Your Dado Throat Plate has been engineered and manufactured to Ryobi's high standards for dependability, ease of
operation, and operator safety.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual.
Thank you for buying a Ryobi tool.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
#4070331 DADO THROAT PLATE
(FOR USE WITH THE BT3000 AND BT3100

TABLE SAWS)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4070331 DADO THROAT PLATE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ryobi 4070331 DADO THROAT PLATE

Summary of Contents for Ryobi 4070331 DADO THROAT PLATE

  • Page 1: Table Saws

    #4070331 DADO THROAT PLATE (FOR USE WITH THE BT3000 AND BT3100 TABLE SAWS) Your Dado Throat Plate has been engineered and manufactured to Ryobi's high standards for dependability, ease of operation, and operator safety. WARNING: To reduce the risk of injury, the user must read and understand the operator's manual.

  • Page 2: Rules For Safe Operation

    RULES FOR SAFE OPERATION Safe operation of this accessory requires that you read and DO NOT USE THIS PRODUCT WITH OTHER EQUIP- understand this operator's manual, the operator’s manual for MENT or for other purposes. the table saw and all labels affixed to the tool. ALWAYS DISCONNECT THE SAW FROM THE POWER SUPPLY BEFORE ASSEMBLING THIS KIT.

  • Page 3: Loose Parts List

    UNPACKING INFORMATION LOOSE PARTS LIST Remove the loose parts from the box. 1. Dado throat plate Inspect the dado throat plate carefully to make sure no 2. 10-24 x 34 in. flat head screws (3) breakage or damage occurred during shipping. TOOLS NEEDED If the dado throat plate is damaged, please call Phillips head screwdriver...
  • Page 4 Remove the inner blade washer and both spacers on the blade arbor to allow for the thickness of the dado blade. Refer to the instructions provided with your Ryobi dado set, part no. 4650306. Do not use other dadoes. Replace the inner blade washer, making sure it is tight against the arbor shoulder.
  • Page 5 ASSEMBLY Install dado throat plate: Lower the dado blade and secure the dado throat plate with the three screws provided. Locate the first threads very carefully to avoid stripping. See Figure 3. Rotate the dado blade by hand to make sure it is turning freely and does not contact the saw or throat plate.

  • Page 6: Warranty

    (FOR USE WITH THE BT3000 AND BT3100 TABLE SAWS) WARRANTY Ryobi warrants its accessories for a period of 90 days from the date of purchase. Batteries and chargers are warranted for a period of two years from the date of purchase. PARTS AND SERVICE For parts or service, contact your nearest Ryobi authorized service center.
