La Crosse 512-811 Quick Setup Manual

Atomic Clock
512-811
with Weather Forecast
Quick setup manual
Snooze icon
WWVB
Reception
Forecast icon
Barometric Date Indoor
Pressure Temperature
History
SET UP:
INSTALL BATTERIES IN THE TRANSMITTER:

Remove the screws and the battery cover from the back of the

W186-E transmitter with a small screwdriver.

Select the channel to transmit the outdoor temperature to the display.
NOTE: if using more than one transmitter, set each to a different
channel to be displayed on the clock.

Insert two fresh AAA alkaline batteries into the transmitter,
observing the correct polarity (see markings in battery compartment).

Select Fahrenheit or Celsius for the sensor display.

Press TX button to send a signal to the clock.

Keep transmitter 5-10 feet from the clock

The transmitter display should be showing a temperature reading.
If not please check battery polarity or try a new set of batteries.
C/F Selection
TX Button
Battery Compartment
INSTALL BATTERIES IN THE CLOCK:

Remove the battery cover from the clock:

Insert a finger in the rounded depression at the bottom of
the battery cover.

Lift up and pull out to remove battery cover.

Install three fresh AA alkaline batteries according to the polarity
markings.

Replace battery cover.

Once the batteries are in place, all segments of the LCD will light up
briefly. Then the indoor temperature will be displayed. If the indoor
temperature is not shown in the LCD after 60 seconds, remove the
batteries and wait for at least 60 seconds before reinserting them.

Within three minutes the outdoor temperature should be displayed on
the clock. If the outdoor temperature is not displayed within three
minutes, remove the batteries from both units and start again.
Time

In order to ensure sufficient 434 MHz transmission, the outdoor
transmitter should be placed a distance of no more than 100 feet (30
meters, open air) from the Atomic clock.
Alarm icon
Outdoor
Wall mount
Temperature
Function
buttons
WWVB RADIO CONTROLLED TIME
The NIST radio station, WWVB, is located in Ft. Collins, Colorado and
transmits the exact time signal continuously throughout the United States at
60 kHz. The signal can be received up to 2,000 miles away through the
internal antenna in the atomic clock. However, due to the nature of the
Earth's Ionosphere, reception is very limited during daylight hours. The
atomic clock will search for a signal every night when reception is best.
If the tower icon flashes, but does not set the time or the WWVB tower does
not appear at all, then check the following:

Recommended distance from any interfering sources like computer
monitors or TV sets is a minimum of 6 feet (2 meters).

Within ferro-concrete rooms (basements, superstructures), the
received signal is weakened. In extreme cases, please place
the unit close to a window and/ or point its front or back towards the
Fort Collins, Colorado, transmitter.

During nighttime, the atmospheric disturbances are usually less severe
and reception is possible in most cases. A single daily reception is
Channel
adequate to keep the accuracy deviation below 1 second.
Selection
WWVB RECEPTION icon with full signal strength will appear on
Battery Cover
screen if the reception of atomic time is successful. The atomic clock will
have a daily synchronization at 02:03 and 03:03 everyday. Each reception
cycle is minimum 2.5 minutes and maximum 10 minutes.
BUTTONS:
NOTE: The time cannot be manually set while the clock is actively
searching for a WWVB signal. Please wait 3 minutes if signal search is in
progress.
SET TIME:

LANGUAGE: Hold the SET button until the Language will flash. Press
and release the PLUS button to set the Language (EN English, GE
German, FR French, SP Spanish, DU Dutch,). Press the SET button
once to continue.

YEAR: The Year will flash. Press and release the PLUS button to set
the Year. Press the SET button once to continue.

MONTH: The Month will flash. Press and release the PLUS button to
set the Month. Press the SET button once to continue.

DATE: The Date will flash. Press and release the PLUS button to set
the Date. Press the SET button once to continue.

NOTE: Day of week will set automatically.

HOUR: The Hour will flash. Press and release the PLUS button to set
Time Zone Map
the Hour. Press the SET button once to continue.
(four time zones)

MINUTES: The Minutes will flash. Press and release the PLUS button
to set the Minutes. Press the SET button once to continue.

12/24-HOUR TIME: 12hr or 24hr will flash. Press and release the
PLUS button to select 12-hour or 24-hour time mode. Press the SET
Battery
button once to continue.

compartment
WEATHER FORECAST ICON: The forecast icon will flash. Press and
release the PLUS button to select the forecast Icon that represents
Foldout stands
your current local weather. Press and release the SET button to exit.

NOTE: If possible, it is best to select the RAINY ICON when it is
raining outside. This allows for the most accurate future forecasts
based on barometric pressure changes.

DST: dSt on or dSt of will flash. Press and release the PLUS button to
turn the DST feature ON or OFF. Pres and release the SET button to
continue.
SET TIME ZONE:
TIME ZONE: Press the ZONE button to select four U.S. Time Zones:

ES Eastern

CS Central

MS Mountain

PS Pacific
NOTE: This station will only support these 4 Time Zones.
WEATHER FORECAST ICONS:
The unit predicts weather condition of the next 12 – 24 hours based on the
change of atmospheric pressure. The weather forecast is about 70-75%
correct. As weather conditions cannot be 100% correctly forecasted, we
cannot be responsible for any loss caused by an incorrect forecast.
+ -
Zz/CH, SET, AL, / , /CF, ZONE.
