CONNECTIONS
CONNECTIONS
E
Connecting a DVD Player/Recorder, Video Recorder or
Cable/Satellite Box
Source should be set to ATV/analogue
TV Aerial
Wall Socket
14
A
B
G
F
DVD or VCR
RF
RF
IN
OUT
A
HDMI 2
B
USB
C
EARPHONE
D
CI CARD IN
E
HDMI 1
F
VGA(PC) In
G
VGA(PC) Audio In
H
COMPONENT (HD)
I
AV in
J
RF IN
K
COAX Audio Out
C
D
I
H
RF IN
Connections
HDMI input
USB port
3.5mm Earphone output
Common Interface Card Input
HDMI input
VGA-PC input
3.5mm PC audio input
Mini Component input (YPbPr)
Composite / Video Input
RF / TV Aerial Input
Digital Coax output
K
J
