- Page 1 LC - 20SD5E LC - 20SD5S LCD COLOUR TELEVISION LCD-FARBFERNSEHGERÄT TÉLÉVISION COULEUR À ÉCRAN À CRISTAUX LIQUIDES (LCD) TELEVISORE A COLORI LCD LCD-KLEURENTELEVISIE TELEVISIÓN EN COLOR LCD OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE MANEJO...
- Page 2 SPECIAL NOTE FOR USERS IN THE UK The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
-
Page 3: Table Of Contents
Supplied accessories .............. Useful features ................6 Removing the covering sheet ..........1 Still image ................16 Dear SHARP customer ..............2 Using the Programme Table ..........16 Important Safety Precautions ............. 2 Teletext function ..............16 Trademarks ................... 2 DTV menu operations .............. -
Page 4: Dear Sharp Customer
Dear SHARP customer Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of troublefree operation of your product, please read the Important Safety Precautions carefully before using this product. Important Safety Precautions •... -
Page 5: Quick Guide
Quick guide Setting the TV Rear view Round lock for Removing the terminal Kensington Security cover Standard slot* * Using the Kensington Lock • This LCD TV set has a Kensington Security Standard slot for use with a Kensington MicroSaver Security System. -
Page 6: Inserting The Batteries
Quick guide Inserting the batteries Before using the TV for the first time, insert two “AA” size batteries (supplied). When the batteries become depleted and the remote control unit fails to operate, replace the batteries with new “AA” size batteries. Open the battery cover. -
Page 7: Remote Control Unit
Quick guide Remote control unit (Standby/On) 5 P ( Enter standby mode or turn on the TV/DTV: Select the channel. power. (See page 8.) External: Switch to TV or DTV input mode. DTV/RADIO* Teletext: Move to the next/previous DTV: Switch between RADIO and page. -
Page 8: Tv (Front/Top/Side View)
Quick guide TV (Front/Top/Side view) COMMON INTERFACE slot Control panel ■ Using the control panel of the main unit • (Input), P ( )/( ) (Channel), (+)/(–) (Volume) and MENU on the control panel of the main unit have the same functions as the same buttons on the remote control. -
Page 9: Connecting External Devices
Quick guide Connecting External Devices You can enjoy picture and sound by connecting devices, such as a VCR or home video game system, to the terminals located on the rear of the LCD TV set. When connecting an external device, turn off the power of the LCD TV set first to prevent any possible damage. -
Page 10: Turning On The Power
Quick guide NOTE Turning on the power • With “Automatic search” of “First installation”, digital broadcasts are scanned after scanning analogue Press on the TV. broadcasts. If you want to operate the digital mode • indicator on the TV changes from red to green. first, press END and then press DTV/TV. -
Page 11: Menu Operations
Menu operations Menu operation buttons On-Screen Display Example Use the following buttons on the remote control unit to operate the menu. ① ② ③ ④ ⑤ Picture menu ① • To adjust the picture settings. Sound menu ② • To adjust the audio settings. Setup menu ③... -
Page 12: Common Operations
Menu operations Common operations Picture menu Menu Operation: A Press MENU and the MENU screen displays. ① Press ◀/▶ to select the desired menu. ② Press ▲/▼ to select the desired menu item, and ③ then press OK (Example: AV mode, Film mode, etc.). -
Page 13: Picture Mode Settings
Menu operations Sound menu Picture Mode Settings Menu Operation: A (page 0) You can make various picture mode settings. Selectable items Description AV mode DYNAMIC* For a clear-cut image emphasising high contrast for sports viewing. STANDARD* For a highly defined image Sound adjustments in a normally bright room. -
Page 14: Setup Menu
Menu operations For the “Loudsp. sound” setting Setup menu • The sound output modes differ depending on whether or not a NICAM or A2 stereo signal is received. (See page For the “Auto vol.” setting • Different sound sources, fairly often do not have the same volume level, for example the changing from movie to the advertisements. -
Page 15: Programmes
Menu operations Programmes TV only Manual adjustment This section describes how to set up analogue TV Individual settings of programmes can be adjusted. channels manually. Selectable Choice/ Press MENU to display the Menu screen. Description items Value range Press ◀/▶ to select “Setup”. Channel 0–99 The channel changes to the higher... -
Page 16: Wide Mode
Menu operations Features menu Wide mode Menu Operation: A (page 0) You can select the picture size. Selectable picture size varies with the type of signal received. Selectable Description items Auto Features Settings The optimum Wide mode is automatically chosen for every broadcast, even if broadcast signal format will be changed, Menu Operation: A (page 0) and VCR or DVD containing the WSS... -
Page 17: Child Lock
Menu operations To set a Child Lock for individual programmes Child lock Perform steps and 2 in [2] Setting a Child Important: Lock to display the “Child lock” screen. • Please refer to page 31 for “IMPORTANT NOTE ON Press ▲/▼... -
Page 18: Useful Features
Useful features Button functions Still image Buttons Description You can freeze a motion picture on the screen. Press Increase or decrease the page number. Colour (Red/ Select a group or block of pages displayed Press again to exit still image. Green/Yellow/ in the coloured brackets at the bottom of the Blue) -
Page 19: Dtv Menu Operations
DTV menu operations DTV menu operation buttons DTV On-Screen Display Example Use the following buttons on the remote control unit to operate the DTV Menu. Main menu Language Setup ① ② ③ ④ ⑤ ⑥ ⑦ Navigate Language Setup ① •... -
Page 20: About Using The Character Set Screen
DTV menu operations About using the character set screen Press ◀/▶ to select a desired language for each item. In some cases you may be prompted to enter Press END or OK. characters. See below for details. Sample Alpha Numerical Character Set screen NOTE •... - Page 21 DTV menu operations Fav (Favourite) Skip Assign services to four different favourite groups. Services that are set to skip will not be picked up when pressing P ( Press ▲/▼ to select the desired service. Press ▲/▼ to select the desired service. Press on the remote control.
