- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SLIP IN ELECTRIC COOKER SE305 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SE 305 Voltage: 230-240 Volts AC 50Hz Wattage: 9.3-10.2kW Height: 900mm Width: 500mm Depth: 600mm Weight: 50kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC... -
Page 3: Table Of Contents
CONTENTS Technical Details ............................ 2 Contents ..............................3 Preface ..............................5 Safety ............................... 6 Before Installation ........................... 6 During Operation ..........................6 After Use ............................7 General ............................7 Introduction ............................. 8 Rating Plate ............................ 8 Installation ............................8 General Notes on Using Your Appliance ..................9 Oven Indicator Neon ........................ - Page 4 CONTENTS Defrost Feature ............................19 Uses of Defrost Feature ........................19 Selecting Defrost ..........................19 Things to Note ..........................19 Hints and Tips ..........................19 Care and Cleaning ..........................20 Cleaning Materials .......................... 20 Cleaning the Outside of the Appliance ................... 20 Cleaning the Sealed Hotplates and Hotplate Trims ................
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN DURING OPERATION THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND This appliance is not intended to THEM ALL BEFORE INSTALLING OR be operated by means of an external timer or separate remote USING THE APPLIANCE. control system. -
Page 7: After Use
Take care follow For hygiene and safety reasons recommendations given this appliance should be kept tending the food when grilling. clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the Always oven gloves grill pan. -
Page 8: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE The cable should be routed away from potentially hot areas marked by X in the diagram below. This is situated on the front frame of the appliance and can be seen upon opening the door. Alternatively the rating plate may also be found on the back or top of some models (where applicable). -
Page 9: General Notes On Using Your Appliance
Note: Vapours from the oven vent may in time cause GRILL AND OVEN FURNITURE discolouration of wallcoverings behind the appliance. For ease of cleaning it may be preferable to tile The following items of grill/oven furniture have been behind the appliance. supplied with the appliance: Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. -
Page 10: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Fan Oven Control - Grill Control - Hotplate Controls - Fan Oven Indicator Neon... -
Page 11: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 12: Deep Fat Frying
DEEP FAT FRYING 6. Frying temperatures Celsius Fahrenheit Scale (°C) Scale (°F) SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one third full of oil, DO NOT cover the pan with a lid First frying of potatoes and DO NOT leave the pan unattended. -
Page 13: The Grill
THE GRILL USES OF THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL THE GRILL PAN AND HANDLE · To operate the grill open the grill door and turn the grill control in either direction. -
Page 14: Hints And Tips
To correctly locate the grill pan on the shelf, ensure · When toasting bread use the straight shelf in that the cut out on the underside of the handle position 1 with the grid in the high position. bracket locates over the front bar of the shelf. ·... -
Page 15: The Fan Oven
THE FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5 – 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. -
Page 16: Hints And Tips
HINTS AND TIPS · Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. · When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 17: Fan Oven Cooking Chart
FAN OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. FAN OVEN FOOD SHELF COOKING APPROXIMATE POSITION TEMP (°C) COOK TIME (m) Biscuits 180-190... -
Page 18: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C, Medium : 60-70°C, Well done : 70-80°C MEAT FAN OVEN COOKING TIME 20-35 minutes per ½kg (1lb) Beef 160-180°C and 20-35 minutes over Beef, boned 160-180°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Mutton and Lamb 160-180°C... -
Page 19: Defrost Feature
DEFROST FEATURE Small or thin fish fillets, frozen peeled prawns, cubed USES OF DEFROST FEATURE or minced meat, liver, thin chops, steaks etc., can be thawed in 1 – 2 hours. This fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. -
Page 20: Care And Cleaning
CARE AND CLEANING BEFORE CLEANING THE APPLIANCE THINGS TO NOTE ALWAYS ALLOW THE COOLING FAN TO The red spot in the centre of the hotplates may be COOL THE APPLIANCE DOWN BEFORE removed with some abrasive cleaning agents. This is not a fault and does not affect the performance of SWITCHING OFF AT THE ELECTRICITY the hotplates. -
Page 21: Cleaning The Grill And Oven Furniture
CLEANING THE GRILL AND OVEN HINTS AND TIPS FURNITURE · Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if All removable parts, except the grill pan handle can abrasives or aerosol sprays of any kind are used. be washed in the dishwasher. -
Page 22: Something Not Working
SOMETHING NOT WORKING? Before calling an Engineer please carry out the The oven temperature is too high or low: following checks, you may be able to solve the problem without the expense of an engineer. * Check that the recommended temperatures If our Service Engineer finds that the problem is listed are being used (see page 17). -
Page 23: Service And Spare Parts
Email: service.eid@electrolux.ie CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department Tricity Bendix 55 –... -
Page 24: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 25: Notes
NOTES... - Page 26 NOTES...
- Page 27 NOTES...
- Page 28 Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
