GUITAR/BASS TUNER SAT100
INSTRUCTION MANUAL

PARTS OF YOUR TUNER AND THEIR OPERATION

Before use, install the batteries included with the tuner, following the instructions in "BATTERY
CHANGE".
Note: The batteries included with the tuner are monitor batteries, and the battery life may be shorter than
the specified period.
Power button
With each press, the tuner is turned on and off alternately.
Auto power-off function
If no button operation is made or no sound is input into the tuner for approximately 20 minutes
while the tuner is turned on, it will be turned off automatically to save the battery energy.
Selector button
Use the button to select the item of tuner setting. With each press, the setting item is selected in
order.
Printed mark
Setting item
Guitar/Bass setting
Mode setting
Reference pitch setting
Note (string name) setting
* For details, see "TUNER SETTING".
UP button
DOWN button
Use the buttons to change the settings of the item selected by pressing the selector button
two buttons change the setting of the selected item in the opposite order. For details, see "TUNER
SETTING".
Liquid crystal display
Setting item indication
The pointer "
" indicates the item currently selected.
Tuning meter
It shows the difference in pitch between the string name indicated on the display and the note
given by the instrument.
Tuning mode indication
The tuning mode currently selected is shown.
Cent/reference pitch indication
The difference in pitch between the string name indicated on the display and the note given by
the instrument is shown numerically. While the pitch setting is made, the current reference
pitch is shown.
String name indication
AUTO mode: The tuner automatically identifies and indicates the string name of the note
given by the instrument.
MANUAL and SOUND modes: The string name you have set is indicated.
Flat/sharp tuning indication
The current setting for flat/sharp tuning is shown.
GUITAR/BASS indication
The type of instrument to tune is shown.
Tuning guide
As a guide in tuning, it visually shows the difference in pitch between the string name indicated on
the display and the note given by the instrument by means of the LED lights.
• When the pitch of the input note is lower than that of the indicated string name, the " " LED lights up.
• When the pitch of the input note is higher than that of the indicated string name, the "
lights up.
• When the instrument is in tune, the LED at the center lights up in green.
Input jack
When tuning an electric guitar or bass, connect the output cord of the instrument to the input jack
. While the cord is connected to the input jack
Description
To set the instrument you wish to tune.
To set the tuning mode.
To set the frequency of the reference
pitch (A4).
To set the name of the string you wish to
tune.
setting
To set the flat/sharp tuning.
G/BASS
MODE
PITCH
NOTE
, the built-in microphone
. The
" LED
will not work.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAT100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seiko SAT100

  • Page 1 GUITAR/BASS TUNER SAT100 INSTRUCTION MANUAL PARTS OF YOUR TUNER AND THEIR OPERATION Before use, install the batteries included with the tuner, following the instructions in “BATTERY CHANGE”. Note: The batteries included with the tuner are monitor batteries, and the battery life may be shorter than the specified period.
  • Page 2 Output jack Bypass function The tuner outputs the signal input from the instrument connected with the input jack to an amplifier and other devices through the output jack Precautions on using the bypass function 1. Before connecting an amplifier to the output jack , be sure to set its volume control to the lowest level, and turn it off, to prevent any malfunction of the tuner and the amplifier.
  • Page 3 Also, bring the instrument close to the tuner to register a note. If it is difficult to tune the instrument with the built-in microphone, it is recommended that a microphone, such as SEIKO STM-20, sold separately from the tuner, be used together with the tuner. MEMORY BACKUP FUNCTION Even after the tuner is turned off, the following settings are stored in memory and will not be erased.
  • Page 4 SPECIFICATIONS MODE : AUTO mode ... Guitar/Bass MANUAL mode ..Guitar/Bass SOUND mode ..Guitar/Bass DISPLAY : Liquid crystal display and tuning guide TUNING RANGE : Guitar ..... 7B, 6E, 5A, 4D, 3G, 2B, 1E Bass ......LowB (LB), 4E, 3A, 2D, 1G, HighC (HC) : ±1 cent ACCURACY REFERENCE NOTE...
