Summary of Contents for Tricity Bendix SE558
- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SLIP IN ELECTRIC COOKER SE558 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Always support the grill pan when it is in the These warnings are provided in the interests of your withdrawn or partially withdrawn position. safety. Ensure that you understand them all before Always use oven gloves to remove and replace the installing or using the appliance. -
Page 3: Table Of Contents
CONTENTS Care and Cleaning Cleaning Materials Cleaning the Outside of the Appliance Important Safety Information Cleaning the Control knobs and Handles Contents Cleaning the Ceramic Hob Description of the Appliance Hints and Tips Getting to Know Your Appliance Cleaning the Grill and Oven Furniture The Control Panel Cleaning Inside the Grill and Oven Before Using the Appliance... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE SLIP-IN ELECTRIC DOUBLE OVEN WARNING: THIS APPLIANCE MUST BE EARTHED Electronic Timer Control Panel Dual Grill / Top Oven Main Oven... -
Page 5: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES Hotplate Controls Grill/Top Oven Control Timer Main Oven Control Hotplate Controls Grill/Top Oven Indicator Neon Main Oven Indicator Neon... -
Page 6: Before Using The Appliance
BEFORE USING THE APPLIANCE GRILL AND OVEN FURNITURE RATING PLATE This is situated on the lower front frame of the The following items of grill and oven furniture have appliance and can be seen upon opening the door. been supplied with the appliance. Alternatively the rating plate may also be found on the back or top of some models (where applicable). -
Page 7: Electronic Time
ELECTRONIC TIMER Bell Symbol Button 1 = ) Decrease control and minute minder setting button Button 2 = ) Increase control ) Bell Symbol The electronic minute minder can also be used to show the time of day. Button 1 Button 2 Please note that this is a 24 hour clock, for example Fig 1. - Page 8 Fig 5. 2) THE MINUTE MINDER The minute minder gives an audible reminder at the end of any period of cooking up to 23 hours and 59 minutes. To set press button (1) and the display will read 0.00, see Fig. 5. Fig 6.
-
Page 9: The Ceramic Hob
THE CERAMIC HOB Do not use the appliance if the ceramic glass is damaged. If a fault or crack becomes visible, disconnect the appliance immediately from the electricity supply and contact your local Service Force Centre. USING THE HOB • To operate the hotplates turn the control knobs in either direction to vary the heat setting. -
Page 10: Hints And Tips
HINTS AND TIPS • Lift, rather than slide saucepans on and off the hob. This will reduce the risk of scratches and metal marks from saucepans with aluminium bases. Metal marks can be easily cleaned off providing they are not allowed to burn on. •... -
Page 11: The Dual Grill
THE DUAL GRILL CAUTION – Accessible parts may be hot when the grill is in use. Young children should be kept away. The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes, the centre section only can be used when cooking smaller quantities of food. -
Page 12: Hints And Tips
HINTS AND TIPS • In order to become acquainted with the performance of the Dual Grill it is advisable to check food regularly when grilling. • Food should be thoroughly dried before grilling to minimise splashing. Brush lean meats and fish lightly with a little oil or melted butter to keep them moist during cooking. -
Page 13: The Top Oven
THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweets and savoury flans or quiche. -
Page 14: Hints And Tips
HINTS AND TIPS • All cooking should be carried out using an oven shelf positioned in one of the shelf runners. • There should always be at least 2.5cm (1”) between the top of the food and the element. This gives best cooking results and allows room for rise in yeast mixtures, Yorkshire puddings, etc. -
Page 15: The Main Oven
THE MAIN OVEN The fan oven is particularly suitable for cooking larger quantities of food. The advantages of fan oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may need to add an extra 5 –... -
Page 16: Hints And Tips
HINTS AND TIPS • Arrange the shelves in the required positions before switching the oven on. Shelf positions are numbered from the bottom upwards. • When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 17: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. FAN OVEN TOP OVEN FOOD SHELF COOKING SHELF COOKING APPROX POSITION TEMP °C POSITION... -
Page 18: Oven Roasting Chart
ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C MEAT COOKING TIME TEMPERATURE 20-35 minutes per ½kg (1lb) Beef/ Beef boned 160-180°C and 20-35 minutes over Mutton/Lamb 160-180°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Pork/Veal/Ham 160-180°C 30-40 minutes per ½kg (1lb) -
Page 19: Defrost Feature
DEFROST FEATURE This main fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones, etc. -
Page 20: Care And Cleaning
CARE AND CLEANING Always switch off the electricity supply at the main wall switch and allow the appliance to cool before cleaning. CLEANING MATERIALS Before using any cleaning materials on your appliance, check that they are suitable and that their use is recommended by the manufacturer. -
Page 21: Daily Cleaning
DAILY CLEANING Use the recommended Hob Brite Cleaner daily. If soilage is not allowed to burn on it will be much easier to clean off. 1. Apply a small amount of Hob Brite in the centre of each area to be cleaned. 2. -
Page 22: Hints And Tips
HINTS AND TIPS TO REDUCE HOB SOILAGE: • Make sure the bottom of the saucepan and the cooking area are clean and dry before cooking begins. • Ensure saucepans large enough accommodate food to avoid boil overs. • If possible, wipe up spills and splatters as they occur, but take care to avoid steam burns. -
Page 23: Cleaning Inside The Grill And Oven Compartments
CLEANING INSIDE THE GRILL AND OVEN COMPARTMENTS The vitreous enamel coating in the grill/top oven and main oven compartments can be cleaned using normal oven cleaners or aerosol oven cleaners with care. Ensure that the manufacturers instructions are followed and that all parts are well rinsed afterwards. Aerosol cleaners must not come into contact with elements, the door seal, or any painted finishes as this may cause damage. -
Page 24: To Replace The Outer Glass
CLEANING BETWEEN THE OUTER AND INNER DOOR GLASS The outer door glass is removable for cleaning. TO REMOVE THE OUTER GLASS 1. Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. -
Page 25: Replacing An Oven Light Bulb
REPLACING AN OVEN LIGHT BULB The type of bulb required is a 300°C 25 watt small Edison Screw. Part number 572 491 5431-00/1 (Available through your local Service Force Centres). Disconnect appliance from electricity supply before replacing the bulb. Open the door and remove the shelves to enable easy access to the oven light assembly. -
Page 26: Something Not Working
SOMETHING NOT WORKING? Please carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. In-guarantee customers should make sure that the checks have been made as the engineer will make a charge if the fault is not a mechanical or electrical breakdown. -
Page 27: Service And Spare Parts
Email: service.eid@electrolux.ie CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department Tricity Bendix... -
Page 28: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •... -
Page 29: Technical Details
TECHNICAL DETAILS Voltage: 230-240 Volts AC 50Hz Wattage: 10.9-11.8kW Height: 900mm Width: 600mm Depth: 598mm Weight: 65 kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC... -
Page 30: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING: THIS APPLIANCE MUST BE EARTHED If your appliance has been damaged in transit, contact your supplier immediately. DO NOT attempt to install it. Your appliance left the factory fully packaged to protect it from damage. If it is delivered without packaging damage occurred,... - Page 31 NOTES...
- Page 32 Tricity Bendix, Major Appliances, Addington Way, Luton, Bedfordshire LU4 9QQ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice.