-
Page 22: Installation
DTV menu operations Installation Move This section describes how to reconfigure the DTV Sort the order of the selected service by moving the settings after conducting Initial auto installation on service position. page 8. Press ▲/▼ to select the desired service. Auto Scan Press 7 on the remote control. -
Page 23: Carrier Setup
DTV menu operations System Configuration Carrier Setup This is provided for you to rename (label), delete, Configure On-Screen Display and Child Lock or re-scan carriers. “Carrier” in this context refers settings. to a service station that provides a set of individual services. -
Page 24: Password Setup (Parental Lock)
DTV menu operations Password Setup (Parental Lock) Software upgrade This function allows TV and Radio services to be The software for controlling the built-in DTV decoder restricted. It prevents children from watching violent can be upgraded when necessary. In Great Britain or sexual scenes that may be harmful. -
Page 25: Common Interface
DTV menu operations NOTE Common Interface • To view paid TV broadcasting, you need to make a contract with a service provider. Check the detailed information on the Common Please contact a service provider for details. Interface module card in use. •... -
Page 26: Useful Features (Dtv)
Useful features (DTV) About EPG To watch an event currently on-air, press OK. • The “ ” button of Navigation buttons will be With the Electronic Programme Guide (EPG), you displayed as “ ” when the cursor is selecting View an event currently on-air, and other than this will can check the schedule of DTV and Radio events, display “... -
Page 27: Using The Digital Channel List
Useful features (DTV) Viewing a service banner Changing the start time of the Event Select the start time of the event to change and A service banner shows event names, start/end time press the YELLOW (Edit Timer). of event, and other useful information. Change the start time with ▲/▼... -
Page 28: Using The Multi Audio Function
Useful features (DTV) Using the Digital Service (UK only) Using the multi audio function Change the audio mode and language for the Some services bring you programmes with currently viewed service. the Digital Service, letting you experience DTV interactively. Press when no other menu screen is When provided, the Digital Service will start when displayed. -
Page 29: Appendix
Appendix Communication procedure PC compatibility chart Send the control commands from the PC via the RS- 232C connector. Horizontal Vertical VESA The TV operates according to the received Resolution Frequency Frequency Standard command and sends a response message to the PC. Do not send multiple commands at the same time. - Page 30 Appendix Commands CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS POSITION H-POSITION PC (-30 POWER SETTING POWER OFF H P O S P O W R 0 to +30) (STANDBY) H P O S ? ? PC (-30 to +30) INPUT INPUT SWITCHING T G D _...
-
Page 31: Troubleshooting
Appendix Troubleshooting Problem Possible Solution • No power. • Check if you pressed on the TV. (See page 8.) If the indicator on the TV lights up red, press on the remote control unit. • Is the AC cord disconnected? (See page 3.) •... -
Page 32: Specifications
0°C to +40°C • As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 33: End Of Life Disposal
If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities. - Page 34 Unit: mm 317.7 68.3 89.4 403.3 157.7...
- Page 35 SHARP ELECTRONICS (Europe) GmbH SHARP ELECTRONICS (Europe) GmbH Sonnistraße 3, D-20097 Hamburg, Deutschland Sonnistraße 3, D-20097 Hamburg, Deutschland Printed on environmentally friendly paper Printed in Poland Auf ökologischem Papier gedruckt Gedruckt in Polen Imprimé sur papier écologique Imprimé en Pologne...
