Summary of Contents for Olympus Stylus 1000
- Page 1 DIGITAL CAMERA ENGLISH Basic FRANÇAIS 28 Manual ESPAÑOL 54 DEUTSCH 80 РУССКИЙ 106...
-
Page 2: Table Of Contents
Connecting the camera ..............15 Playback on a TV................... 15 Direct Printing (PictBridge) ..............16 Transfer images ................. 17 OLYMPUS Master Software............... 19 Specifications..................20 Safety precautions ................22 Before using your camera, read this manual carefully to ensure correct use. -
Page 3: Gather These Items (Box Contents)
LI-12B Lithium Ion Battery LI-10C Battery Charger USB Cable AV Cable OLYMPUS Master Software CD-ROM Items not shown: Advanced Manual (CD-ROM), Basic Manual (this manual), and warranty card. Contents may vary depending on purchase location. Attach the strap Pull the strap tight so that it does not come loose. -
Page 4: Prepare The Battery
Prepare the battery a. Charge the battery Lithium Ion Battery Power Cable Battery Charger Charging Indicator Light On (Red): Charging Light On (Green): Charging complete (Charging time: Approx. 2 hours) AC Wall Outlet Battery comes partially charged. b. Insert the battery in the camera •... -
Page 5: Turn The Camera On
Turn the camera on This explains how to turn on the camera in shooting mode. a. Set the mode dial to K. When shooting still pictures (shooting mode) When shooting movies (shooting mode) When viewing pictures (playback mode) Still picture shooting modes This function allows you to shoot with the camera's automatic settings. -
Page 6: Set Date And Time
Set date and time About the date and time setting screen Y-M-D (Year-Month-Day) Hour M D D T I M E T I M E Minute ----.--.-- --:-- ----.--.-- --:-- Date formats (Y-M-D,M-D-Y,D-M-Y) Y / M / D Y / M / D CANCEL MENU Exits a setting. - Page 7 Set date and time e. Press the 1F button and the 2Y but- ton to select [D]. M D D T I M E T I M E 2006 2006.11 11.26 26 --:-- --:-- Y / M / D Y / M / D CANCEL MENU f.
-
Page 8: Select A Language
ENGLISH press the o button. FRANCAIS The selected language is set. ESPAÑOL You can add other languages to your PORTUGUES camera with the provided OLYMPUS BACK MENU Master software. Prease refer to the Advanced Manual. -
Page 9: Take A Picture
Take a picture a. Hold the camera Horizontal grip Vertical grip b. Focus Place this mark over your subject. Shutter Button (Pressed halfway) [ IN IN ] HQ 3648 3648 × 2736 2736 The number of remaining still pictures is displayed. The green lamp indicates the focus and exposure are locked. -
Page 10: Review Your Pictures
Review your pictures a. Set the mode dial to q. Mode Dial [ IN IN ] Arrow Pad Next Picture '06.11.26 '06.11.26 12:30 12:30 1 0 0 - 0 0 0 1 1 0 0 - 0 0 0 1 Prev. -
Page 11: Basic Operation
Basic operation Shooting Mode Buttons While in shooting mode, use these buttons for quick access to some of the more commonly used features. 4& button (Macro Mode) Use macro or super macro mode when taking close-up pictures such as of a flower. m button (MENU) Press this button to display the top menu. -
Page 12: En S Modes (Scene Mode)
Modes (Scene mode) This function allows you to switch the s (Scene mode) according to the subject. Set the mode dial to s. Press 12 to select a scene mode, and press o. PORTRAIT BACK MENU button button Mode Dial Arrow pad (1243) Shooting s (Scene) Modes... -
Page 13: Self-Timer
Self-Timer Press 2Y. Self-Timer Lamp Press 12 to select [Y ON], and press o. Press the shutter button fully to take the picture. The self-timer lamp lights for approximately 10 seconds after the shutter button is pressed, then starts blinking. After blinking for approximately 2 seconds, the picture is taken. -
Page 14: Menus And Settings
Menus and settings Top Menu Press m to display the top menu. IMAGE IMAGE IMAGE QUALITY QUALITY QUALITY CAMERA CAMERA CAMERA SETUP SETUP SETUP RESET RESET RESET MENU MENU MENU SILENT SILENT SILENT MODE MODE MODE EXIT MENU Top menu in shooting mode Use the arrow pad (1243) to select menu items, and press o to set them. -
