 Regional settings These settings allow you to customise the application for your local language, measurement units, time and date settings and formats, as well as to choose the time zone. Button Description You can set the distance units to be used by the program. ZE- NC620DMH may not support all the listed units in some voice guidance languages. -
Page 73: Glossary
Colour theme ZE-NC620DMH comes with different colour themes for daytime or night use of the map and menu screens. Themes are custom graphic settings and they can have different colours for streets, blocks or surface waters in 2D and 3D modes, and they display shades or shadows in different ways in 3D mode. - Page 74 Road Safety Camera Special alert points for speed, red light or bus lane cameras. Different data sources are available. You can configure ZE-NC620DMH to warn you when you approach one of these cameras. Detecting the location of Road Safety Cameras is prohibited in certain countries. It is the sole responsibility of the driver to check whether this feature can be used during the trip.
-
Page 75: Copyright Note
This manual may not, in whole or in part, be reproduced or transmitted in any form either electronically or mechanically, including photocopying and recording, without the express written consent of ZENEC. © 2011 - ZENEC Data Source © 2006-2010 Tele Atlas. All rights reserved. This material is proprietary and the subject of copyright protection, database right protection and other intellectual property rights owned by Tele Atlas or its suppliers. - Page 76 ZENEC by ACR AG · Bohrturmweg 1 · Bad Zurzach · Switzerland www.zenec.com...
