Your new throat plate has been engineered and manufactured to Ryobi's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual.
Thank you for buying a Ryobi accessory kit.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
Zero Clearance Throat Plate
4070333
(For use with BT3000 & BT3100 Table Saws)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ryobi 4070333
Summary of Contents for Ryobi 4070333
- Page 1 (For use with BT3000 & BT3100 Table Saws) Your new throat plate has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Rules For Safe Operation
RULES FOR SAFE OPERATION ■ ALWAYS WEAR SAFETY GLASSES WITH SIDE Safe operation of this accessory requires that you read and understand this operator's manual, the operator’s SHIELDS. Everyday eyeglasses have only impact- manual for the table saw and all labels affixed to the tool. resistant lenses;... - Page 3 UNPACKING INFORMATION LOOSE PARTS LIST ■ Remove the loose parts from the box. Make sure 1. Zero clearance throat plates (2) that all items listed in the loose parts list are in- 2. Thread cutting screw - 1 in. (1) (For use with BT3000) cluded.
- Page 4 ASSEMBLY WARNING: The table saw should never be connected to a power supply when you are assembling or disassembling parts. Disconnecting the table saw will prevent acci- dental starting that could cause serious personal injury. PREPARING THE ZERO CLEARANCE THROAT PLATE FOR USE WITH A STANDARD BLADE To prepare the zero clearance throat plate for use with a standard blade, cut an opening for the blade guard,...
- Page 5 ASSEMBLY TO INSTALL THE ZERO CLEARANCE THROAT PLATE See Figure 3. Follow these steps to install the zero clearance throat plate. ■ Release the blade tilt lock lever and adjust the saw to 90° cut by setting the bevel angle to 0°. ■...
- Page 6 ASSEMBLY PREPARING THE ZERO CLEARANCE THROAT PLATE FOR USE WITH A DADO BLADE NOTE: Use only the Dado Set, part number 4650306, with the BT3000 and BT3100 table saws. WARNING: Turn saw off, remove key plate and unplug saw from power source before proceeding.
- Page 7 NOTES...
-
Page 8: Parts And Service
Zero Clearance Throat Plate 4070333 WARRANTY Ryobi warrants its accessories for a period of 90 days from the date of purchase. Batteries and chargers are warranted for a period of two years from the date of purchase. PARTS AND SERVICE For parts or service, contact your nearest Ryobi authorized service center.