Page 15: Connecting The Camera
Connecting the camera Playback on a TV Use the AV cable provided with the camera to playback recorded images on your TV. Both still pictures and movies can be played back. Make sure that the TV and camera are turned off. Connect the multi-connector on the camera to the video input terminal on the TV using the AV cable. -
Page 16: Direct Printing (Pictbridge)
Direct Printing (PictBridge) Using the provided USB cable, you may connect your camera directly to a PictBridge compatible printer such as the Olympus P-11 to make prints. In playback mode, display the picture you want to print out on the monitor. -
Page 17: Transfer Images
Transfer images a. Install the software Insert the OLYMPUS Master CD- ROM. Windows: Click the “OLYMPUS Master“ button. Macintosh: Double-click the “Installer“ icon. Simply follow the on-screen instructions. b. Connect the camera to the computer Connect the camera and computer using the USB cable (included). - Page 18 • For more detailed information regarding camera setup and usage, please refer to the camera’s “Advanced Manual” provided on CD-ROM. • For more details on using the OLYMPUS Master software, please refer to the (electronic) reference manual located in the OLYMPUS Master folder on your hard drive.
-
Page 19: Olympus Master Software
CD/DVD writing functions, and a lot more, allowing you to greatly expand your digital photograph capabilities. You can upgrade your software to OLYMPUS Master Plus via the Internet. You need to have OLYMPUS Master installed in a computer with an Internet connection. User Registration... -
Page 20: Specifications
Image pickup device : 1/1.8" CCD (primary color filter), 10,370,000 pixels (gross) Lens : Olympus lens 7.4 to 22.2 mm, f2.8 to 4.7 (equivalent to 35 to 105 mm on a 35 mm camera) Photometric system : Digital ESP metering, spot metering system Shutter speed : 4 to 1/1000 sec. - Page 21 (Lithium ion battery (LI-12B) Product type : Lithium ion rechargeable battery Standard voltage : DC 3.7 V Standard capacity : 1230 mAh Battery life : Approx. 300 full recharges (varies on usage) Operating environment Temperature : 0°C to 40°C (32°F to 104°F) (charging)/ -10°C to 60°C (14°F to 140°F) (operation)/ 0°C to 30°C (32°F to 86°F) (storage) Dimensions...
-
Page 22: Safety Precautions
Safety precautions Weatherproof feature This camera is weatherproof, but it cannot be used underwater. Olympus will not assume any responsibility for malfunction of the camera caused by water getting inside as a result of misuse by the user. The camera is weatherproof and is not damaged by water spray from any direction. - Page 23 CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL. An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instructions in the documentation provided with the product.
- Page 24 Handling the Camera WARNING ( Do not use the camera near flammable or explosive gases. ( Do not use the flash on people (infants, small children, etc.) at close range. • You must be at least 1 m (3 ft.) away from the faces of your subjects. Firing the flash too close to the subject’s eyes could cause a momentary loss of vision.
- Page 25 DANGER • The camera uses a lithium ion battery specified by Olympus. Charge the battery with the specified charger. Do not use any other chargers. • Never heat or incinerate batteries.
-
Page 26: For Customers In Europe
Olympus does not assume any liability for accidents or damage that may result from the use of a battery and/or battery charger that are not genuine Olympus accessories. - Page 27 Imaging Europa GmbH as stipulated on the website: http://www.olympus.com. During the one year period of the World Wide Warranty the customer may turn the product in at any Olympus service station. Please notice that not in all countries such Olympus service station exists.
- Page 28 2006 Printed in Japan VH705801 1AG6P1P3257--...
